Elkay Lustertone ELU129 Specifications

SPECIFICATIONS

GENERAL

Highest quality sink seamlessly drawn of #18 gauge, type 304
(18-8) nickel bearing stainless steel. Underside of sink is fully
protected by heavy duty Sound Guard

DESIGN FEATURES

Bowl Depth: 7".
Finish: Exposed surfaces are hand blended to a lustrous
highlighted satin finish. ELUH129 model has highlighted inside
top bowl radius.
Underside: Underside of sink is fully protected by heavy duty
Sound Guard undercoating to prevent condensation and
™
deaden sound.

OTHER

Drain Opening: 2".
Note: All Elkay custom design undermount sinks are designed
to affix easily to the underside of any solid surface countertop.
Installation: See illustrated profile below.

OPTIONAL ACCESSORIES

Cutting Board: CB912.

SINK DIMENSIONS (INCHES)*

Overall
Model
Number L W
ELU129 13 1 / 10 3 /
2 4
ELUH129 14 1 / 11 3 /
2 4
*
Length is left to right. Width is front to back.
**Template and countertop mounting clips are packed with every sink.
4-5/8"
6"
1-3/4 R
12"
13-1/2"
Model ELU129 Illustrated
The template provided with each ELU/ELUH sink provides the only type of installation recommended by Elkay.
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
1/8" Countertop
Overhang
1-3/8" + 1/4"
(ELU Single bowl)
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkay.com
®
undercoating.
™
Inside Bowl
Cutout in
L W D Countertop
12 9 1 / 7
4
See
Template**
12 9 1 / 7
4
10-3/4"
9-1/4"
1-3/4" R

Installation Profile of ELU and ELUH Single Bowl Models

COUNTERTOP
SILICONE CAULK
(NOT FURNISHED)
SINK
1/8 (APPROX.)
_
OVERHANG
2222 Camden Court
Oak Brook, IL 60523
Lustertone ® Undermount Single Bowl Sink
Models ELU129 and ELUH129
Minimum Ship.
Cabinet Wt.
Size Lbs.
18 7
18 7
7"
COUNTERTOP
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
(ELUH Single bowl)
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Model ELU129
4-5/8"
6"
1-3/4 R
12"
14-1/2"
Model ELUH129 Illustrated
CONTOUR EDGE
TO CUSTOMER DESIRE
1/2"
SILICONE
CAULK
(NOT
FURNISHED)
SINK
1-1/8"
Printed in U.S.A.
©2003 Elkay
(3/03)
11-3/4"
9-1/4"
1-179
