Canon CANOSCAN D1230 series Service Manual page 96

FIGURE
& PART NUMBER
KEY NO.
100-01 NIA-YFSC-290
02 NIS-F300-872
03 NIP-N339-000
04 NIP-N226-900
05 NIA-YFSC-224
06 NIS-M300-882
07 NIA-YFSC-317
08 NIM-L103-700
09 NIB-LHTS-F18
10 NIM-U102-300
11 NIA-YFSC-223
12 NIS-X000-700
13 NIA-YFSC-268
14 NIP-N502-100
15 NIP-N400-300
16 NIA-YFSC-236
17 NIA-YFSC-316
18 NIP-S200-100
19 NIR-C201-200
20 NPN
21 NPN
COPYRIGHT © 2001 CANON INC.
R Q'
A
T
N
K
Y
1 DOCUMENT COVER ASSEMBLY
8 SCREW, M3X8, SELF-TAPPING
1 LOCK, CARRIAGE
1
COVER, TOP
1
PLATEN GLASS ASSEMBLY
3 SCREW, M3X8, BH
1 PLATE, GEAR 2
1 SPRING
1 BELT, DRIVE, RUBBER
1 SLIDING ROD
1 MOTOR ASSEMBLY
1 SCREW, M3X8, SELF-TAPPING
1 BUTTON PCB ASSEMBLY
1 BUTTON, FUNCTION
4
CLAMP, CABLE
1
CARRIAGE ASSEMBLY
1 MAIN PCB ASSEMBLY
1 COVER, CABLE
4 FOOT, RUBBER
1 FRAME, MAIN
1 CORE, FERRITE
CANOSCAN D1230U/D2400U REV.0 MARCH 2001 PRINTED IN JAPAN (IMPRIME AU JAPON)
DESCRIPTION SERIAL NUMBER/REMARKS
6 - 5
