4) New GM PASSLOCK
vehicles.
In 1997 the Malibu/Cutlass and then in 1998 all truck platforms (Full size
Pickup, Suburban, S-10/Sonoma, Blazer/Jimmy, Tahoe/Yukon and Astro/Safari) came out
with this new Passlock II system.
Use the diagram above and the list below to interface to this new type system. Note that the
Yellow wire for the Passlock is a similar gauge wire to the Starter wire. Don't confuse these.
You must acquire a resistor value within 5% of the value of the resistor in the key. Additionally,
there is No BULB TEST wire on this system, so pin 87 is not used.
Substitute as follows:
Wire color above
'Black or Yellow'
'Black'
'Black/White or White'

Important Note:

Make sure that all drivers who will be operating the AutoCommand
aware of the safety precautions installed and their limitations. Stress the impor-
tance of switching the On/Off control switch to the "OFF" position (down) every
time the car is serviced. Show the user how the control switch must be turned off
and on again after pulling out the key before leaving the car.

limited lifetime consumer warranty

Directed Electronics, Inc. (hereinafter "Directed") promises to the original purchaser to
repair or replace with a comparable reconditioned Directed add-on remote start unit if
this Directed add-on remote start unit (hereinafter "Unit"), excluding without
limitation, any remote transmitters or associated accessories, proves defective in
materials or workmanship under normal use for the life of the vehicle which the Unit is
originally installed. During this period, so long as the Unit remained installed in the
original vehicle, Directed will at its option, repair or replace this Unit if it is proved
defective in workmanship or material PROVIDED the Unit is returned to Directed's
warranty department at One Viper Way, Vista, CA 92081, along with $20 postage and
handling fee, a bill of sale or other dated proof of purchase bearing the following
information: Date of purchase, name and location of the merchant who sold the Unit,
and product description. This warranty does not cover labor costs for the removal or
reinstallation of the Unit. This warranty is non-transferable and does not apply to any
Unit that has been modified or used in a manner contrary to its intended purpose, and
this warranty does not cover damage to any Unit caused by installation or removal of
the Unit. This warranty is void if the Unit has been damaged by accident or
unreasonable use, neglect, improper service or other causes not arising out of defects in
materials or workmanship. Directed makes no warranty against theft of a vehicle or its
contents.
1 8
II Anti-Theft System for 1998 model
®
Trucks
Yellow
Orange/Black
Red/White
Malibu / Clutlass
Yellow
Black
Red/White
are fully
®
© 2005 Directed Electronics, Inc.
