21. Special Programming Options
The AutoCommand
to use these special options in most situations. The factory settings will oper-
ate most vehicles. You must turn the On/Off control switch to the "OFF"
position to program any features. Note that when turning off this control
switch, the red LED will flash a few times, giving the diagnostic code described
in Section 20. Wait a few seconds for it to finish before programming your new
Options.
# Factory Setting (2 flashes)
1 "No-Tach"
2 10 min. run time
3 Normal Crank
4 Normal Crank
5 Normal Voltage Metering
6 Gasoline vehicles
7 "Enable" feature
8 Normal Trigger
#1 sets the starting method. The factory setting uses "No-Tach" start-
ing. If you wish to use the tach to start, follow the instructions in 12A.
#2 is for the choice of run times.
#3 will add 50% more crank time to "No-Tach" starting.
#4 adds 100% more crank time. This is necessary on many deisel a n d
hard to start vehicles. Options #3 and #4 can be added together for
even more cranking time.
#5 is used in the "No-Tach" starting method for some diesel vehicles.
#6 option must be activated when installing on a diesel vehicle.
#7 cancels the Enable mode safety feature. The Enable mode requires
that the driver toggle the ON/OFF control switch "OFF" then "ON" in
order to "enable" the vehicle for AutoCommand
guards against undesired starting of the vehicle by remote control.
#8 Normal Trigger will start and stop the AutoCommand with a single
quick ground pulse to the Remote Input wire of Step 13. Double Pulse
Trigger mode will not activate the AutoCommand until it has seen two
pulses within 3 seconds time. Thus if you hook the Remote Input wire
up to the Door Lock wire of your keyless entry module -- you can lock
1 4
®
unit has 8 special options and features. You will not need
Option (1 flash)
Tach Mode
15 min. run time
Extended Crank
Super Crank
Ignore Voltage Metering
Diesel vehicles
No "Enable"
Double Pulse Trigger
control. This feature
®
