Fostex VF16 Supplement Owner's Manual page 3

Addition of Collective Track Select function
When selecting INPUT - TRACK (9 ~ 16), BUSS REC
SOURCE (1 ~ 16), DIRECT REC TRK (1 ~ 16) and
SAFE/READY status of input monitoring function,
all the objective tracks can be collectively selected
at once now.
• Collective Select of INPUT - TRACK
When selecting IN (INPUT) - TRK (TRACK) after
pressing the [INPUT SEL] key, pressing either one of
the [CH STATUS/CH SEL] 9 ~ 16 keys with holding
down the [SHIFT] key allows to select "IN (INPUT)" or
"TRK (TRACK)" all at once. Every time the key is
pressed, "IN" and "TRK" are alternatively selected.
< CAUTION >
If Collective Select is executed in the condition that there
are " IN (INPUT)" channels, all the channels are switched
to "TRACK". In the same manner, if Collective Select is
executed in the condition that one or some of the record
tracks (BUSS or DIRECT REC track) are in the READY
status, all the READY tracks are canceled.
VF-16 Owner's Manual V3.1 Supplement
• Collective Select of BUSS REC SOURCE
When selecting a source channel after pressing the
[BUSS SOURCE] key, pressing either one of the [CH
STATUS/CH SEL] 1 ~ 8 key with holding down the
[SHIFT] key allows to change all the channel 1 ~ 8
SOURCE and SAFE status alternatively. In the same
manner, pressing either one of the [CH STATUS/CH
SEL] 9 ~ 16 key with holding down the [SHIFT] key
allows to change all the channel 9 ~ 16 SOURCE and
SAFE status alternatively.
< CAUTION >
If some of the channels are selected as REC tracks,
Collective Select is not possible. If some of the channels
are selected as SOURCE tracks, all the channels (1 ~ 8,
9 ~ 16) will be in the SAFE status.
<Example>
Pressing either one of the 1 ~ 8 [CH STATUS/CH SEL] keys
with holding down the [SHIFT] key changes the SOURCE -
SAFE status alternatively.
<Example>
Pressing either one of the 9 ~ 16 [CH STATUS/CH SEL] keys
with holding down the [SHIFT] key changes the SOURCE -
SAFE status alternatively.
3
