Portable microprocessor printing and logging k-type thermocouple thermometers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
Untitled-27
1
Instruction Manual
HI 92701 - HI 92704
HI 92801 - HI 92804
Portable Microprocessor
Printing and Logging
K-type Thermocouple
Thermometers
h t t p : / / w w w . h a n n a i n s t . c o m
These Instruments are in
Compliance with the CE Directives
2
Dear Customer,
Thank you for choosing a Hanna Instruments Product.
Please read this instruction manual carefully before using the instru-
ment. This manual will provide you with all the necessary information
for the correct use of the instrument, as well as a precise idea of its
versatility in a wide range of applications.
These instruments are in compliance with
1 and EN50082-1).

TABLE OF CONTENTS

TABLE OF CONTENTS
TABLE OF CONTENTS
TABLE OF CONTENTS
TABLE OF CONTENTS
PRELIMINARY EXAMINATION ........................................................ 3
GENERAL DESCRIPTION ................................................................ 3
LCD DISPLAY FUNCTIONAL DESCRIPTION ...................................... 4
SPECIFICATIONS HI 92701 AND HI 92704 .................................. 7
SPECIFICATIONS HI 92801 AND HI 92804 .................................. 7
OPERATIONAL GUIDE ................................................................... 8
DATA TRANSFER TO PC .............................................................. 24
FAULT FUNCTIONS ..................................................................... 25
MEMORY ORGANIZATION ........................................................... 25
PRINTER MAINTENANCE ............................................................. 26
BATTERY REPLACEMENT .............................................................. 28
CALIBRATION ............................................................................. 29
ACCESSORIES ............................................................................. 30
WARRANTY ................................................................................ 34
CE DECLARATION OF CONFORMITY .............................................. 35
2
directives (EN 50081-
ISO 9000 Certified
Company since 1992
