12 Installing the Symantec Gateway Security 400 Series

Installing the appliance

Installing the appliance
This section describes the installation of the Symantec Gateway Security 400 Series models 420, 440, 460,
and 460R, including:

Back panel connectors and controls

Figure 2-1
and 460R. The numbers in both figures correspond to
Figure 2-1
Figure 2-2
Table 2-1
Table 2-1
Location
1
2
3
Back panel connectors and controls
Connecting the appliance
Powering the appliance
shows the back panel of models 420 and 440 and
Models 420 and 440 back panel
Models 460 and 460R back panel
describes the connectors, controls, and icons on the back panel of all the models.
Symantec Gateway Security 400 Series back panel controls
Icon Feature
Restart
LAN ports
WAN port
Figure 2-2
Table 2-1.
Description
When you press this button, current connections and all client VPN
tunnels are lost, all Gateway-to-Gateway VPN tunnels that were previously
connected re-establish after the appliance restarts, and the initial
hardware self-test is run.
This button is recessed. Press it gently and quickly with a paper clip.
Models 420 and 440 have four Ethernet ports and models 460 and 460R
have eight Ethernet ports to which you connect RJ-45 connectors from the
nodes that the appliance protects.
Models 420 and 440 have one Ethernet port and models 460 and 460R have
two Ethernet ports to which you connect RJ-45 connectors from an outside
network (such as an intranet) or the Internet.
shows the back panel of models 460
