Hanna Instruments HI 99556 Instruction Manual

Instruction Manual
HI 99551 • HI 99556
Infrared Thermometers
for the Food Industry
w w w . h a n n a i n s t . c o m

WARRANTY

HI 99551 and HI 99556 are warranted for two years against
defects in workmanship and materials when used for its intended purpose
and maintained according to instructions. Probes are guaranteed for
a period of six months.
This warranty is limited to repair or replacement free of charge. Damages
due to accident, misuse, tampering or lack of prescribed maintenance are
not covered. If service is required, contact the dealer from whom you
purchased the instrument. If under warranty, report the model number,
date of purchase, serial number and the nature of the failure. If the repair
is not covered by the warranty, you will be notified of the charges in-
curred. If the instrument is to be returned to Hanna Instruments, first
obtain a Returned Goods Authorization Number from the Customer Ser-
vice department and then send it with shipment costs prepaid.
When shipping any instrument, make sure it is properly packaged for
complete protection.
All rights are reserved. Reproduction in whole or in part is prohibited
without the written consent of the copyright owner.
Hanna Instruments reserves the right to modify the design, construction
and appearance of its products without advance notice.
Dear Customer,
Thank you for choosing a Hanna product.
This manual will provide you with the necessary information
for the correct operation of the meter.
If you need additional technical information, do not hesitate
to e-mail us at tech@hannainst.com.
These instruments are in compliance with the directives.

PRELIMINARY EXAMINATION

Remove the instrument from the packing material and exam-
ine it carefully to make sure that no damage has occurred
during shipment. If there is any damage, notify your Dealer.
Each meter is supplied complete with:
• HI 765PW temperature probe (HI 99556 only)
• 9V battery
• instruction manual
Note: Conserve all packing material until the instrument has
been observed to function correctly. Any defective item
must be returned in its original packing.

GENERAL DESCRIPTION

HI 99551 and HI 99556 thermometers employ infrared technol-
ogy to measure the surface temperature.
Infrared measurements are extremely practical with a fast re-
sponse time, typically around 1 second.
Another main advantage is the non-intrusive nature of the
measurement, which is particularly attractive in the food indus-
try since it translates itself into substantial savings by leaving
products intact, especially those sealed or pre-wrapped. This type
of non-intrusive measurement is also useful when the surface
temperature is high, for difficult-to-reach places or due to hy-
giene requirements.
Simply point to the product or the spot and hold down the
measurement key. The measured value will be immediately dis-
played on the LCD.
If in addition to surface measurement, you must check the core
temperature too, then HI 99556 is the ideal solution: simply
attach the external probe to the meter and you will have a 2-in-
1 infrared-thermistor thermometer.
Different models are available, with different temperature ranges.

FUNCTIONAL DESCRIPTION

1. Infrared sensor
2. Temperature probe connector (HI 99556 only)
3. Liquid Crystal Display (LCD)
4. ON/OFF button
5. IR/CONTACT button to select infrared sensor or external
probe (HI 99556 only)
6. Wrist-strap

SPECIFICATIONS

HI 99551-00 HI 99551-01 HI 99551-10
HI 99556-00 HI 99556-01 HI 99556-10
Range IR Sensor
-10 to 300°C 14 to 572°F -20 to 199.9°C
Range Probe (HI 99556 only)
-40 a 150°C -40 a 302°F -40 to 150.0°C
Resolution IR Sensor
1°C 1°F 0.1°C
Resolutio Probe (HI 99556 only)
0.1°C 1°F 0.1°C
Accuracy IR Sensor
±2% of reading or ±2°C (-00 and -10 models);
±2% of reading or ±3°F (-01 models)
Accuracy Probe (HI 99556 only)
±0.5°C (-20 to 120°C) /±1°F (0 to 250°F);
±0.5°C / ±1°F +1% reading (outside)
Typical EMC Deviation IR Sensor
±1°C ±2°F ±1°C
Typical EMC Deviation Probe (HI 99556 only)
±0.5°C ±1°F ±0.5 °C
IR Sensor
Response Time 1 second
Optic Coefficient 3:1 (distance/target diameter)
Minimum Distance 30 mm (1.2'')
Emissivity 0.95 (fixed)
Wave Length 6 a 14 µm
Probe HI 765PW (included) (HI 99556 only)
Battery Type 1 x 9V alkaline (IEC 6LR61)
Battery Life approx. 150 hours of continuous use
Environment 0 to 50°C (32 to 122°F);
RH max 95%
Dimensions 143 x 80 x 38 mm (5.6 x 3.2 x 1.5")
Weight 320 g (11.3 oz.)
