Duerkopp Adler 580 Service Instructions Manual
  1. Manuals
  2. Brands
  3. Duerkopp Adler Manuals
  4. Sewing Machine
  5. 580
  6. Service instructions manual

Duerkopp Adler 580 Service Instructions Manual

Automatic double-chainstitch buttonholer, single-chainstitch automat for stitched eyelet
Hide thumbs Also See for 580:
Table of Contents

Advertisement

Quick Links

Doppelkettenstich Knopflochautomat,
Einfachkettenstich Schnürlochautomat
Automatic double-chainstitch buttonholer,
Single-chainstitch automat for stitched eyelet
Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld
Telefon + 49 (0) 5 21 / 9 25-00 • Telefax + 49 (0) 5 21 / 9 25 24 35 • www.duerkopp-adler.com
Ausgabe / Edition:
Änderungsindex
02/2008
Rev. index: 02.0
Bedienanleitung / Operating Instructions
Aufstellanleitung / Installation Instructions
Serviceanleitung /
Printed in Federal Republic of Germany
580
Service Instructions
Teile-Nr./Part.-No.:
0791 580001
1
2
3
