Introduction

Detaching the front panel

Using the detachable panel

The front panel of the main unit can be removed.
By removing this panel when you leave the
vehicle, you can prevent the theft of the main
unit.

How to remove the detachable panel

1
Press the [Release] button.
The right end of the front panel
detaches from the body of the main
unit.
2
Remove the front panel.
Hold the front panel and pull it toward
you to remove it.
3
Put the front panel into the case.
Push to open the front panel case and
put the front panel in it.
20

How to fit the detachable panel

Insert the left end of the front panel
1
into the main unit.
Engage the catch at the left end of the
front panel with the lock on the main
unit itself.
2
Insert the front panel.
Press the right end of the front panel
until it clicks into place.
CAUTION
• If you drop the detachable panel or
subject it to
damaged or malfunction.
• Do not detach or fit the detachable
panel while driving since this could
cause an accident.
• Store the panel at a location free from
humidity, dust, and water.
• Do not leave the detachable panel in
locations that are likely to become hot,
like the dashboard and surroundings.
impact, it may be
