POWER & IGNITION WIRES
The AutoCommand
been completed. Do not mount the module at this time! You will need to check
the diagnostic light (LED) as the installation progresses. Locate (or drill) a
hole in the firewall to run the VIOLET (hood) and the GREEN (tach) wires of the
Control Harness and the PINK wire of the Power Harness through into the
engine compartment. The remaining short wires stay in the passenger area.
Leave about a foot of the wire harness under the dash for ease of working and
visual access to the diagnostic lights.
Note: Always connect the Black and Pink wires before connecting
any of the other wires.
2. Black Wire (14 AWG)
Connect this BLACK wire to a very good, clean chassis ground in the driver's
kick panel area. Use the small red ring terminal if needed. The metal bracing
around or beneath the dash board is not adequate.
3. Pink Wire (12 AWG)
Plug this wire onto the spade terminal marked Power. Run the other end
of this wire through the firewall of your vehicle and to the positive side
of the vehicle's battery terminal. Connect the ring terminal of the fuse
holder provided to the vehicle's positive battery post. Join the remaining
ends of the power wire together by soldering them. Alternatively, you
may wish to use a Yellow butt terminal, but we recommend soldering.
Ignition Key Diagram for Steps 4-7
The vehicle's wires are found coming off of the key switch.
Lock/Off
ACC
6
module will be installed under the dash once all wiring has
®
ACC
RUN
START
Ground
Power (+12V)
