Avaya 90A Attenuator Installation Instructions

Attenuator

CIB 3242

Comcode 700262512

Issue 2

May 2003

Model 90A Attenuator

Comcode 107864456

Installation Instructions

Always follow these basic safety precautions when installing the

Model 90A Attenuator:

1. Read and understand all instructions.

2. Never touch uninsulated telephone wires or terminals, unless

the telephone line has been disconnected at the network

interface.

3. Use caution when installing this product on telephone lines.

4. DO NOT install this product on telephone wiring during a

lightning storm.

5. Never install this product in a wet location.

Save these instructions

Table of Contents

Do you have a question about the 90A Attenuator and is the answer not in the manual?

Page 1: Installation Instructions
CIB 3242 Comcode 700262512 Issue 2 May 2003 Model 90A Attenuator Comcode 107864456 Installation Instructions Important Safety Instructions Always follow these basic safety precautions when installing the Model 90A Attenuator: 1. Read and understand all instructions. 2. Never touch uninsulated telephone wires or terminals, unless the telephone line has been disconnected at the network interface.
Page 2 Installation 1. Refer to the diagram below for placement instructions. Be sure to use the 2-foot 4 conductor (D4BU) modular cord supplied with the Attenuator (Comcode 107864456). 2. Connect one end of the 2-foot D4BU cord to a modular jack on the Attenuator.
Page 3 Parts Enclosed Modular jacks 2-foot 4 conductor (D4BU) Attenuator modular cord...
Page 4 Copyright 2003, Avaya Inc. All rights reserved. All trademarks identified by the  and  are registered trademarks or trademarks respectively. All other trademarks are properties of their respective owners. The above information is based on knowledge available at the time of publication and is subject to change without notice.
