VF-16 QUICK START – DIRECT METHOD RECORDING
With this method, the 8 mic/line inputs at the top of the VF16 feed tracks 1 – 8 respectively. These inputs
can also be set to feed tracks 9 – 16 (described later).
PRIOR TO RECORD:
Since Program 1 (PGM-1) is a record-protected demo, you must first exit PGM-1 prior to recording and
disable record protect.
1. Press the
PGM SEL
2. Using the
JOG
3. Press the
ENTER
ENTER
4. Using the
JOG
for display to read "OFF". Press
At the top of the VF16 there are 8 mic/line mixer inputs:
The audio levels for these mixer inputs are controlled using the bottom row of channel faders also labeled
A, B, C, D, E, F, G, and H. These faders are always used to set your record levels.
TO START RECORDING
For the following example let's record on Track 1. Using Input A.
1. Connect your audio signal to Input A (labeled "1/9/A") at the top of the VF16
2. Press
REC TRK (direct)
3. Press the
CH SEL #1
a. Display now reads " RDY" underneath 1
b. Press
4. Press the
RECORD
5. Adjust your record level using FADER A (Bottom Row #9)
button
wheel, turn until display reads "NEW PGM?"
button *Note: From here you can name your program and press
....or.... to skip simply press
wheel, turn until display reads "REC PROTECT". Press
button (above FADER#1).
EXIT
button only. It should now be blinking
EXIT.
ENTER.
Press
EXIT.
A, B, C, D, E, F, G, and H
ENTER.
Turn
JOG
