Elkay Lustertone ELUH4020 Specifications

SPECIFICATIONS

GENERAL
Highest quality sink seamlessly drawn of #18 gauge, type 304
(18-8) nickel bearing stainless steel. Underside of sink is fully
protected by heavy duty Sound Guard
Designed to accept waste disposer.
DESIGN FEATURES
Bowl Depth: 9-7/8" (left bowl), 5" (center), 7-7/8" (right bowl).
Finish: Exposed surfaces are hand blended to a lustrous
highlighted satin finish.
Underside: Fully protected by heavy duty Sound Guard
undercoating to prevent condensation and deaden sound.
OTHER
Drain Opening: 3-1/2".
NOTE: All Elkay custom design undermount sinks are designed
to affix easily to the underside of any solid surface countertop.
OPTIONAL ACCESSORIES
Rinsing Baskets: LKRB1611, LKRB1614, LKRB715 and
LKERBSS.
Bottom Grids: LKOBG1814 and LKOBG1613.
Cutting Boards: CBS1316, CBS1418, CBS715, CBR1316 and
CBR1418.
This sink complies with ANSI Standard A112.19.3M.
This sink is listed by the International Association of
U P
C Plumbing and Mechanical Officials as meeting the
requirements of the Uniform Plumbing Code.
SINK DIMENSIONS (INCHES)*
Overall
Model
Number L W L
1
ELUH4020 40 20 / 14 18 9
2
*Length is left to right. Width is front to back.
**Template and countertop mounting clips are packed with every sink.
1-1/4"
7"
5"
15-3/4"
20-1/2"
18"
1-3/4" R
1-1/4"
1-1/4" 14"
9-7/8"
1-3/4" R
12"
Model ELUH4020 Illustrated
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
® undercoating.
Inside Inside Inside
Left Center Right
Bowl Bowl Bowl
W D L W D L W
7 1 3 1
/ 7 / 15 / 5 13 / 16 7
8 2 4 2
3-1/2" DIA. HOLE
5"
18-1/2"
16"
6-3/4"
3" R
1-1/4"
13-1/2"
7-1/2"
40"
5"
7-7/8"
11-3/4"
2222 Camden Court
Oak Brook, IL 60523
Lustertone ®
®
Minimum
Cutout in Cabinet
D Countertop Size
See
7
/ 45
8
Template**
Installation Profile of ELUH Double Bowl Models
The template provided with each ELUH sink provides
the only type of installation recommended by Elkay.
COUNTERTOP
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
(ELUH Double bowl)
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Undermount Triple Bowl Sink
Model ELUH4020
Model ELUH4020
Ship.
Wt.
Lbs.
30
CONTOUR EDGE
TO CUSTOMER DESIRE
1-1/8"
Printed in U.S.A.
©2003 Elkay
(Rev. 11/03)
1/2"
SILICONE CAULK
(NOT FURNISHED)
SINK
1-133B
