Integrated Peripherals - ECS 865-M7 User Manual

Integrated Peripherals

These options display items that define the operation of peripheral components on the
system's input/output ports.
Phoenix-AwardBIOS CMOS Setup Utility
OnChip IDE Device
Onboard Device
SuperIO Device
: Move Enter: Select
F5:Previous Values
OnChip IDE Device
Scroll to this item and press <Enter> to view the following screen:
Phoenix-AwardBIOS CMOS Setup Utility
IDE HDD Block Mode
On-chip Primary PCI IDE
IDE Primary Master PIO
IDE Primary Slave PIO
IDE Primary Master UDMA
IDE Primary Slave UDMA
On-chip Secondary PCI IDE
IDE Secondary Master PIO
IDE Secondary Slave PIO
IDE Secondary Master UDMA
IDE Secondary Slave UDMA
ATA 66/100 Cable Msg
*** On-Chip Serial ATA Setting***
SATA Mode
On-chip Serial ATA
Serial ATA Port0 Mode
Serial ATA Port1 Mode
: Move Enter: Select
F5:Previous Values
IDE HDD Block Mode (Enabled)
Block mode is also called block transfer, multiple commands, or multiple sector read/write.
If your IDE hard drive supports block mode (most new drives do), select Enabled for
automatic detection of the optimal number of block read/write per sector the drive can
support.
On-Chip Primary/Secondary PCI IDE (Enabled)
This integrated peripheral controller contains an IDE interface with support for two IDE
channels. Select Enabled to activate each channel seperately.
Integrated Peripherals
Item Help
[Press Enter]
[Press Enter]
[Press Enter]
Menu Level
+/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
F6:Fail-Safe Defaults F7:Optimized Defaults
OnChip IDE Device
[Enabled]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
[IDE]
[Disabled]
[Primary Master]
Primary Master
+/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
F6:Fail-Safe Defaults F7:Optimized Defaults
Using BIOS
Item Help
Menu Level
41
