48 LEDs and DIP switches
About LEDs
Table D-1
Location Symbol
6

Interpreting the LEDs

The LEDs on the front panel of the appliance have three states: solid on, flashing, and solid off. The
combination of the Error and Transmit LED states indicate the status of the appliance.
the LED state combinations and appliance status that they indicate.
Table D-2
Error LED state
Solid off
Solid off
Flashing
Flashing
Solid on
Flashing once
Flashing twice
Flash three
Solid on
Solid on
Solid on
Solid off
Both flashing alternately.

LiveUpdate LED status

Automatic firmware updates using LiveUpdate have a special set of LED sequences.
LED activity before, during, and after a LiveUpdate firmware update.
Table D-3
LiveUpdate status
During retrieval of LiveUpdate firmware from the Internet (or TFTP)
there is no effect on appliance operation. LEDs are in a normal
operational pattern.
Firmware downloaded and CRC verified. Flash erase begins (about 10
seconds).
LEDs (Continued)
Feature Description
Wireless- Illuminates or flashes when the wireless card is transmitting or
active receiving data.
LED states and appliance status
Transmit LED state
Solid on
Flashing
Flashing
Solid on
Solid on
Solid off
Solid off
Solid off
Flashing once
Flashing twice
Flashing three
Solid off
LED states for LiveUpdate status
Appliance status
Normal operation.
Transmitting/receiving Data from LAN.
MAC address not assigned.
Firmware problem. Appliance is ready for a forced
download.
Appliance detected an error and cannot recover.
Configuration mode.
Hardware problem.
RAM error.
Timer error.
DMA error.
LAN error.
WAN error.
Serial error.
No power.
Download in progress.
Appliance is writing to flash.
Power LED
(1) state
On
On
Table D-2 describes
Table D-3 describes the
Error LED Transmit
(2) state LED (3)
state
On On (flashing
for traffic)
On On
