Sim2 HT3000E User And Installation Manual page 19

520
0.8
540
Green
0.6
Y 0.4
Infinity
0.2
480
470
450
0.0
0.2
1. Color Temperature
x= 0,307 T= 8700K
y= 0.320
= 0,015
uv
2. Ultra Contrast
green component. On the other hand, by selecting the ele-
ments in the lower part of the graph, an increase in the purple
component will be obtained. It is possible, as in the previous
case, to enable "Ultra Contrast" from within this menu. 1-2 Keys
allow to select "Ultra Contrast" menu
BEST COLOR
The projector uses the BrilliantColor(TM) algorithm to improve the
colour rendering of images. By enabling this function, the quality
of the image is optimised to the detriment of a moderate loss of
light. With this function disabled, the BrilliantColor(TM) algorithm
makes use of the maximum projector light.
gAMMA CORRECTiON
Determines the system's response to the grey scale, empha-
560
580
590
2850
1500
4800
1000
620
6500
10000
Red
650
Blue
0.4 0.6 0.8
X
y
x
On Off
sising or attenuating the different grades of brightness (blacks,
dark, medium, light grey, whites) in the projected image.
The projector has a range of gamma functions which enable
you to display any image to the best effect for the type of video
source, the ambient lighting and your subjective preferences.
There are 4 sets of gamma curves: Standard (ST), Enhanced
SIM2 (EN) and Graphics (GR), User. The Standard curve has
been defined for general use, and is set for videocameras,
digital cameras, and for viewing films or photos on your PC. The
Table 5 - gamma correction settings
ST1
ST2
ST3
ST4
ST5
Fig. 23
EN1
EN2
EN3
Fig. 24
EN4
EN5
G1
G2
ht3000e
For general use
Suited to displaying images from videoca-
meras, digital cameras or TV studios in high
ambient light.
Suited to displaying images from videoca-
meras, digital cameras or TV studios in low
ambient light.
Suited to displaying cinematographic material
in high ambient.
Suited to displaying cinematographic material
in moderate ambient.
Suited to displaying cinematographic material
in controlled ambient light.
Suited to displaying graphic images (e.g. Win-
dows desktop) in moderate ambient light.
Suited to displaying graphic images in mode-
rate controlled light.
19
