Billion BIPAC 7100SV User Manual

Voip adsl modem/router with single ethernet port
Hide thumbs Also See for BIPAC 7100SV:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
BIPAC 7100SV
VoIP ADSL Modem/Router
with Single Ethernet Port
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIPAC 7100SV and is the answer not in the manual?

Questions and answers

Related Manuals for Billion BIPAC 7100SV

Summary of Contents for Billion BIPAC 7100SV

  • Page 1 BIPAC 7100SV VoIP ADSL Modem/Router with Single Ethernet Port User Manual...

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 ................1 NTRODUCTION ..................1 1.1 An Overview of BIPAC 7100SV ..................1 1.2 Package Contents .......................2 1.3 BIPAC 7100SV Features.....................2 1.4 BIPAC 7100SV Application ..................4 Chapter 2 ................5 IP ADSL M SING ILLION ODEM OUTER ......
  • Page 4 Billion BIPAC 7100SV VoIP ADSL Router 3.4.3.3.6 Ring Tone....................36 3.4.3.3.7 Timer ......................38 3.4.3.4 System ........................... 39 3.4.3.4.1 Password....................39 3.4.3.4.2 Time Zone ....................40 3.4.3.4.3 Upgrade....................41 3.4.3.4.4 Factory Setting ..................42 3.4.3.4.5 Restart....................42 3.4.3.5 Firewall ........................... 43 3.4.3.5.1 Packet Filtering..................43 3.4.3.5.2 Bridge Filtering ..................45 3.4.3.5.3 Intrusion Detection..................46 3.4.3.5.4 Block WAN Request ................47 3.4.3.6 Virtual Server.........................

  • Page 5: Chapter 1

    Chapter 1 Introduction 1.1 An Overview of BIPAC 7100SV BIPAC 7100SV VoIP ADSL Modem/Router provides a high-speed Ethernet port for high-speed Internet browsing. It can support downstream transmission rates of up to 8Mbps and upstream transmission rates of up to 1024Kbps. It is compliant with Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1); G.lite (G992.2);...

  • Page 6: Package Contents

    Billion BIPAC 7100SV VoIP ADSL Router between the PSTN world and the IP world acting as a residential gateway, eventually providing Internet Telephony capability. Cost savings and ease of developing and integrating new services motivate most of the interest in Internet telephony. Internet telephony integrates a variety of services provided by the current Internet and the PSTN infrastructure.
  • Page 7 Chapter 1 Introduction Dynamic Domain Name System (DDNS): The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname. This dynamic IP address is the WAN IP address. For example, to use the service, you must first apply an account from this free Web server http://www.dyndns.org/. There are more than 5 DDNS servers supported.

  • Page 8: Bipac 7100Sv Application

    Billion BIPAC 7100SV VoIP ADSL Router 1.4 BIPAC 7100SV Application...

  • Page 9: Chapter 2

    Chapter 2 Using Billion VoIP ADSL Modem/Router 2.1 Cautions for Using Billion VoIP ADSL Modem/Router Do not place the router under high humidity and high temperature. Do not use the same power source for the device with other equipment. Do not open or repair the case yourself. If the device is too hot, turn off the power immediately and have a qualified serviceman repair it.

  • Page 10: The Rear Ports

    Billion BIPAC 7100SV VoIP ADSL Router 2.3 The Rear Ports Meaning Power Switch A Power ON/OFF switch Connect the supplied power adapter to this jack. Power Jack Reset Press it to restore the factory default setting back. Connect RJ-11 cable to this port when connecting to an analog phone VoIP set.

  • Page 11: Chapter 3

    Chapter 3 Configuration BIPAC 7100SV can be configured with your Web browser. The web browser is included as a standard application in following operation systems, UNIX, Linux, Mac OS, Windows 95/98/NT/2000/Me/XP, etc. The product provides a very easy and user-friendly interface for configuration. 3.1 Before Configuration This section describes the configuration required by LAN-attached PCs that communicate with BIPAC 7100SV, either to configure the device, or for network access.
  • Page 12 Billion BIPAC 7100SV VoIP ADSL Router 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 13: Configuring Pc In Windows

    Chapter 3 Configuration 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Configuring PC in Windows 2000 1. Go to Start / Settings / Control Panel.
  • Page 14 Billion BIPAC 7100SV VoIP ADSL Router 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.
  • Page 15 Chapter 3 Configuration 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Configuring PC in Windows 95/98/ME 1. Go to Start / Settings / Control Panel.
  • Page 16 Billion BIPAC 7100SV VoIP ADSL Router 4. Select the IP Address tab. In this page, click the Obtain an IP address automatically radio button. 5. Then select the DNS Configuration tab. 6. Select the Disable DNS radio button and click OK to finish the configuration.
  • Page 17 Chapter 3 Configuration Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double- click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties.

  • Page 18: Factory Default Settings

    Billion BIPAC 7100SV VoIP ADSL Router 3. Select the Obtain an IP address from a DHCP server radio button and click OK. 3.2 Factory Default Settings Before you configure this device, you need to know the following default settings. 1. Web Configuration Password: There are two levels of password protection, Administrator Level and User Level.

  • Page 19: Password

    Chapter 3 Configuration 3.2.1 Password The default username and password are admin and password respectively. If you ever forget the password to log in, you may press the RESET button up to 2 seconds to restore the factory default settings. 3.2.2 LAN and WAN Port Addresses The parameters of LAN and WAN ports are pre-set in the factory.

  • Page 20: Configuring With Web Browser

    Billion BIPAC 7100SV VoIP ADSL Router VPI/VCI, VC-based/LLC-based multiplexing, IP address, Subnet mask, IPoA Gateway address, and Domain Name System (DNS) IP address (it is fixed IP address). 3.4 Configuring with Web Browser The ADSL Modem/Router can be configured with your Web browser. The web browser is included as a standard application following...

  • Page 21: Status

    Chapter 3 Configuration At the configuration homepage, the left navigation pane where bookmarks are provided links you directly to the desired setup page, including: Status (ADSL Status, LAN Status, PPP Status, Learned MAC Table, Routing Table, System Log, Security Log) Quick Start Configuration (WAN, LAN, VoIP, System, Firewall, Virtual Server, Advanced) 3.4.1 Status...

  • Page 22: Status - Adsl Status

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.1.1 Status – ADSL Status Displays the status of your ADSL connection. It will refresh every two seconds.

  • Page 23: Adsl Status - Wan Status

    Chapter 3 Configuration 3.4.1.1.1 ADSL Status – WAN Status 3.4.1.1.2 ADSL Status – ATM Status...

  • Page 24: Status - Lan Status

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.1.2 Status – LAN Status Displays the status of your Local Area Network (LAN) connection.

  • Page 25: Lan Status - Tcp Status

    Chapter 3 Configuration 3.4.1.2.1 LAN Status – TCP Status 3.4.1.3 Status- PPP Status Displays the status of your PPP connection. It will refresh every ten seconds.

  • Page 26: Status- Learned Mac Table

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.1.4 Status- Learned MAC Table Aging Timeout: Enter the time period for the router to memorize MAC addresses. 3.4.1.5 Routing Table Display the current routing paths of BIPAC 7100SV.

  • Page 27: System Log

    Chapter 3 Configuration 3.4.1.6 System Log Display the system logs cumulated till the present time. You can trace the historical information through this function.

  • Page 28: Security Logs

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.1.7 Security Logs Display the information of security logs. If hacker attacks your sever, he will be isolated by the firewall function and the router will record related information. Hence, you know where the hacker comes from. 3.4.2 Quick Start If you use this device to access the Internet through the ISP, this web page is enough for you to configure this router to access the Internet and enable VoIP service without a problem.

  • Page 29: Voip Quick Start

    Chapter 3 Configuration 3.4.2.2 VoIP Quick Start If you have a VoIP SIP account, you may configure it to enable this service. Please refer to the sections (VoIP configuration) below for more information.

  • Page 30: Configuration

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.3 Configuration When you click this item, you get following sub-items to configure BIPAC 7100SV. LAN, WAN, Firewall, System, VPN, Virtual Server, Advanced and Help 3.4.3.1 WAN The screens below contain settings for the WAN interface toward Internet. Select Adapter Select the item of PVCs you want to configure.
  • Page 31 Chapter 3 Configuration Virtual Circuit Virtual Circuit: Enable/Disable the settings of this VC. Bridge: If you set this device to be bridge mode, select Enable; if not, please select Disable. IGMP: You can Enable or Disable this function.
  • Page 32 Billion BIPAC 7100SV VoIP ADSL Router Encapsulation: There are eleven ways ─ PPPoE VC-Mux, PPPoE LLC, PPPoE None, PPPoA VC-Mux, PPPoA LLC, 1483 Bridged IP VC-Mux, 1483 Bridged IP LLC, 1483 Routed IP VC-Mux, 1483 Routed IP LLC, Classical IP over ATM, Native ATM ─ for the device to have a public IP address and then to access Internet.

  • Page 33: Lan

    Chapter 3 Configuration MTU: Maximum Transmission Unit indicates the network stack of any packet is larger than this value will be fragmented before the transmission. During the PPP negotiation, the peer of the PPP connection will indicate its MRU and will be accepted. The actual MTU of the PPP connection will be set to the smaller one of MTU and the peer’s MRU.

  • Page 34: Voip

    Billion BIPAC 7100SV VoIP ADSL Router DHCP Server: Check DHCP Server to enable the router to distribute IP Addresses, subnet mask and DNS setting to computers. Hence, the following fields will be activated. If you do not check this selection, remember to specify a static IP address, subnet Mask, and DNS setting for each of your local computers.

  • Page 35: Configuration

    Chapter 3 Configuration 3.4.3.3.1 Configuration This screen contains settings for configuring VoIP SIP module. SIP: Enable/Disable to use SIP as VoIP call signaling protocol. SIP Registration: Enable/Disable to register a SIP account in the SIP server (refer Service Provider section below) or not. LocalSIPPort: Enter the local SIP port which device listens incoming request.

  • Page 36: Service Provider

    Billion BIPAC 7100SV VoIP ADSL Router G.729A: Set the priority of voice compression to be used in the voice codec. Please be noted. Then codec priority is selected using a drop-down box. If two codec type are assigned the same priority, then the priority is assigned in the order as G.711U > G.711A > G.729A in the decreasing order or priority.

  • Page 37: Phone Book

    Chapter 3 Configuration OutbondProxyPort: specify the port of the SIP outbound proxy on which it will listen for messages. 3.4.3.3.3 Phone Book This screen contains settings for creating phone book for speed dial. You can dial the “#0” to inform VoIP device to dial the VoIP number in the entry 0 of phone book.

  • Page 38: Dial Plan

    Billion BIPAC 7100SV VoIP ADSL Router If your friend Felix gives you a SIP URL as sip:felix@iptel.org then you can enter the Phone book as: Remote UserID: felix IP Address / Domain: iptel.org If your friend Greg gives you an IP address "192.246.56.56" only, then you can enter the Phone book as: Remote UserID: (leave blank, don't fill anything) IP Address / Domain: 192.246.56.56 3.4.3.3.4 Dial Plan...
  • Page 39 Chapter 3 Configuration CallForwarding: Check CallForwarding Unconditionally: VoIP device will forward all incoming call to the forwarding number. Check CallForwarding On Busy: VoIP device will forward all incoming call to the forwarding number when user is already on the phone talking to someone. Check CallForwarding On No Answer: VoIP device will forward all incoming call to the forwarding number when user is unavailable to pick up the phone.

  • Page 40: Ptm

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.3.3.6 PTM 3.4.3.3.6 Ring Tone This screen contains settings for creating different ring tone patterns.
  • Page 41 Chapter 3 Configuration Working Country: This selection is a drop-down box, which allows user to select the country for which the VoIP device must work. When a country is selected, the country parameters are automatically displayed. Current supported countries are USA and UK. New country can be added and defined by user New Country: a text-field where you can enter the new country to add or modify some existing string.

  • Page 42: Timer

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.3.3.7 Timer This screen contains settings for timers (all are given in seconds) in system level. RedialTimer: indicate the time period through which the dial tone is heard once the phone is lifted off the hook.

  • Page 43: System

    Chapter 3 Configuration 3.4.3.4 System There are five items under the System section: Password, Time Zone, Upgrade, Factory Setting and Restart. 3.4.3.4.1 Password In factory setting, the default password is password, and that for user is also password. You can change the default password to ensure that someone cannot adjust your settings without your permission.

  • Page 44: Time Zone

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.3.4.2 Time Zone BIPAC 7100SV does not have a real time clock on board; instead, it uses the simple network time protocol (SNTP) to get the current time from the SNTP server in outside network. Please choose your local time zone and click Submit.

  • Page 45: Upgrade

    Chapter 3 Configuration Automatically adjust clock for daylight saving changes: It is optional for different time zone area. SNTP Server IP Address: Specify the IP address if you want to use your familiar SNTP server. 3.4.3.4.3 Upgrade...

  • Page 46: Factory Setting

    Billion BIPAC 7100SV VoIP ADSL Router To upgrade the firmware of BIPAC 7100SV, you should download or copy the firmware to your local environment first. Press the “Browse…” button to specify the path of the firmware file. Then, click “Upgrade” to start upgrading. When the procedure is completed, BIPAC 7100SV will reset automatically to make the new firmware work.

  • Page 47: Firewall

    Chapter 3 Configuration 3.4.3.5 Firewall User can decide to enable this firewall function including Packet Filter, Block Hacker Attack, and Block WAN request features for better security control or not. But be noted, it wastes network processor computation power. The performance will be lower about 10% to 15%. More firewall features will be added continually, please visit our web site to download latest firmware.
  • Page 48 Billion BIPAC 7100SV VoIP ADSL Router Add: Click this button to add a new packet filter rule. After click, next figure will appear. Edit: Check the Rule No. you want to edit. Then, click the “Edit” button. Delete: Check the Rule No. you want to delete. Then, click the “Delete” button. Outgoing Incoming: Determine whether the rule is for outgoing packets or for incoming packets.

  • Page 49: Bridge Filtering

    Chapter 3 Configuration Active: Choose “Yes” to enable the rule, or choose “No” to disable the rule. Packet Type: Specify the packet type (TCP, UDP, ICMP or any) that the rule will be applied to. Select TCP if you want to scope for the connection-based application service on the remote server using the port number.

  • Page 50: Intrusion Detection

    Billion BIPAC 7100SV VoIP ADSL Router Enable Bridge Filtering: Check Yes to enable this function or check No to disable. Src MAC: Enter the source MAC address. Dest MAC: Enter the destination MAC address. Type: Enter the Ethernet type. Block Forward: Check Block if you want to block requests from the source MAC address sending to the destination MAC address.

  • Page 51: Block Wan Request

    Chapter 3 Configuration 3.4.3.5.4 Block WAN Request Check “Enable” if you want to exclude outside PING request from reaching on this router.

  • Page 52: Virtual Server

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.3.6 Virtual Server Being a natural Internet firewall, the ADSL Router protects your network from being accessed by outside users. When it needs to allow outside users to access internal servers, e.g. Web server, FTP server, E- mail server or News server, this product can act as a virtual server.

  • Page 53: Advanced

    Chapter 3 Configuration Public Port (from) & Port (To): Enter the public port number & range you want to configure. Port Type: Select TCP if you want to scope for the connection-based application service on the remote server using the port number. Or select UDP if you want to scope for the connectionless application service on the remote server using the port number.

  • Page 54: Dns

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.3.7.2 DNS A Domain Name System (DNS) contains a mapping table for domain name and IP address. In the Internet, every host has a unique and friendly name such as www.yahoo.com and IP address. The IP address is so hard to remember that you may just enter the friendly name www.yahoo.com and then the...

  • Page 55: Dynamic Dns

    Chapter 3 Configuration 3.4.3.7.3 Dynamic DNS With Dynamic DNS service, a domain name can be translated into a dynamic IP address, which is often issued by ISP for dial-up service. A local server, such as Web server, Email server or FTP server, can then be easily accessed without knowing the changing IP address.

  • Page 56: Nat

    Billion BIPAC 7100SV VoIP ADSL Router Check the “Enable” button to access the Dynamic DNS service. You may sign up Dynamic DNS service http://www.dyndns.org and there you can also register domain names. Host: Enter one domain name you have registered. User Name: Enter the username used for sign-up.
  • Page 57 Chapter 3 Configuration associated with one WAN interface. Click the Session Name Configuration to add the session name for WAN interface. Session Name: Enter the desired session name. User’s IP: Allows the user to assign the IP address to map the corresponding NAT/NAPT sessions. Session Name status will be displayed at the middle of this page to show the corresponding Session Name with its IP address.

  • Page 58: Rip

    Billion BIPAC 7100SV VoIP ADSL Router 3.4.3.7.5 RIP RIP: Default is Disabled. Border Gateway: Default is Enabled. Supply Interval seconds: The default value is 30 seconds. Expire Timeout seconds: The default value is 180 seconds. Garbage Timeout seconds: The default value is 120 seconds.

  • Page 59: Static Route

    Chapter 3 Configuration 3.4.3.7.6 Static Route If you have another router with a LAN-to-LAN connection, you may create a static routing on the router that is the gateway to Internet.

  • Page 60: Misc Configuration

    Billion BIPAC 7100SV VoIP ADSL Router Add: Click this button to add a new static routing. When you click this button, the next figure appears. Delete: Check the item you want to delete. Then, click the “Delete” button. Destination / Subnet Mask / Gateway Address: Fill in these fields required by this Static Routing function.

  • Page 61: Diagnostic Test

    Chapter 3 Configuration PPP Half Bridge: Default at Disabled. PPP reconnect on WAN access: Default at Disabled. Select Enabled if you want to automatically re- establish the PPPoE/PPPoA session when disconnected by ISP. 3.4.3.7.8 Diagnostic Test As soon as you enter the test program, all tests will run automatically to diagnose the connection status of the device.
  • Page 62 Billion BIPAC 7100SV VoIP ADSL Router If this test returns FAIL, all other tests will be skipped. Checking Circuit 0 for Network Connection Test ATM OAM Segment Loop Back This test sends ATM OAM F5 Segment loop back request cells to the central office equipments through your DSL connection.
  • Page 63 Chapter 3 Configuration If this test returns FAIL, run this test again a few minutes after this test is completed. If this test returns FAIL consistently and your DSL modem seems not working, check to make sure your statically assigned IP address is configured correctly or DHCP client is turned on with the current VC.

  • Page 64: Save Config

    3.4.4 Save Config Click the Submit button to write settings to flash. Then, the system will reboot for changes to take effect.

  • Page 65: Chapter 4

    Chapter 4 Troubleshooting If the ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider. This could save your time and effort but if the symptoms persist, then consult your service provider. Problems Starting Up the ADSL Router Problem Corrective Action...

  • Page 66: Appendix
