AREA SHOT Screen Configuration

The following two functions can be displayed in the Area Shot mode.
Route Assist mode : Displays the guidance by setting starting point and destination.

Town Map mode :

Route Assist mode

• Guidance point map : Displays a map on which the guidance point is centered.
• Route map : Displays a map showing the route to the next guidance point.
Text information
Manually selection icons*
POI icons (guidance point map only)
Guidance point (intersection) enlarged map*
Turn list display : A list for the 3 guidance points ahead of present point can be displayed.
Distance
* Can be displayed only when GPS unit is connected.
Town Map mode
Specific area (town map) that user selected with E-iSERV can be displayed.
OVERALL VIEW : All over view of the area can be displayed.
When GPS reception is available:
Current position can be displayed.
CLOSE UP VIEW : Detail map for the area can be displayed.
The map is displayed with the scale.
Current position can be displayed only when GPS unit is connected.
Displays the surrounding of self-chosen area such as a sightseeing spot.
The route to the destination
Scale
Arrows
Route section icon
Manually selection icons*
How to operate the Area Shot function (U.S.A./CANADA only)
Guidance list
The reduction scale map of the
selected range can be displayed.
* If the GPS signal cannot be
Distance display
Current position*
Directional indicator
Arrows
received with the GPS unit
connected, the icon will be
displayed.
