Blank
Switches off the video signal and displays a black page. As
soon as the key is pressed an OSD indication lasting a few se-
conds confirms that the function has been activated. Pressing
any further keys on the remote control restores the previous
conditions.
Color Temperature
Clicking the key in question again (F1 / F2) enables you to set
the colour temperature from HIGH, MEDIUM, LOW, NATIVE and USER.
gamma Correction
Successive pressing of the key in question (F1 or F2) makes it
possible to select from among the available gamma curves.
SOURCE iNfORMATiON
When active (YES) each time the source is changed informa-
tion is displayed relative to the signal type. If inactive, (NO) no
information about the source is displayed.
OSD BACKgROUND
Determines the type of background for the On Screen Display
(opaque transparent).
OSD TiMEOUT
Determines the On Screen Display timeout. The adjustment is
made using the ◀ (decrease) and ▶ (increase) keys within a
6-200 second timeframe.
OSD POSiTiON
Allows the On Screen Display to be positioned in a particular
area of the projected image. The OSD can be positioned using
the arrow keys for fine adjustments or keys 1...9 on the remote
control to select one of 9 preset positions.
MEMORiES
The main picture parameters can be saved in discrete sets
of values called "Memories" so that they can be subsequently
applied as a group using a single command.
There are 6 distinct Memories (Memory 1, Memory 2, Memory
3) for each of the 8 signal types managed:
1 VIDEO
2 S-VIDEO
3 COMP/RGB (YPrPb 15KHz)
3 COMP/RGB (YPrPb 32KHz)
4
5 HDMI
6 HDMI
making a total of 24 different available Memories.
The image parameters that can be saved/recalled by the
Memories management system are the following:
BRIGHTNESS
CONTRAST
COLOUR
TINT
SHARPNESS
FILTER
NOISE REDUCTION
Some of these parameters may not be available for certain
inputs or certain input signals, as indicated in Tables 4 and 5.
The menu page for the Memories management functions is
activated by pressing the key
The operations that can be performed on each memory se-
lected are described here below.
ht3000e
3 COMP/RGB (RGB 15KHz)
3 COMP/RGB (RGB 32KHz)
GRAPHICS RGB/YPrPb
ASPECT
COLOUR TEMPERATURE
OVERSCAN
GAMMA
on the remote control.
