4 Blue Wire (14 AWG)

Connect the LIGHT BLUE wire to the ignition 1 wire of your vehicle. This

wire will measure +12V on the test meter in the "run" and "start" position, and

is off (ground) in the "lock/off" and "accessory" positions).

5. Green (14 AWG)

Connect the GREEN wire to the second IGN2 wire of your vehicle. This is a

wire that is hot in the "run" and sometimes "start".

6. White Wire (14 AWG)

Connect the WHITE wire to the accessory wire which is +12V in the "run" and

"accessory" position, but off (ground) in the "start" and "off" positions. This

wire will power the heater / air conditioner (in some cars).

This WHITE wire can also be used as the headlights wire if you do not need it

for the Accessory position -- or if you power the heater / air conditioner with

the GREEN IGN2 wire. Simply connect this WHITE wire to the low beam

connection of the headlights or to the parking lights. Do not use this wire for to

power both Accessory AND Headlights together unless you use 2 external re-

lays powered by this WHITE wire -- one for the headlights and the other for the

Accessories.

7. Yellow (14 AWG)

Connect the YELLOW wire to the starter wire. This wire is hot in the "start"

position only.

Note: Nissan vehicles have two starter wires. Connect both starter wires to the

YELLOW wire.

8. Control Switch

Plug the Control Switch into the AutoCommand on the side next to the push

buttons and led light. Mount the switch using a 1/2" drill bit.

Ignition 1

Ignition 2

Accessory / Lights

Starter

Plug-in Switch
