Elkay Lustertone ELU1113 Specifications

Lustertone Undermount Single Bowl Sink
®
Models ELU1113 and ELUH1113

SPECIFICATIONS

GENERAL

Highest quality sink seamlessly drawn of #18 gauge, type 304
(18-8) nickel bearing stainless steel. Underside of sink is fully
protected by heavy duty Sound Guard
Designed to accept waste disposer.

DESIGN FEATURES

Bowl Depth: 5-15/16".
Finish: Exposed surfaces are hand blended to a lustrous
highlighted satin finish. ELUH1113 model has highlighted
inside top bowl radius.
Underside: Fully protected by heavy duty Sound Guard
undercoating to prevent condensation and deaden sound.

OTHER

Drain Opening: 3-1/2".
Note: All Elkay custom design undermount sinks are designed
to affix easily to the underside of any solid surface countertop.
Installation: See illustrated profile below.
Recommended Minimum Sink Base:

SINK DIMENSIONS (INCHES)*

Overall
Model
Number L W
ELU1113 13 / 14 /
1 3
4 4
ELUH1113 14 1 / 15 3 /
4 4
*
Length is left to right. Width is front to back.
**Template and countertop mounting clips are packed with every sink.
13-1/4"
14-3/4"
11-3/4"
13-1/4"
ELU1113 Illustrated
The template provided with each ELU/ELUH sink provides the only type of installation recommended by Elkay.
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
1/8" Countertop
Overhang
(ELU Single bowl)
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay Manufacturing Company
www.elkay.com
undercoating.
™
Inside Bowl
Cutout in
L W D Countertop
11 / 13 / 5 /
3 1 15
4 4 16
See
Template**
11 3 / 13 1 / 5 15 /
4 4 16
5-15/16"
3/4" TYP.
(8 SIDES)
Installation Profile of ELU and ELUH Single Bowl Models
COUNTERTOP
SILICONE CAULK
(NOT FURNISHED)
SINK
1/8 (APPROX.)
1-3/8" + 1/4"
_ OVERHANG
™
These sinks comply with ANSI Standard A112.19.3M.
These sinks are listed by the International Association
U P of Plumbing and Mechanical Officials as meeting the
C
requirements of the Uniform Plumbing Code.
Ship.
Wt.
Lbs.
7
7
15-3/4"
COUNTERTOP
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
(ELUH Single bowl)
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
2222 Camden Court
Oak Brook, IL 60523
Model ELU1113
13-1/4"
11-3/4"
14-1/4"
ELUH1113 Illustrated
CONTOUR EDGE
TO CUSTOMER DESIRE
1-1/8"
Printed in U.S.A.
©2001 Elkay Mfg. Co.
(Rev. 7/01)
®
1-1/4" TYP.
(8 SIDES)
1/2"
SILICONE
CAULK
(NOT
FURNISHED)
SINK
1-117C
