Various Settings

Making changes with Function Mode

A variety of settings can be changed.

Switching the Function Mode

Press the [CUSTOM/MENU] button
1
for more than one second.
The Menu Selection mode is activated.
Press the [SELECT] (Upper/Lower)
2
button to select the FUNC then
press the [ENTER] button.
The function mode is activated.
Press the [SELECT] (Upper/Lower)
3
button to select the setting item.
When the button is pressed, the
setting item changes in the following
order.
*1
↔ Title
AreaShot
↔ Guide Tone ↔ Clock ON/OFF ↔
Clock Adjust ↔ Demo ↔ HD RADIO
↔ AUX ON/OFF
↔ Steering SW Data ↔ SIRIUS ID
*7
↔ AVL Setting
XM ID
*1: Refer to page 41 for details on
Area shot operation.
*2: Cannot make settings other than
for tuner operation.
*3: Cannot make settings other than
for CD/CD changer operation.
*4: This setting can only be chosen
when an optional HD Radio tuner
unit is connected. (Refer to page
64 for details on HD Radio
operation.)
*5: Refer to page 76 for detail on AUX
operation.
*6: This setting can only be chosen
when an optional SIRIUS Satellite
radio tuner unit is connected.
(Refer to page 70 for details on
SIRIUS Satellite radio operation.)
56
*3 *2
↔Station Name
*4
*5 *5
↔ AUX Sensitivity
*6
↔
*8
*7: This setting can only be chosen
when an optional XM Satellite
radio tuner unit is connected.
(Refer to page 67 for details on XM
Satellite radio operation.)
*8: This setting can only be chosen
when an optional GPS unit is
connected.
Setting station name/disc title
(Station Name/Title)
The name of the station being received, or the
title of the CD being played can be set.
ATTENTION
• No CD text disc can be set.
• Setting cannot be performed when an
optional HD radio tuner unit is connected,
or during SIRIUS satellite radio reception.
Press the [SELECT] (Upper/Lower)
1
button to select the Station Name
or Title.
Station Name or Title will be selected
based on the current audio mode
settings.
2
Press the [ENTER] button.
The title setting mode is activated.
Press the [SCREEN] button to
3
select the character type.
Pressing the button will switch types
from [ABC]
characters)
characters) and then [!"#] (symbols).
(upper-case alphabet
to, [123] (numeric
