Fostex VF16 Supplement Owner's Manual page 2

VF-16 Owner's Manual V3.1 Supplement
• Addition of Collective Track Select function (Refer to page 3 - 4.)
When selecting IN (INPUT) - TRK (TRACK), BUSS REC SOURCE and DIRECT REC TRK or SAFE/READY
status of input monitoring function, all of the objective tracks can be collectively selected at once now.
• Addition of Channel SOLO Function (Refer to page 5.)
With a simple key operation, turning ON/OFF of SOLO function on a desired channel is now possible.
• Expanded Locate function (Refer to page 5)
1. Designating the event number allows to locate directly.
2. Locating to a last REC START POINT is now possible instantly.
3. A faster locating using [F FWD/NEXT] / [REWIND/PREV] key is now possible.
• Expanded Zoom function on Digital Scrub (Refer to page 6)
Enlarging the waveform by the zoom function in 5 scales allows to improve locate accuracy.
• Addition of Track Exchange pattern (Refer to page 6)
In addition to the "8 track" unit and "mono (1) track" unit, exchanging "2 track (stereo pair)" unit is
now possible.
• Expanded function that the tempo map setting is incorporated into BPM value of BPM DELAY (Refer
to page 7)
Incorporating the tempo map setting into the BPM parameter setting (Effect Type: L31 / L32) in the
internal DSP Multi Effect is now possible. With this function, there is no need to use a scene to change
the BPM value. Thus, varying the BPM value in accordance with previously set tempo map when in
PLAY mode.
• Expanded Scene Event Map function (Refer to page 7)
1. Even in the Event Map window, VF-16 current location can be now recognized.
2. The cursor position when displaying the Event Map window is changed.
3. In order to prevent from operation mistake, an "ALERT" is now displayed when deleting an event.
• Change on Display contents when in Scene Recall/Store/Clear (Refer to page 8)
1. When Scenes are displayed by the list, the scene currently recalled is easily recognized now.
2. Even when in PLAY mode, entering into Scene Store mode is now possible.
3. In or der to prevent from operation mistake, an "ALERT" is now displayed when a scene is cleared.
• Change on turning ON/OFF of Fader Recall mode (Refer to page 8)
1. When a scene is recalled with "Fader Recall mode" setting in the SETUP mode to ON, FADER ADJUST
LED will not flash anymore.
2. In the condition that "Fader Recall mode" is set to OFF, Level Adjust function can be activated now.
• Addition of "Pair Fader Setting" SETUP mode (Refer to page 9)
Manipulating an odd channel fader allows to control the adjacent channel fader level now.
• Addition of WAV file Export/Import function using a SCSI external CD-RW/CD-R drive (Refer to page
10 - 14)
In addition to the operation-confirmed drives up to now (e.g. MO, zip), exporting/importing a WAV file
to/from a SCSI external CD-RW/CD-R drive/disk is now possible.
• Expanded function on creating an Audio CD (Refer to page 15)
Creating a multiple audio CDs with same contents consecutively is now possible.
2
