Fostex VF16 Supplement Owner's Manual

Fostex VF16 Supplement Owner's Manual

V3.1 supplement
Hide thumbs Also See for VF16:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
8288 688 000
VF-16 Owner's Manual
< V3.1 Supplement >
This owner's manual supplement explains
about "added function" and "expanded
function" by updating the software to V3.1.
Read this supplementary manual together
with the main owner's manual to fully utilize
VF-16 with V3.1 software.

Advertisement

loading

Related Manuals for Fostex VF16

Summary of Contents for Fostex VF16

  • Page 1 8288 688 000 VF-16 Owner’s Manual < V3.1 Supplement > This owner’s manual supplement explains about “added function” and “expanded function” by updating the software to V3.1. Read this supplementary manual together with the main owner’s manual to fully utilize VF-16 with V3.1 software.
  • Page 2 VF-16 Owner's Manual V3.1 Supplement • Addition of Collective Track Select function (Refer to page 3 - 4.) When selecting IN (INPUT) - TRK (TRACK), BUSS REC SOURCE and DIRECT REC TRK or SAFE/READY status of input monitoring function, all of the objective tracks can be collectively selected at once now. •...
  • Page 3 VF-16 Owner's Manual V3.1 Supplement • Collective Select of BUSS REC SOURCE Addition of Collective Track Select function When selecting a source channel after pressing the When selecting INPUT - TRACK (9 ~ 16), BUSS REC [BUSS SOURCE] key, pressing either one of the [CH SOURCE (1 ~ 16), DIRECT REC TRK (1 ~ 16) and STATUS/CH SEL] 1 ~ 8 key with holding down the SAFE/READY status of input monitoring function,...
  • Page 4 VF-16 Owner's Manual V3.1 Supplement • Collective Select of DIRECT REC TRK • Collective Select of INPUT MONITORING When selecting a DIRECT REC TRACK after pressing In the condition that the normal display is displayed the [DIRECT REC TRK] key, pressing either one of the or in the DIRECT REC TRK selection on the screen, [CH STATUS/CH SEL] 1 ~ 8 key with holding down the pressing the [INPUT SEL] key with holding down the...
  • Page 5 VF-16 Owner's Manual V3.1 Supplement Addition of Channel SOLO function Expanded LOCATE Function The following LOCATE functions have been expanded In the VF-16 with the previous software version, if on the V3.1 software. you would like to monitor only a certain channel, all the other channels faders must be turned down.
  • Page 6 VF-16 Owner's Manual V3.1 Supplement Zoom Function on Digital Scrub Addition of Track Exchange pattern The zoom function on Digital Scrub has been An "Adjacent odd and even 2 tracks (stereo pair)" unit expanded on the V3.1 software and it is now possible Track Exchange pattern has been newly added.
  • Page 7 VF-16 Owner's Manual V3.1 Supplement Change on Event Map Tempo Map setting incorporating into BPM value Event Map display (pressing the [SCENE-STORE/MAP] On the V3.1 software, the programmed “tempo map” key with holding down the [SHIFT] key) and the setting in the SETUP menu can be incorporated into display when deleting the Event Map has been the BPM parameter value set in the effect type “L31”...
  • Page 8 VF-16 Owner's Manual V3.1 Supplement Change on Display contents when in Scene Recall/Store/Clear Change on turning ON/OFF of Fader Recall mode • Change 1 • Changing on display contents when in scene recall Recalling the scene when the “Fader Recall mode In the condition that there are SCENES stored, Setting”...
  • Page 9 VF-16 Owner's Manual V3.1 Supplement Addition of Pair Fader Setting in SETUP menu A newly added “Pair Fader Set” menu sets whether or not you simultaneously control the adjacent odd and even channels. Normally, each channel fader on VF-16 is designed to act independently. By turning ON the “Pair Fader Set”, you can pair faders of two adjacent channels, allowing the odd channel fader to control the partner (even) channel's level.
  • Page 10 Unlike the save/load using another type of SCSI devices such as zip, MO and DVD-RAM drives, preformatting a CD-R/RW disc by the DOS format (FAT-16) is not required. For external SCSI CD-R/RW drives that can be used with VF-16, access the Fostex Home Page (http:// www.fostex.co.jp/int/) or contact your local distributor.

  • Page 11: Saving A Wav File

    VF-16 Owner's Manual V3.1 Supplement Saving a WAV file In the following description, we assume that an operation-confirmed external SCSI CD-R/RW drive is connected to the VF-16 SCSI terminal and a blank CD-R/RW disc is set. Press the [SETUP] key. <...
  • Page 12 VF-16 Owner's Manual V3.1 Supplement <File name coversion example> <To Specify desired tracks by selecting "From ** To **"> On VF-16 On a computer By rotating the [JOG] dial while the left ("From") field is flashing, you can select the track number from 01 VF-16_##.wav Vf-16 through 24.

  • Page 13: Loading A Wav File

    VF-16 Owner's Manual V3.1 Supplement < About saved WAV files > • WAV file structure. 24 WAV files (one file per track) are created in the root directory of the CD-R/RW disc. The WAV file names are “******01.WAV” through “******24.WAV” where “******” indicates the file name input in step 8 and 2-digit numbers (01 ~ 24) indicates the corresponding track number.
  • Page 14 VF-16 Owner's Manual V3.1 Supplement Flashing When the screen shows “Title” and “Capacity (MB)”, it indicates that the WAV files to be loaded will overwrite the selected existing program on the VF-16 HD. When the screen shows “Title” and “New PGM”, it indicates that the WAV files will be loaded into a newly created program on the VF-16 HD.
  • Page 15 VF-16 Owner's Manual V3.1 Supplement Expanded functions on making an audio CD On “Making an audio CD”, the message to complete the SAVE operation (“Save Completed!”) has been changed as shown below. It is now possible to select either “Continue” or “Exit” when the save operation is completed. If “Continue”...
  • Page 16 FOSTEX CORPORATION 3-2-35, Musashino, Akishima-shi, Tokyo, Japan 196-0021 FOSTEX AMERICA 15431, Blackburn Avenue, Norwalk, CA 90650, U.S.A. © PRINTED IN JAPAN MAR. 2002 8288 688 000 FX.
