44 Specifications and safety

Safeguard instructions

Table C-1
Parameter
AC power
Operating shock and
vibration
Non-operating shock
and vibration
Safeguard instructions
For your protection, please read all of these instructions regarding your appliance.
Product specifications (Continued)
Model 420 and 440
North American power supply unit
Line voltage range: 100 V to 120 V AC
Current: 1.1 Amps (at 115 V)
Frequency: 59 - 61 Hz, single phase
Power: 10 W
The multi-national power supply unit includes
four removable wall-plug clips to support the
following geographies: USA, Europe, UK and
Australia.
Line voltage range: 110 V to 253 V AC
Current: 0.55 Amps (at 230 V)
Frequency: 49.5 - 50.5 Hz, single phase
Power: 10 W
Shock: 250 G, < 2 ms
Vibration: 0.41 Grms2 (3-500 Hz) random
input
Shock: 65 G, 8 ms
Vibration: 1.12 Grms2 (3-500 Hz) random
input
Read instructions
Read and understand all of the safety and operating instructions before operating the appliance.
Ventilation
Vents at the front edge of the bottom panel and the back edge of the top panel of the Symantec Gateway
Security 400 Series provide ventilation for reliable product operation and to protect it from
overheating. These openings must not be blocked or covered. This product should not be placed in an
enclosure unless proper ventilation is provided.
Power cord
Caution: The power-supply cord is used as the main disconnect device. Ensure that the socket outlet is
located or installed near the equipment and is easily accessible.
Note: On the left side and bottom of the appliance is a seal with the Symantec logo, certification logos,
country where the unit was manufactured, the MAC address of the LAN card, and a unique bar-coded
serial number. Breaking this seal or opening the appliance in any way voids your warranty.
Warning: To prevent a possible electrical shock, when adding the device to a system, disconnect all
power cords, if possible, from the existing system before connecting the signal cable to that device.
Warning: To prevent a possible electrical shock during an electrical storm, do not connect or
disconnect cables.
Model 460 and 460R
North American power supply unit
Line voltage range: 100 V to 120 V AC
Current: 1.1 Amps (at 115 V)
Frequency: 59 - 61 Hz, single phase
Power: 10 W
The multi-national power supply unit includes
four removable wall-plug clips to support the
following geographies: USA, Europe, UK and
Australia.
Line voltage range: 110 V to 253 V AC
Current: 0.55 Amps (at 230 V)
Frequency: 49.5 - 50.5 Hz, single phase
Power: 10 W
Shock: 250 G, < 2 ms
Vibration: 0.41 Grms2 (3-500 Hz) random
input
Shock: 65 G, 8 ms
Vibration: 1.12 Grms2 (3-500 Hz) random
input
