Summary of Contents for Sim2 HT3000E

  • Page 1 HT3000E 460649000...

  • Page 2: Remote Control And Keypad

    ht3000e 1 REMOTE CONTROL AND KEYPAD BACKLighTiNg STAND-BY / ON Backlights the keys on the remote control LIGHT Sets the panel to stand-by . KEYS 0-9 Select the sources directly. Switches on the panel from Standby. SOURCE Displays the source selection menu. ESCAPE Deactivates the On Screen Display.

  • Page 3: Table Of Contents

    The appliance has been subjected to exhaustive operating tests by digital graphics. SiM2 to ensure maximum quality. Faithful reproduction of signals at higher resolutions (such as high The projector bulb life should thus initially be around 30-60 hours.

  • Page 4: Fcc Statement

    ht3000e fCC STATEMENT CLASS B PRODUCT Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 5: Important Safety Instructions

    To prevent noxious materials being released into the environment and to promote the use of NATIVE materials, SIM2 Multimedia provides the following information regarding the disposal and recyclig of the product. Electrical and electronic waste materials (WEE) should never be disposed of in normal residential waste disposal facliities.
  • Page 6 ht3000e PROJECTOR R / P C / Y B / P L (R S 2 3 S -V ID E H IC S -V ID E R E M D IO E S C Projection lens. 11 Composite video input. Lens shift knob.
  • Page 7 ht3000e • Changing the fuses. • Do not allow the unit to overheat. Before changing the fuse disconnect the unit from the To prevent this, allow a free space of at least 40 cm around mains power supply. the back of the projector. The fuse compartment is next to the power supply con- Do not block the ventilation slots.

  • Page 8: Unpacking

    ht3000e 3 UNPACKiNg To remove the HT3000E system from its carton follow the diagrams (Fig. 4). Keep the carton for use when transporting or ship- ping the unit. Fig.4 CONTENTS Of PACKAgE - the projector - Remote control - four 1.5V AAA batteries (for remote control) - three power cables (EU, UK, USA) for the projector - the user manual.

  • Page 9: Installation

    ZOOM HELP observe the safety instructions included with the bracket FOCUS itself. if using a bracket other than that supplied by SiM2 FOCUS AUTO ASPECT Multimedia, make sure that the projector is at least 65 mm below the ceiling and that the bracket does not obstruct the air vents (intake and outlet).
  • Page 10 ht3000e screen’s axis. Prevent ambient light shining directly on the screen during projection as this will reduce the contrast of the projected image. Furniture and other objects with reflecting surfaces, as well as light coloured walls should be avoided, as they are likely to interfere with the screen’s characteristics.

  • Page 11: Switching The Projector On And Off

    ht3000e 5 SwiTChiNg ThE PROJECTOR ON AND Off wARNiNg: Connect the projector to a power supply with a SwiTCh ON fROM STANDBY nominal voltage within the following values: 100-240 V AC, 50/60 hz. it must be earthed (fig. 12). With the remote control press one of the keys (Fig. 14): - 0 to select the last imput selectet after last switching off.

  • Page 12: Connections

    ht3000e red leds on), after which they automatically switch off. Do not SwiTChiNg Off AND RETURNiNg TO STANDBY switch off the projector with the power switch until the fans have stopped running. With the remote control: press With the keypad: press When switching off, the projector goes into stand-by mode and stores the input selection at the time of switch-off.
  • Page 13 ht3000e hT3000E - Connection panel RGB - YPrPb GRAPHICS RGB + 1 2 R / P U S B S-VIDEO 1 . 1 C / Y N T R B / P VIDEO ( R S 2 3 2 HDMI S - V I D E H I C...
  • Page 14 ht3000e of the pictures reproduced by the HT3000E in the two cases: COMPOSiTE ViDEO the deinterlacing performed by the HT3000E is often more effective than that performed by the source itself. Fit an RCA connector with a Composite Video (CVBS) signal to this input.

  • Page 15: Remote Control

    ht3000e MOTORiSED SCREEN OUTPUTS RS232 iNTERfACE CONNECTOR 12Volt CONTROL RS 232 + 1 2 120 mA CONTROL USB R / C C / Y R / C U S B 1 . 1 B / C C / Y R S 2 B / C R S 2 S - V...

  • Page 16: On Screen Menu

    ht3000e 9 ON SCREEN MENU All system functions can be operated from the keypad or MAiN MENU remote control, with the aid of a complete, user-friendly on screen menu. To access the main menu of the On Screen Display press the MENU key on the keypad or the MENU+ or MENU- key on the remote control.
  • Page 17 ht3000e To access these submenus, press the <, mentre l’uscita ed Image il ritorno al livello superiore avviene con la pressione dei tasti MENU+/- key. Aspect Normal Press ESC on the remote control or keypad to interrupt the Anamorphic Color Temperature menu display or wait for it to disappear automatically after Letterbox Gamma Correction...
  • Page 18 ht3000e NOiSE REDUCTiON ANAMORPHIC: correctly displays a 16:9 image. This adjustment serves to select the noise reduction filter value. LETTERBOx: serves to display a 4:3 letterbox image (with source In this latter case, simply click on the slider and set the value signal having black bands above and below the picture) so that with the ◀...
  • Page 19 There are 4 sets of gamma curves: Standard (ST), Enhanced Green SIM2 (EN) and Graphics (GR), User. The Standard curve has been defined for general use, and is set for videocameras, digital cameras, and for viewing films or photos on your PC. The...
  • Page 20 ht3000e Enhanced set is suitable for watching movies. The Graphics set Y/C DELAY is suited to displaying synthetic graphics (PC, CAD, PC presenta- In the case of Video and S-Video signals, it may be necessary tions, etc.). User enables you to define your own curve. You can to correct horizontal colour misalignment within the projected thus select the coefficient which determines the curve.
  • Page 21 ht3000e Confirm? Fig.28 MENUS LANgUAgE It allow to select the languages available for the On Screen Display menus. iNPUTS LiST Fig.26 In order to make the HT3000E system increasingly flexible, the functions described below make it possible to modify the inputs LAMP POwER selection menu and adapt it so that it matches the require- To obtain the greatest picture quality, the LAMP POWER para-...
  • Page 22 ht3000e Table 6 same key as before. Use the ▲ key to switch from upper case to lower case characters. Cancel errors with ▼ once you have selected the character in question. Once you have terminated the text input procedure confirm your text and save it by pres- sing the MENU+ key on the remote control.
  • Page 23 ht3000e Blank MEMORiES Switches off the video signal and displays a black page. As soon as the key is pressed an OSD indication lasting a few se- The main picture parameters can be saved in discrete sets conds confirms that the function has been activated. Pressing of values called “Memories”...
  • Page 24 ht3000e 2 3 2 the corresponding drop-down menu (◀ key). Select the line S - V I D E H I C S - V ‘Save initial settings’. I D E R E M To confirm the operation, the message ‘Initial settings saved in O T E D I O Memory 1’...
  • Page 25 ht3000e iNfO Displays the current status of the projector and information concerning the projected video/graphic signal. This function is displayed on pressing the key on the remote control (or, in the absence of the On Screen Display, the ▶ key on the keypad).

  • Page 26: Cleaning And Maintenance

    ht3000e 10 CLEANiNg AND MAiNTENANCE The projector does not require internal adjustment. There are no user serviceable parts inside the projector. The lens may be cleaned with a very soft, non-abrasive small To replace the bulb or any other repairs, contact your local brush, in order to remove dust particles.

  • Page 27: Optional Accessories

    • keypad to execute automatic adjustments. 12 OPTiONAL ACCESSORiES You can purchase the following optional accessories at your Use only original or SiM2 Multimedia approved accessories. Dealer: warning: for ceiling/wall installation, by means of suspension - Ceiling mount kit bracket, carefully follow the instructions and safety instruc- - Lens tions recommended by the Manufacturer in the bracket’s...

  • Page 28: A Technical Specifications

    ht3000e A TEChNiCAL SPECifiCATiONS ELECTRONiCS gENERAL PROJECTOR SPECifiCATiONS Power cable: (EU, UK and US); 2m length Input signals: Power supply: from 100 to 240 V AC, +/-10% tolerance • COMPOSITE VIDEO (CVBS) Frequency: from 48 to 62 Hz gold plated RCA connectors Power absorption: 300 W max 1,0 V / 75 Ω, negative synchronisation...
  • Page 29 ht3000e B ON SCREEN MENU LAYOUT HDMI™ Video • S-Video Component [NTSC] Ghaphics Brightness Brightness Brightness Contrast Contrast Contrast Sharpness Color Color Sharpness Mode Tint Sharpness Cinema Mode Sharpness Sharpness Mode Best Color Cinema Mode Filter Noise reduction Best Color Cinema Mode Noise reduction Best Color...
  • Page 30 ht3000e Orientation Floor Keystone Floor-rear Horizontal Projection Lens Ceiling Vertical Zoom Ceiling-rear Lamp Power Focus Power On Lens shift Test patterns Initial settings Auto Stand-by English Italiano Français Deusch Español Português Language Pycc Source list F1/F2 keys F1 F2 Source info Zoom OSD background Focus...

  • Page 31: C Dimensions

    ht3000e C DiMENSiONS...

  • Page 32: D Projection Distance

    ht3000e D PROJECTiON DiSTANCE 16/9 Screen size Max projection distance Screen width Min projection distance (diagonal) max L max L in . 50” 44” 66” 90” 60” 52” 79” 107” 70” 61” 93” 126” 80” 70” 106” 144” 90” 78” 119”...
  • Page 33 Phone +39.434.383.253-256 • Fax +39.434.383260-261 www.sim2.com • e-mail: info@sim2.it SIM2 USA Inc. • 10108 USA Today Way • 33025 Miramar FL - USA Phone +1.954.4422999 • Fax +1.954.4422998 www.sim2usa.com • e-mail: sales@sim2usa.com SIM2 Deutschland GmbH • Gewerbepark, 17 D-35606 Solms Phone 0800.800.7462 • Fax 0800.900.7462 www.sim2.com • e-mail: info.de@sim2.it SIM2 UK LTD • Steinway House Worth Farm, Little Horsted Nr. Uckfield, East Sussex TN22 5TT Phone +44.01825.750850 • Fax +44.01825.750851 www.sim2.co.uk • e-mail: kate.buckle@sim2.co.uk SIM2 Multimedia is certified • In accordance with the manufacturer’s constant product development programme, product specifications and design are subject to changes without notice.
