  • Page 3 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.0 Disclaimer The information in this document is subject to change without notice.

  • Page 4: Declaration Of Conformity

    Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the Motherboard Introduction....................1 Features.......................2 Motherboard Components...............4 7 7 7 7 7 Chapter 2 Installing the Motherboard Safety Precautions..................7 Choosing a Computer Case...............7 Installing the Motherboard in a Case............7...
  • Page 6 Advanced Chipset Features............39 Integrated Peripherals..............41 Power Management Setup............46 PNP/PCI Configurations.............48 PC Health Status................49 Frequency/Voltage Control............50 Load Fail-Safe Defaults..............51 Load Optimized Defaults.............51 Set Supervisor/User Password............51 Save & Exit Setup Option.............51 Exit Without Saving..............52 53 53 Chapter 4 Using the Motherboard Software About the Software CD-ROM..............53 Auto-installing under Windows 98/ME/2000/XP........53 Running Setup................54...

  • Page 7: Introducing The Motherboard

    Chapter 1 Introducing the Motherboard Introduction Thank you for choosing 865-M7 motherboard of great performance and with enhanced function. 865-M7 motherboard carries a Micro-ATX form factor of 244 x 244 mm. This motherboard is a high performance, enhanced function motherboard that supports LGA775 socket for the latest Intel Pentium 4/Celeron processors for high-end business or personal desktop markets.

  • Page 8: Features

    Features Processor The 865-M7 uses an LGA775 type of Pentium 4 that carries the following features: • Accommodates the latest Intel P4/Celeron processors • Supports a system bus (FSB) of 800/533MHz • Supports “Hyper-Threading” technology CPU “Hyper-Threading” technology enables the operating system into thinking it’s hooked up to two processors, allowing two threads to be run in parallel, both on separate “logical”...
  • Page 9 Graphics • 3D setup and render engine • 2D/3D graphics enhancement • Video DVD/PV-VCR • High quality texture engine • Zone Rendering support • Video Overlay Expansion Options The motherboard comes with the following expansion options: • Three 32-bit PCI slots •...

  • Page 10: Motherboard Components

    Motherboard Components Introducing the Motherboard...
  • Page 11 Table of Motherboard Components LABEL COMPONENT 1 CPU Socket LGA775 socket for P4/Celeron CPUs 2 CPU_FAN CPU cooling fan connector 3 DIMM1~DIMM4 184-pin DDR SDRAM slots 4 IR1 Onboard infrared header 5 FDD1 Floppy disk drive connector 6 ATX1 Standard 20-pin ATX power connector 7 IDE1 Primary IDE connector 8 IDE2...
  • Page 12 Memo Introducing the Motherboard...

  • Page 13: Installing The Motherboard

    Chapter 2 Installing the Motherboard Safety Precautions • Follow these safety precautions when installing the motherboard • Wear a grounding strap attached to a grounded device to avoid damage from static electricity • Discharge static electricity by touching the metal case of a safely grounded object before working on the motherboard •...

  • Page 14: Checking Jumper Settings

    Do not over-tighten the screws as this can stress the motherboard. Checking Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. Setting Jumpers Use the motherboard jumpers to set system configuration options. Jumpers with more than one pin are numbered.

  • Page 15: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. Jumper Settings Type Jumper Description Setting (default) 1-2: NORMAL Clear CMOS 2-3: CLEAR CLR_CMOS 3-pin CLEAR CMOS Before clearing the CMOS, make sure to turn off the sys- tem.

  • Page 16: Connecting Case Components

    Connecting Case Components After you have installed the motherboard into a case, you can begin con- necting the motherboard components. Refer to the following: Connect the CPU cooling fan cable to CPU_FAN. Connect the case cooling fan connector to SYS_FAN. Connect the power cooling fan connector to PWR_FAN.

  • Page 17: Front Panel Connector

    SPK1: Internal speaker Signal Name Signal Ground ATX1: ATX 20-pin Power Connector Signal Name Signal Name +3.3V +3.3V +3.3V -12V Ground Ground PS ON# Ground Ground Ground Ground Ground PWRGD +5VSB +12V ATX12V: ATX 12V Power Connector Signal Name Ground Ground +12V +12V...

  • Page 18: Installing Hardware

    Power/Sleep/Message waiting LED Connecting pins 2 and 4 to a single or dual-color, front panel mounted LED provides power on/off, sleep, and message waiting indication. Reset Switch Supporting the reset function requires connecting pin 5 and 7 to a momentary-contact switch that is normally open.

  • Page 19: Cpu Installation Procedure

    CPU Installation Procedure The following illustration shows CPU installation components. A. Unload the cap · Use thumb & forefinger to hold the lifting tab of the cap. · Lift the cap up and remove the cap completely from the socket. B.

  • Page 20: Installing Memory Modules

    Installing Memory Modules 865-M7 accommodates four 184-pin 2.5V unbuffered Double Data Rate (DDR) SDRAM (Synchronous Dynamic Random Access Memory) memory modules, and supports up to DDR400/333/266. Each module can be installed with 1GB of memory, the total maximum memory size is 4GB. DDR SDRAM memory module table Memory module Memory Bus...
  • Page 21 Table A: DDR (memory module) QVL (Qualified Vendor List) The following DDR400 memory modules have been tested and qualified for use with this motherboard. Size Vendor Module Name 128MB Infineon HYS64D16301GU-5-B NANYA NT128D64SH4B1G-5T 256MB Infineon HYS64D32300GU-5-B Infineon HYS64D32300HU-5-C Micron MT16VDDT3264AG-403B2 Micron MT8VDDT3264AG-40BC4 NANYA...

  • Page 22: Installing A Hard Disk Drive/Cd-Rom

    Installing a Hard Disk Drive/CD-ROM This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your motherboard has a primary and secondary IDE channel interface (IDE1 and IDE2). An IDE ribbon cable supporting two IDE devices is bundled with the motherboard. You must orient the cable connector so that the pin1 (color) edge of the cable correspoinds to the pin 1 of the I/O port connector.
  • Page 23 About SATA Connectors Your motherboard features two SATA connectors supporting a total of two drives. SATA , or Serial ATA (Advanced Technology Attachment) is the standard interface for the IDE hard drives which are currently used in most PCs. These connectors are well designed and will only fit in one orientation.

  • Page 24: Installing A Floppy Diskette Drive

    Installing a Floppy Diskette Drive The motherboard has a floppy diskette drive (FDD) interface and ships with a diskette drive ribbon cable that supports one or two floppy diskette drives. You can install a 5.25-inch drive and a 3.5-inch drive with various capacities. The floppy diskette drive cable has one type of connector for a 5.25-inch drive and another type of connector for a 3.5-inch drive.

  • Page 25: Installing Add-On Cards

    Installing Add-on Cards The slots on this motherboard are designed to hold expansion cards and connect them to the system bus. Expansion slots are a means of adding or enhancing the motherboard’s features and capabilities. With these efficient facilities, you can increase the motherboard’s capabili- ties by adding hardware that performs tasks that are not part of the basic system.
  • Page 26 Follow these instructions to install an add-on card: Remove a blanking plate from the system case corresponding to the slot you are going to use. Install the edge connector of the add-on card into the expansion slot. Ensure that the edge connector is correctly seated in the slot. Secure the metal bracket of the card to the system case with a screw.
  • Page 27 Millennium Silver TI4600 128MB Triplex GeForce FX5200 64MB ATI R7000 64MB ATI R7500 64MB ATI R9000 128MB ATI Radeon 9500 64MB ATI Radeon 9700PRO 128MB ECS R9200LE-64T For the latest supported AGP graphics list, please visit our website: www.ecs.com.tw/ECSWeb/Support/agp.aspx Installing the Motherboard...
  • Page 28 Once the AGP VGA card is properly installed under Windows 2000 or Windows XP, the below picture will be shown. And users will see the icon if the driver is not well-installed in the system. 1. It is normal to see the icon as the onboard VGA card is “Disabled”.

  • Page 29: Dual Monitor Installation (For Windows Xp)

    Dual Monitor In order to enable “Dual Monitor” Function, users must have “Two Monitors”, “Two Graphics Devices” (one is for AGP VGA card; the other one is for onboard VGA) and Windows 2000 or Windows XP that supports the Dual Monitor Function. Users must follow the “Dual Monitor Installation”...

  • Page 30: Dual Monitor Installation (For Windows 2000)

    Step 5: Right click the desktop. Select “Properties” as shown in the below. Step 6: Select “Display Properties”. Click “Settings” Then the parameters of the two minitors can be adjusted. Dual Monitor Installation (For Windows 2000) If the onboard VGA is already installed, and you want to use the add-on AGP VGA card, you may follow the installation step 1-6 as the following.
  • Page 31 Step 4: Install the Onboard VGA Driver Install the Onboard VGA driver from our support CD to utilize Dual Monitor Function. Please refer to the below path. CD-ROM:\VGA\Intel845_865\Win2K&XP\Graphics\Setup.exe Restart the computer If the add-on AGP VGA card driver and onboard VGA drivers are in- stalled, the dual-monitor display will be enabled.

  • Page 32: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: SPDIFO1: SPDIF out header This is an optional header that provides an S/PDIF (Sony/Philips Digital Interface) output to digital multimedia device through optical fiber or coaxial connector. Signal Name Function SPDIF digital output...
  • Page 33 USB3/4: Front Panel USB headers The motherboard has four USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connector to connect the front-mounted ports to the motherboard. Signal Name Function USBPWR...
  • Page 34 IR1: Infrared header The mainboard supports an Infrared (IR1) data port. Infrared ports allow the wireless exchange of information between your computer and similarly equipped devices such as printers, laptops, Personal Digital Assistants (PDAs), and other computers. Signal Name Function Not Assigned Not assigned No pin...

  • Page 35: Connecting I/O Devices

    Connecting I/O Devices The backplane of the motherboard has the following I/O ports: (optional) Use the upper PS/2 port to connect a PS/2 pointing device. PS2 Mouse Use the lower PS/2 port to connect a PS/2 keyboard. PS2 Keyboard Parallel Port (LPT1) Use LPT1 to connect printers or other parallel communications devices.
  • Page 36 Memo Installing the Motherboard...

  • Page 37: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configura- tion status and provides you with options to set system parameters.

  • Page 38: Bios Navigation Keys

    Press DEL to enter SETUP Pressing the delete key accesses the BIOS Setup Utility: Phoenix-AwardBIOS CMOS Setup Utility: Standard CMOS Features Frequency Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations...

  • Page 39: Updating The Bios

    Updating the BIOS You can download and install updated BIOS for this motherboard from the manufacturer’s Web site. New BIOS provides support for new peripherals, improvements in performance, or fixes for known bugs. Install new BIOS as follows: If your motherboard has a BIOS protection jumper, change the setting to allow BIOS flashing.

  • Page 40: Standard Cmos Features

    Standard CMOS Features This option displays basic information about your system. Phoenix-AwardBIOS CMOS Setup Utility Standard CMOS Features Date (mm:dd:yy) Mon, Sep 17 2004 Time (hh:mm:ss) 13 : 4 : 54 Item Help IDE Channel 0 Master IDE Channel 0 Slave IDE Channel 1 Master Menu Level IDE Channel 1 Slave...
  • Page 41 IDE Channel 0/1 Master/Slave (Auto) Leave this item at Auto to enable the system to automatically detect and configure IDE devices on the channel. If it fails to find a device, change the value to Manual and then manually configure the drive by entering the characteristics of the drive in the items described below.

  • Page 42: Advanced Bios Features

    Advanced BIOS Features This option defines advanced information about your system. Phoenix-AwardBIOS CMOS Setup Utility Advanced BIOS Features CPU Feature [Press Enter] Item Help Hard Disk Boot Priority [Press Enter] CPU L3 Cache [Enabled] Menu Level Hyper-Threading Technology [Enabled] Quick Power On Self Test [Enabled] First Boot Device [Floppy]...
  • Page 43 TM2 Bus Ratio (0X) This item helps you to set the frequency (bus ratio) of the throttled performance that will be initiated when the on-die sensor goes from not hot to hot. You may set the bus ratio number from 0-255. This feature is available when CPU supports Thermal Monitor 2.
  • Page 44 First/Second/Third Boot Device (Floppy/Hard Disk/CDROM) Use these three items to select the priority and order of the devices that your system searches for an operating system at start-up time. Boot Other Device (Enabled) When enabled, the system searches all other possible locations for an operating system if it fails to find one in the devices specified under the First, Second, and Third boot devices.

  • Page 45: Advanced Chipset Features

    Delay for HDD (Secs) (0) Users may set a delay from 1 to 15 seconds in the cold boot process. Some hard disk drives need extra time to spin up in order to identify correctly. If the system does not start after the memory test, try to add tomes in this field.
  • Page 46 DRAM RAS# Precharge (4) Select the number of CPU clocks allocated forthe Row Address Strobe (RAS#) signal to accumulate its charge before the DRAM is refreshed. If insufficient time is allowed, refresh may be incomplete and data lost. Memory Frequency For (Auto) This item sets the main memory frequency.

  • Page 47: Integrated Peripherals

    Integrated Peripherals These options display items that define the operation of peripheral components on the system’s input/output ports. Phoenix-AwardBIOS CMOS Setup Utility Integrated Peripherals Item Help OnChip IDE Device [Press Enter] Onboard Device [Press Enter] SuperIO Device [Press Enter] Menu Level : Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help...

  • Page 48: Onboard Device

    IDE Primary/Secondary Master/Slave PIO (Auto) Each IDE channel supports a master device and a slave device. These four items let you assign the kind of PIO (Programmed Input/Output) was used by the IDE devices. Choose Auto to let the system auto detect which PIO mode is best, or select a PIO mode from 0-4. IDE Primary/Secondary Master/Slave UDMA (Auto) Each IDE channel supports a master device and a slave device.

  • Page 49: Superio Device

    USB Keyboard Support (Enabled) This item allows the BIOS to interact with a USB keyboard or mouse to work with MS-DOS based utilities and non-Windows modes. USB Mouse Support (Enabled) Enable this item if you plan to use a mouse connected through the USB port in a legacy operating system (such as DOS) that does not support Plug and Play.
  • Page 50 Hot Key Power On (Ctrl-F12) When the POWER ON Function is set to Hot Key, use this item to set the hot key combination that turns on the system. Onboard FDC Controller (Enabled) Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it.
  • Page 51 ECP Mode Use DMA (3) When the onboard parallel port is set tp ECP mode, the parallel port can use DMA3 or DMA1. Power On After Power Fail (Off) This item enables your computer to automatically restart or return to its last operating status after power returns from a power failure.

  • Page 52: Power Management Setup

    Power Management Setup This option lets you control system power management. The system has various power- saving modes including powering down the hard disk, turning off the video, suspending to RAM, and software power down that allows the system to be automatically resumed by certain events.
  • Page 53 Suspend Type (Stop Grant) If this item is set to the default Stop Grant, the CPU will go into Idle Mode during power saving mode. MODEM Use IRQ (3) If you want an incoming call on a modem to automatically resume the system from a power-saving mode, use this item to specify the interrupt request line (IRQ) that is used by the modem.

  • Page 54: Pnp/Pci Configurations

    FDD, COM, LPT Port (Disabled) When this item is enabled, the system power will resume the system from a power saving mode if there is any activity on FDD, COM, or LPT port. PCI PIRQ [A-D] # (Disabled) When this item is enabled, the system power will resume the system from a power saving mode if there is any activity on PCI or PIRQ devices.

  • Page 55: Pc Health Status

    PCI/VGA Palette Snoop (Disabled) This item is designed to overcome problems that can be caused by some non-standard VGA cards. This board includes a built-in VGA system that does not require palette snooping so you must leave this item disabled. Assign IRQ For USB (Enabled) “Enable”...

  • Page 56: Frequency/Voltage Control

    Frequency Control This item enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in your system. Phoenix-AwardBIOS CMOS Setup Utility Frequency Control CPU Clock Ratio [8X]...

  • Page 57: Load Fail-Safe Defaults

    Load Fail-Safe Defaults Option This option opens a dialog box that lets you install fail-safe defaults for all appropriate items in the Setup Utility: Press <Y> and then <Enter> to install the defaults. Press <N> and then <Enter> to not install the defaults.

  • Page 58: Exit Without Saving

    Exit Without Saving Highlight this item and press <Enter> to discard any changes that you have made in the Setup Utility and exit the Setup Utility. When the Exit Without Saving dialog box appears, press <Y> to discard changes and exit, or press <N> to return to the main menu. If you have made settings that you do not want to save, use the “Exit Without Saving”...

  • Page 59: Using The Motherboard Software

    Chapter 4 Using the Motherboard Software About the Software CD-ROM The support software CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.

  • Page 60: Running Setup

    Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support Before installing the software from Windows Explorer, look for a file named README.TXT, INSTALL.TXT or something similar.
  • Page 61 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recommended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 62: Manual Installation

    Manual Installation Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your motherboard. Look for the chipset and motherboard model; then browse to the directory and path to begin installing the drivers.
  • Page 63 Caractéristiques Processeur Cette carte mère utilise un type LGA775 de Pentium 4 présentant les fonctionnalités suivantes : • Peut recevoir les derniers processeurs Intel P4/Celeron • Prend en charge un bus système (FSB) de 800/533 MHz • Prend en charge le CPU de technologie " Hyper-Threading" La technologie “Hyper-Threading”...
  • Page 64 Graphique • Configuration 3D et moteur de rendu • Amélioration graphique 2D/3D • DVD/PV-VCR Vidéo • Moteur de texture de haute qualité • Prise en charge du rendu de zone • Superposition vidéo Options d’extension La carte mère est livrée avec les options d’extensions suivantes: •...

  • Page 65: Audio Codec

    Feature Prozessor Das Motherboard verwendet einen LGA775 Typ Pentium 4 mit den folgenden Eigenschaften: • Nimmt die neuesten P4/Celeron Prozessoren auf • Unterstützt einen Systembus (FSB) mit 800/533MHz • Unterstützt eine CPU mit „Hyper-Threading“ Technologie Bei der „Hyper-Threading” Technologie „denkt” das Betriebssystem, dass es an zwei Prozessoren angeschlossen ist.
  • Page 66 Grafik • 3D-Setup und Render Engine • 2D/3D-Grafikerweiterung • Video DVD/PV-VCR • Qualitativ hochwertiger Texture Engine • Unterstützt Zone Rendering • Video-Overlay Erweiterungsoptionen Das Motherboard bietet die folgenden Erweiterungsoptionen: • Drei 32-Bit PCI-Steckplätze • Ein AGP-Express-Steckplatz • Zwei 7-Pin SATA-Stecker •...
  • Page 67 Caratteristiche Processore La scheda madre utilizza un tipo LGA775 di Pentium 4 che offre le seguenti caratteristiche: • Compatibilità con i più recenti processori Intel P4/Celeron • Supporto di un bus di sistema (FSB) da 800/533 MHz • Supporto di CPU con tecnologia “Hyper-Threading” La tecnologia “Hyper-Threading”...
  • Page 68 Grafica • Setup 3D e motore di rendering • Funzionalità avanzate di grafica 2D/3D • Video DVD/PV-VCR • Motore di trama ad alta qualità • Supporto di rendering delle aree • Supporto di Video Overlay Opzioni di espansione La scheda madre è dotata delle seguenti opzioni di espansione: •...
  • Page 69 Característica Procesador Esta placa principal usa un tipo LGA775 de Pentium 4 que lleva las sigtes. características: • Acomoda los últimos procesadores Intel P4/Celeron • Soporta un bus de sistema (FSB) de 800/533MHz • Soporta la CPU con tecnología "Hyper-Threading" La tecnología “Hyper-Threading”...
  • Page 70 Gráficas • 3D setup y motor de rendimiento • Meojamiento de gráficas 2D/3D • Vídeo DVD/PV-VCR • Motor de textura de alta calidad • Soporte de Rendimiento de Zona • Solapado de Vídeo Opciones de Expansión La placa principal viene con las sigtes. opciones de expansión: •...
  • Page 71 Características Processador Esta motherboard usa um tipo de Pentium 4 LGA775 que possui as seguintes características: • Acomoda os processadores Intel P4/Celeron mais recentes • Suporta um bus de sistema (FSB) de 800/533MHz • Suporta CPU de tecnologia “Hyper Threading” Tecnologia “Hyper Threading”...
  • Page 72 Gráficos • Instalação 3D e dispositivo de distribuição • Melhoramento de gráficos 2D/3D • Vídeo DVD/PV-VCR • Dispositivo de textura de elevada qualidade • Suporte de Distribuição de Zona • Cobertura de Vídeo Opções de Expansão A motherboard é fornecida com as seguintes opções de expansão: •...
  • Page 73 機能 プロセッサ このマザーボードにはLGA775 タイプのPentium 4 を取り付け可能で、次の特徴があ ります： • Intel P4 /Celeron プロセッサに対応 • 800/533 MHzのシステムバス(FSB)をサポート • “ハイパースレッド” 技術をサポート ハイパースレッド（HT） 技術というのは、オペレーションシステムに2つのプロセッサが存 在すると認識させることで、実際には2つのスレッドを1つのプロセッサで同時に執行させ 、平行利用を可能とする技術です。 チップセット Intel 865GV(GMCH)Northbridge (NB)と82801EB Southbridge (SB)チップセッ トは、実証された信頼性と性能を持つ革新的で拡張性のあるアーキテクチャに基づいて います。 • 865GV (NB) データ転送率が800/533/400MHzのP4/Celeron プロセッサ に対応 • 400/333/266 MHz の DDR-SDRAM に対応 •...
  • Page 74 グラフィック • 3Dセットアップ＆レンダーエンジンを導入 • 2D/3D グラフィック強化機能を導入 • ビデオDVD/PV-VCRに対応 • 高品質テクスチャエンジンを導入 • ゾーンレンダリング機能をサポート • ビデオオーバーレイ(Video Overlay)機能を導入 拡張オプション 本マザーボードでは、次の拡張機能が利用できます。 • 32ビットPCIスロット x3 • AGP Expressスロットx1 • 7ピンSATAコネクタ X2 • IDEヘッダー (4つのIDEデバイスの接続を可能) • フロッピーディスクドライブインターフェイス x1 • オプションのCNRスロットx1 このマザーボードは、100/66/33MB/秒の転送速度でのUltra DMAバスマスタリングを サポートします。 オンボードLAN (オプション) オンボードLANは、次の機能を提供します。 •...
  • Page 75 특성 프로세서 본 마더보드는 팬티엄 4 의 LGA775 을 사용하며 다음과 같은 특성을 지닙니다: • 최신 인텔 P4/샐러론 프로세서 사용 • 800/533MHz 의 시스템 버스 (FSB) 지원 • "Hyper-Threading" 기술의 CPU 지원 “Hyper-Threading" 기술은 운영 체제가 두개의 프로세서에 연결되어 있는 것처럼, 두...
  • Page 76 그래픽 • 3D 설정 및 랜더 엔진 • 2D/3D 그래픽 강화 • 비디오 DVD/PV-VCR • 고품질 텍스처 엔진 • Zone 랜더링 지원 • 비디오 오버레이 확장 옵션 본 마더보드의 확장 옵션은 다음과 같다: • 32 비트 PCI 슬롯 3 개 •...
  • Page 77 功能 處理器 本主機板㊜用於LGA775 型Pentium 4 且具㈲如㆘功能： • 支援Intel P4 /Celeron 處理器； • 支援高達800/533MHz之系統匯流排(FSB)； • 支援使用超執行緒(Hyper-Threading)技術之CPU。 利用“超執行緒(HT)”技術，可使作業系統在相當於裝㆖了兩具處理器的狀態㆘運作 ：利用㆒個”實體”處理器模擬出兩個獨立的”邏輯”處理器，同時執行兩個工作緒 。 晶片組 Intel 865GV(GMCH)北橋(NB)及82801EB(ICH5)南橋(SB)晶片組在研發設計㆖採用了創新 且具擴充性之架構，具備㊝良的可靠性及性能。 • 865GV (NB) 支援傳輸率高達800/533/400MHz的P4/Celeron 處理器； • 支援400/333/266 MHz的DDR-SDRAM； • 具㈲內建終結的AGTL+主控匯流排，支援32位元主控定址； • 具㈲8位元/66MHz 8X 匯流排介面，連接Intel ICH5； • 整合㈲㆒繪圖加速器，藉此提供低成本3D、2D 及視訊相容 性。...
  • Page 78 繪圖卡 ‧ 3D算圖引擎； ‧ 2D/3D圖形強化功能； ‧ 視訊DVD/PV-VCR； ‧ 高品質紋理引擎； ‧ 支援區域繪圖成形(Zone Rendering)功能 ‧ 影像重疊(Video Overlay)功能 擴充選㊠ 本主機板包括㆘列擴充選㊠： • 3 個 32-bit PCI 插槽； • 1 個 AGP Express 插槽 ； • 2 個7針SATA插頭 • 2 個 IDE 接頭，支援 4個 IDE 裝置； •...
  • Page 79 功能 处理器 此主板使用 LGA775 型 Pentium 4 CPU，具备以下特点： • 支持最新的 Intel P4/Celeron 处理器 • 支持 800/533 MHz 系统总线 (FSB) • 支持“多线程”技术 CPU “多线程”技术可以让操作系统认为自己连接了两个处理器，允许两个线程并行运行 ，每个线程位于同一处理器中的单独“逻辑”处理器中。 芯片组 Intel 865GV(GMCH) 北桥 (NB) 和 82801EB(ICH5) 南桥 (SB) 芯片组是基于一种新型 的、可扩展的架构，能提供已经证明的可靠性和高性能。 865GV (NB) • 支持 P4/Celeron 处理器，数据传输速率可达 800/533/ 400MHz •...

  • Page 80: Onboard Lan

    图形 • 3D 设置和着色引擎 • 2D/3D 增强图形 • 视频 DVD/PV-VCR • 高性能纹理引擎 • 支持区域着色 • 视频覆盖 扩展选项 此主板提供如下扩展选项： • 3 个 32 位 PCI 扩展插槽 • 1 个AGP Express 槽 • 2 个 7-pin SATA 接口 • 2 个 IDE 接口，可支持 4 个 IDE 设备 •...
  • Page 81 Характеристики Процессор Плата построена на базе процессора Pentium 4 LGA775 и обладает следующими характеристиками: • Поддерживает новейшие процессоры Intel P4/Celeron • Поддерживает системные шины (FSB) с частотой 800/533MHz • Поддерживает технологию CPU “Hyper-Threading” Технология “Hyper-Threading” «убеждает» операционную систему в том, что в машине имеется...
  • Page 82 Графика • Процессор трехмерной графики (3D setup and render) • Расширение графики 2D/3D • Видео DVD/PV-VCR • Процессор высококачественных текстур • Поддержка технологии Zone Rendering • Поддержка режима Video Overlay Возможности расширения Существуют следуюшие опции расширения данной материнской платы: • Три...
  • Page 83 Cechy Procesor Ta płyta główna zaopatrzona jest w procesor Pentium 4 typu LGA775 i charakteryzuje się następującymi cechami: • Obsługuje najnowsze procesory Intel P4/Celeron • Obsługuje szynę systemowa (FSB) 800/533MHz • Zabezpiecza technologię CPU “Hyper-Threading” Technologia “Hyper-Threading” powoduje, że system "myśli”, że posiada dwa procesory i wykonuje równolegle dwa procesy;...
  • Page 84 Grafika • Procesor 3D setup and render • Rozszerzona grafika 2D/3D • Video DVD/PV-VCR • Procesor tekstur wysokiej jakości • Obsługuje technologię Zone Rendering • Obsługuje tryb Video Overlay Możliwości rozbudowy Płyta głwna wyposażona jest w następujące gniazda: • Trzy 32-bitowe gniazda PCI •...
  • Page 85 Vlastnosti Procesor Tato základní deska je určena pro procesory Pentium 4 LGA775 a může nabídnout následující vlastnosti: • Základní deska je určena pro nejnovější procesy Intel P4/Celeron • Podporuje taktování systémové sběrnice (FSB) na frekvenci 800/533 MHz • Podporuje technologii CPU „Hyper-Threading“ Technologie „Hyper-Threading“...
  • Page 86 Grafika • Renderovací grafické jádro 3D • Funkce vylepšující zobrazení 2D/3D grafiky • Video DVD/PV-VCR • Jádro pro zobrazování textur ve vysoké kvalitě • Podpora zónového renderování • Překrývání videa Možnosti rozšíření Základní deska je dodávána s následujícími možnostmi rozšíření •...
  • Page 87 Caracteristici Procesorul Această placă de bază utilizează Pentium 4 de tipul LGA775, având următoarele caracteristici: • Este destinată celor mai recente procesoare Intel P4/Celeron • Funcţionează cu bus sistem (FSB) de 800/533 MHz • Este compatibilă cu unităţi centrale dotate cu tehnologia „Hyper- Threading”...
  • Page 88 Grafică • Motor de configurare şi randare 3D • Intensificare grafici 2D/3D • Video DVD/PV-VCR • Motor de texturare de înaltă calitate • Permite randare de zone • Suprapunere video Opţiuni de extindere Placa de bază este dotată următoarele posibilităţi de extindere: •...
  • Page 89 Спецификация Процесор Тази дънна платка използва Pentium 4 тип LGA775 със следните спецификации: • поддръжка на последни модели процесори Intel P4/Celeron • поддръжка на системна шина със скорост 800/533MHz • поддръжка на процесори с технология “Hyper-Threading" Технологията “Hyper-Threading" позволява да се “излъже” операционната система, че работи...
  • Page 90 Графичен чип • 3D setup and render engine • подобрена графика 2D/3D • Video DVD/PV-VCR • висококачествено ядро за текстури • поддръжка на Zone Rendering • Video Overlay Възможности за разширяване Дънната платка има следните разширителни възможности: • три 32-bit PCI слота •...
  • Page 91 Jellemző Processzor Ez az alaplap LGA775 típusú Pentium 4 számára készült, és a következő jellemzőkkel bír: • A legújabb Intel P4/Celeron processzorokkal működik • 800/533 MHz sebességű rendszerbuszt (FSB) támogat • Támogatja a „Hyper-Threading” technológiát használó központi egységeket A „Hyper-Threading” technológia által az operációs rendszer úgy működik, mintha két processzorral rendelkezne, ami két szál párhuzamos futását teszi lehetővé...
  • Page 92 Grafika • 3D beállító és megjelenítő motor • 2D/3D grafikus bővítés • Video DVD/PV-VCR • Kiváló minőségű mintázómotor • Zónamegjelenítés támogatása • Video átfedés Bővítési lehetőségek Az alaplap a következő bővítési lehetőségekkel rendelkezik: • Három 32 bites PCI foglalat • Egy AGP Express foglalat •...
