1 Installation and Setup

Euphonix is dedicated to making your MC Mix experience enjoyable and trouble-free
so we will periodically update the following software and documentation:
• EuControl: This software runs your MC Mix and communicates to your audio/video appli-
cation. Always download the new version if prompted to do so when you launch EuControl.
• MC Mix User Guide (PDF): This is the complete user guide for your MC Mix.
• EuCon Application Setup Guide (PDF): The MC Mix supports many applications, each with a
slightly different setup procedure. This document includes supplementary instructions for
each application.
Before proceeding, download the latest versions from:

Unpacking and Elevating the MC Mix

Unpack your MC Mix, power adapter, AC power cord, installation CD, Ethernet crossover
cable, and riser brackets from its box.
The MC Mix can be elevated or angled using small foldout legs on the bottom of the
unit or elevated and angled by attaching the larger riser brackets. Since either method
requires turning the MC Mix over, it is easier to do this before attaching any cables.
Turn it over and place it on a soft surface.
Pull out all four of the small foldout legs to moderately elevate the unit; pull out only
the back two to angle the unit towards you (Figure 1-1 left).
Two larger, detached riser brackets elevate and angle the unit more than the foldout
legs. Use moderate force to snap them into the bottom panel as shown in Figure 1-1.
NOTE: To remove the riser brackets, see the MC Mix User Guide.
Foldout
leg
Riser
bracket
Figure 1-1 Foldout leg (left); riser bracket (right)
