Elkay Lustertone ELU2118 Specifications

SPECIFICATIONS

GENERAL

Highest quality sink seamlessly drawn of #18 gauge, type 304
(18-8) nickel bearing stainless steel. Underside of sink is fully
protected by heavy duty Sound Guard
Designed to accept waste disposer.

DESIGN FEATURES

Bowl Depth: 7-1/2" (ELU[H]2118), 10" (ELU[H]211810).
Finish: Exposed surfaces are hand blended to a lustrous high-
lighted satin finish. ELUH models have highlighted inside top
bowl radius.
Underside: Underside of sink is fully protected by heavy duty
Sound Guard undercoating to prevent condensation and
®
deaden sound.

OTHER

Drain Opening: 3-1/2".
NOTE: All Elkay custom design undermount sinks are designed
to affix easily to the underside of any solid surface countertop.
Installation: See illustrated profile below.
These sinks comply with ANSI Standard A112.19.3M.

SINK DIMENSIONS (INCHES)*

Overall
Model
Number L W
ELU2118 22 / 20 /
1 1
2 8
ELU211810 22 1 / 20 1 /
2 8
ELUH2118 23 / 21 /
1 1
2 8
ELUH211810 23 1 / 21 1 /
2 8
*
Length is left to right. Width is front to back.
**Template and countertop mounting clips are packed with every sink.
20-1/8"
18-5/8"
21"
3/4" TYP.
(8 SIDES)
22-1/2"
Model ELU2118/10
The template provided with each ELU/ELUH sink provides the only type of installation recommended by Elkay.
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
1/8" Countertop
Overhang
(ELU Single bowl)
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
undercoating.
®
Inside Bowl
Cutout in
L W D Countertop
21 18 / 7 /
5 1
8 2
21 18 5 / 10
8
See
Template**
21 18 / 7 /
5 1
8 2
21 18 5 / 10
8
Installation Profile of ELU and ELUH Single Bowl Models
COUNTERTOP
SILICONE CAULK
(NOT FURNISHED)
SINK
1/8 (APPROX.)
1-3/8" + 1/4"
_
OVERHANG
2222 Camden Court
Oak Brook, IL 60523
Lustertone Undermount Single Bowl Sink
Model ELU2118 and ELUH2118 Series

OPTIONAL ACCESSORIES

Rinsing Baskets: LKRB1614, LKERBSS, VB1816 and DB1420.
Cutting Board: CBT2213.
Minimum Ship.
Cabinet Wt.
Size Lbs.
27 14
27 14
27 14
27 14
21-1/8"
7-1/2"
10"
1-1/4" TYP.
(8 SIDES)
COUNTERTOP
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
(ELUH Single bowl)
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Model ELU2118
Note: Drain not included.
Available as accessory item.
18-5/8"
21"
23-1/2"
Model ELUH2118/10
CONTOUR EDGE
TO CUSTOMER DESIRE
1/2"
SILICONE
CAULK
(NOT
FURNISHED)
SINK
1-1/8"
Printed in U.S.A.
©2003 Elkay
(Rev. 11/03)
1-111E
