  • Page 1 Coronis Fusion 4MP/6MP User Guide...
  • Page 2 (This page intentionally left blank.) Coronis Fusion 4MP/6MP...
  • Page 3 Welcome! Thank you for choosing this C 4MP/6MP display! ORONIS USION Coronis Fusion is an ingenious PACS display system designed to further enhance flexibility and productivity in diagnostic imaging. Featuring the industry’s first 30-inch color LCD that can be used as two seamless heads or one wide-screen display, Coronis Fusion offers you the freedom to organize your workspace just the way you want it.
  • Page 4 (This page intentionally left blank.) Coronis Fusion 4MP/6MP...

  • Page 5: Table Of Contents

    Table of contents What's in the box.............6 Parts, controls and connectors ........7 Front view ....................7 Rear view ....................8 Display installation ............11 Removing the covers ................11 Unlocking the height mechanism ............13 Adjusting the display position ............. 14 Connecting the signal cables...............
  • Page 6 Information menu................. 37 Changing the viewing mode ............... 38 Enabling/disabling User Controls............38 Switching Power LED on/off ............... 40 Switching DPMS on/off................ 40 Changing Display Functions ..............41 Concepts..................41 Display function selection ............42 ALC & DICOM Options..............43 Cleaning your display ............48 Front glass .....................

  • Page 7: What's In The Box

    • If you ordered a Barco display controller, it’s also in the box together with its accessories. A dedicated user guide is available on the system Keep your original packaging. It is designed for this display and is the ideal protection during transport.

  • Page 8: Parts, Controls And Connectors

    Parts, controls and connectors Front view USB downstream connectors Left/Down key Right/Up key Enter key Stand-by key Ambient light sensor Power status indicator light Control wheel Coronis Fusion 4MP/6MP...

  • Page 9: Rear View

    Rear view Connector compartment Neck cover cover Display stand cover Coronis Fusion 4MP/6MP...
  • Page 10 ORONIS USION +24 VDC power input USB upstream connector USB downstream connector +5 VDC, 0.25 A power output for accessories +3.3 VDC, 0.25A auxiliary DVI 1 video input power output DVI 2 video input Coronis Fusion 4MP/6MP...
  • Page 11 ORONIS USION +24 VDC power input USB upstream connector USB downstream connector +5 VDC, 0.25 A power output for accessories +3.3 VDC, 0.25A auxiliary DVI 1 video input power output DVI 2 video input Coronis Fusion 4MP/6MP...

  • Page 12: Display Installation

    USION connecting all necessary cables, make sure to have a suitable display controller physically installed in your computer. If you are using a Barco display controller, please consult the dedicated user guide available on the system CD. Removing the covers...
  • Page 13 ISPLAY STAND COVER To get access to the cable routing channel, the display stand cover should be removed. This can be done as follows: Gently press and hold the clips at the inside top of the cover. Slide the cover upwards while holding the clips pressed. Coronis Fusion 4MP/6MP...

  • Page 14: Unlocking The Height Mechanism

    Unlocking the height mechanism In the factory, the height-positioning system in the display stand is locked with a red hook to prevent damage during transportation. You’ll have to remove this hook before adjusting your display height position. While holding the display panel pushed down, pull out the red hook in the display stand.

  • Page 15: Adjusting The Display Position

    Adjusting the display position Now that the height-positioning system of your display is unlocked, you can tilt, swivel, raise and lower the display as desired. Do not try to pivot your display when attached to the stand. Trying to do so could cause serious damage to your display and its stand.

  • Page 16: Connecting The Signal Cables

    Connecting the signal cables Connect one head of the display controller to the DVI 1 connector with one of the supplied DVI cables. Connect another head of the display controller to the DVI 2 connector with one of the supplied DVI cables. If you want to make use of your display’s USB downstream connectors, connect a PC USB downstream connector to the display’s USB upstream connector by means of the supplied USB...

  • Page 17: Connecting The Power Cables

    Connecting the power cables Connect the supplied external DC power supply to the +24 VDC power input of your C 4MP/6MP display. ORONIS USION Plug the other end of the external DC power supply into a grounded power outlet by means of the proper power cord delivered in the packaging.

  • Page 18: Re-Attaching The Covers

    Re-attaching the covers Re-attach the display stand cover by sliding it downward. You’ll hear a “click” sound of the cover’s clips when the display stand cover is in position. Pay attention that all cables stay in the cable channel while replacing the cover. Re-attach the connector compartment cover by sliding the cover’s top in position and then push the cover’s bottom.

  • Page 19: Vesa-Mount Installation

    VESA-mount installation The panel, standard attached to a stand, is compatible with the VESA 100 mm standard. Thus, it can be used with an arm that is approved by VESA. This chapter shows you how to release the panel from the stand and how to attach it to an arm.
  • Page 20 Lift the plastic frame that covers the fixation of the panel to the stand. Turn it for 45 degrees to uncover the fixation screws. Unscrew the four fixation screws fixing the panel to the stand. Attach the panel firmly to the arm using 4 screws M4 x 10 mm. You should mount the panel in landscape position.

  • Page 21: First Time Starting Up

    USION video mode at a default refresh rate when first time starting If you are using a Barco display controller, please consult the dedicated user guide available on the system CD to install the drivers, software and documentation. When this is done, your display will automatically detect the connected video input signal(s) and apply the correct video mode and refresh rate.

  • Page 22: Daily Operation

    DPMS is enabled on your display, but it also needs to be activated on your workstation. To do this, go to “Power Options Properties” in the “Control Panel”. Barco recommends setting DPMS activation after 20 minutes of non-usage. SE A SCREEN SAVER TO AVOID IMAGE RETENTION Prolonged operation of an LCD with the same content on the same screen area may result in a form of image retention.
  • Page 23 NHANCE USER COMFORT Every Barco multi-head display system is color matched with the highest specification in the market. Barco recommends keeping color-matched displays together. Furthermore, it is important to use all displays of a multi-head configuration at the same rate to preserve color matching throughout the economic lifetime of the system.

  • Page 24: Stand-By Switching

    Stand-by switching SING THE TOUCH KEYS While the OSD is not on the screen, touch any touch key. As a result, the control panel illumination is switched on for a few seconds. While the contol panel illumination is on, touch the stand-by touch key.

  • Page 25: Navigating Through The Osd Menus

    Navigating through the OSD menus SING THE TOUCH KEYS Use the Up and Down keys to move through the menus. To go into a submenu, use the Up or Down key to highlight the submenu. Next, touch the Enter key to go into the submenu.

  • Page 26: Making Selections In The Osd Menus

    Making selections in the OSD menus SING THE TOUCH KEYS Navigate through the menus and highlight the parameter you wish to select. Touch the Enter key to make a selection or toggle between several settings. SING THE CONTROL WHEEL Navigate through the menus and highlight the parameter you wish to select.

  • Page 27: Advanced Operation

    Advanced operation Info messages The following messages may appear automatically on the screen: NPUT ELECTION The Input selection menu appears in case 2 video signals are connected and the resolution of one or both video signals is too high to display them both.
  • Page 28 LCM T EMPERATURE This is a serious error message. You should power off the display and call for service. The warning means the LCD panel temperature is too high. As a result the display switches to a safe operating mode (with decreased backlight value).

  • Page 29: On-Screen Display (Osd)

    On-screen display (OSD) Luminance and color menu Measured luminance Indicates the actual luminance measured by the internal sensor. This is a read-only value. It is expressed in cd/m2. Luminance target Allows to manually adjust the luminance target. See note below. Color target Allows to select from a list of factory- defined and user-defined color targets.
  • Page 30 OLOR DEFINITION SUBMENU A color target is defined by its luminance target and color temperature. The color definition submenu allows to edit these values. Color name Indicates the color target you are editing. You can select another color target to edit by using the Up and Down touch keys...

  • Page 31: Display Function Menu

    Color temperature Allows to define the color temperature that corresponds to the color target in Kelvin units. This function is available only when the color target is defined in Kelvin units. This function is available only when the User color target is selected. Restore factory x, y Allows to reset the (x,y) co-ordinates of values...
  • Page 32 ALC & DICOM O PTIONS SUBMENU Measured ambient Indicates the ambient light actually light measured by the ambient light sensor on the front of the display. This is a read-only value. Averaged ambient Shows the average of the measured light ambient light since the display was switched on.
  • Page 33 DICOM offset This function is available only when the DICOM DF is selected.When Continuous DICOM ALC is switched off, the DICOM DF is recalculated at the moment the DICOM Offset is changed, taking the new DICOM Offset into account. When set to “Dark Room”, the •...
  • Page 34 Calibration info Jumps to the calculation information submenu, which displays information about the values taken into account to recalculate the DICOM DF. EADING ROOM DEFINITION SUBMENU Measured ambient Indicates the ambient light actually light measured by the ambient light sensor on the front of the display.
  • Page 35 Measured ALC value The value shown here is taken into account in the calculation of the DICOM DF if Continuous DICOM ALC is switched off and DICOM Offset is set to “Measured ALC”. When you select this line and confirm the selection, the actual averaged ambient light value is stored here, overwriting the former value.

  • Page 36: Settings Menu

    Settings menu DPMS Allows to switch the display power management system on/off. See note below. Power LED Allows to switch the power LED’s on state on/off. The LED's orange DPMS state is not influenced by this setting. So, when the display goes into power-saving mode, the LED will turn orange, even if it was switched off by this setting...
  • Page 37 OSD Orientation Select the desired orientation of the on- screen display. The default position is Landscape, but if you put the display in portrait orientation (possible but not supported), you should select Portrait as OSD orientation as well. If not, the OSD will not be easily readable.

  • Page 38: Information Menu

    The DPMS system will power down the display when the connected computer is left idle for a certain time. Barco recommends to switch DPMS on to prevent image burn- in (image retention) on the LCD panel.. Information menu Product...

  • Page 39: Changing The Viewing Mode

    Changing the viewing mode BOUT VIEWING MODES The display contains two viewing modes. Diagnostic viewing mode provides the full calibrated luminance. This mode is intended for using the display in diagnostic applications. In Text mode, the luminance is approximately half of the luminance in Diagnostic mode.
  • Page 40 O ENABLE THE USER CONTROLS AGAIN USING THE TOUCH KEYS To enter the user controls keycode, the OSD must not be visible. Touch any of the soft touch keys to switch on the front illumination. While the illumination is on, touch the following keys in successive order: Enter Down...

  • Page 41: Switching Power Led On/Off

    Switching Power LED on/off O SWITCH THE POWER Open the OSD main menu. Open the Settings menu. Select Power LED. Select On or Off. Return to the Settings menu. When the display is switched in stand-by, the power LED will turn orange, even if the power LED setting is switched off.

  • Page 42: Changing Display Functions

    Changing Display Functions Concepts The Display Function menu lets you select a display function (DF). • When you select the DICOM DF you can define the DICOM DF to be • recalculated taking the ambient light into account. This can be a continuous recalculation (“Continuous DICOM ALC”...

  • Page 43: Display Function Selection

    Display function selection (DF): O SELECT A DISPLAY FUNCTION Open the main menu. Open the Display Function menu. Select Display Function. Select the desired DF. Return to the Display Function menu. You can select the following DFs: DICOM Select a DICOM display function for most medical viewing applications.

  • Page 44: Alc & Dicom Options

    ALC & DICOM Options Continuous DICOM ALC NTRODUCTION When you select the DICOM DF, the display offers the possibility to take the ambient light into account for calculating the DICOM display function. This function is called Continuous DICOM ALC (ALC is short for Ambient Light Compensation).
  • Page 45 DICOM O SELECT A OFFSET Select the DICOM display function. See To select a display function (DF):, on page 43. Switch Continuous DICOM ALC off. See To switch continuous DICOM ALC on/off:, on page 44. In the ALC & DICOM Options menu, select DICOM Offset. Select an offset.
  • Page 46 O SELECT A READING ROOM SETTING Select the DICOM display function. See To select a display function (DF):, on page 43. Switch Continuous DICOM ALC off. See To switch continuous DICOM ALC on/off:, on page 44. In the ALC & DICOM Options menu, select Reading Room. Select the reading room that corresponds to the room type the display is installed in.
  • Page 47 Reading room definition This function is available only when the DICOM display function is selected and Continuous DICOM ALC is off. O MODIFY A READING ROOM DEFINITION Select the DICOM display function. See To select a display function (DF):, on page 43. Switch Continuous DICOM ALC off.
  • Page 48 light value. Use Enter or click the control wheel again to store the value. However, if you wish to adapt the ambient light conditions to • the definition of the selected reading room, dim the light in the room so that the measured ambient light becomes lower that the maximum ambient light.

  • Page 49: Cleaning Your Display

    Cleaning your display Front glass Clean the front glass using a sponge, cleaning cloth or soft tissue, lightly Before cleaning the front glass, unplug the power cable from the mains to prevent the keys from being activated inadvertently by sweeping over them. moistened with one of the following tested products: Flux Pril...

  • Page 50: Cabinet

    Do not use following products: Alcohol/solvents at higher concentration > 5% • Strong alkalis lye, strong solvents • Acid • Detergents with fluoride • Detergents with ammonia • Detergents with abrasives • Steel wool • Sponge with abrasives • Steel blades •...

  • Page 51: Important Information

    Important information Safety information ENERAL ECOMMENDATIONS Read the safety and operating instructions before operating the display. Retain safety and operating instructions for future reference. Adhere to all warnings on the display and in the operating instructions manual. Follow all instructions for operation and use. LECTRICAL SHOCK YPE OF PROTECTION ELECTRICAL...
  • Page 52 24 VDC OWER CONNECTION DISPLAY WITH EXTERNAL POWER SUPPLY Power requirements: The display must be powered using the • delivered medical approved 24 VDC SELV power supply. The medical approved DC power supply must be powered by the • AC mains voltage (protective earth terminal). OWER CORDS Utilize a UL-listed detachable power cord, 3-wire, type SJ or •...
  • Page 53 display may fall, causing serious injury to a child or adult, and serious damage to the equipment. ORONIS USION CONFORMS TO UL 60601-1 1ST EDITION, CAN/CSA-C22.2 NO. 601.1-M90, IEC 60601-1 2ND ED:1988 + A1:1991 + A2:1995, IEC 60950-1:2001 1ST EDITION, CE - 89/336/EEC, CE - 93/42/EEC, DEMKO - EN 60601-1, BSMI - CNS13438(95) + CNS14336(94), VCCI, FCC class B, ICES-001 Level B, MDD class IIb, FDA 510k, RoHS...

  • Page 54: Environmental Information

    ERCURY NOTICE This Barco product consists of materials that may contain mercury, which must be recycled or disposed of in accordance with local, state, or country laws: Within this system, the backlight lamps in the monitor display •...
  • Page 55 Electronic Information Products" (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco's product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section "Limit Requirements of toxic substances...
  • Page 56 Pollution Control Labeling Standard" of Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the "Standard of Electronic Information Products Environmental Friendly Use Period"...

  • Page 57: Regulatory Compliance Information

    Regulatory compliance information NDICATIONS FOR USE ORONIS USION The Coronis Fusion 4MP (MDCC-4130) display is a display device capable of displaying two 2MP display images electronically fused together on the one panel. It is intended to be used in displaying and viewing digital images for review and analysis by trained medical practitioners.

  • Page 58: Explanation Of Symbols

    are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
  • Page 59 Indicates the display is approved according to the c-UL regulations Indicates the display is approved according to the DEMKO regulations Indicates the display is approved according S&E to the CCC regulations Indicates the display is approved according to the VCCI regulations Indicates the USB connectors on the display Indicates the manufacturing date Indicates the temperature limitations for...

  • Page 60: Legal Disclaimer

    Barco software products are the property of Barco. They are distributed under copyright by Barco N.V. or Barco, Inc., for use only under the specific terms of a software license agreement between Barco N.V. or Barco Inc.

  • Page 61: Technical Specifications

    Technical specifications ORONIS USION Product acronym MDCC-4130 Screen technology TFT AM Color LCD Dual Domain IPS-Pro Active screen size 758.36 mm (29.9") (diagonal) Active screen size (H x V) 641.208 x 404.808 mm (25.25 x 15.94") Aspect ratio (H:V) 16:10 Resolution native 4MP (2560 x 1600) configurable to 2 x 2MP+ (1280 x 1600)
  • Page 62 Response time (Tr + Tf) 20 ms Scanning frequency (H; V) 30-150 kHz; 15-80 Hz Housing color Black/Silver Video input signals DVI-D Dual Link (2x) Video inout terminals USB ports 1 upstream (endpoint), 3 downstream USB standard Power requirements 100-240V (nominal) Power consumption 135W...
  • Page 63 Tilt -5° / +25° Swivel -45° / +45° Pivot Mounting standard VESA (100 mm) Screen protection Protective, non-reflective glass cover Recommended modalities CT, MR, US, DR, CR, NM, Film Certifications UL 60601-1 1ST EDITION, CAN/CSA-C22.2 NO. 601.1- M90, IEC 60601-1 2ND ED:1988 + A1:1991 + A2:1995, IEC 60950-1:2001 1ST EDITION, CE - 89/336/EEC, CE - 93/42/EEC, DEMKO - EN 60601-1, BSMI -...
  • Page 64 ORONIS USION Product acronym MDCC-6130 DL Screen technology TFT AM Color LCD Dual Domain IPS-Pro Active screen size 772 mm (30.4") (diagonal) Active screen size (H x V) 654 x 409 mm (25.8 x 16.1") Aspect ratio (H:V) 16:10 Resolution native 6MP (3280 x 2048) configurable to 2 x 3MP+ (1640 X 2048) configurable to 2 x 3MP (1536 X 2048)
  • Page 65 Scanning frequency (H; V) 30-150 kHz; 15-80 Hz Housing color Black/Silver Video input signals DVI-D Dual Link (2x) Video inout terminals USB ports 1 upstream (endpoint), 3 downstream USB standard Power requirements 100-240V (nominal) Power consumption 166W (nominal) Power save mode Power management DVI-DMPM Dot clock...
  • Page 66 Swivel -45° / +45° Pivot Mounting standard VESA (100 mm) Screen protection Protective, non-reflective glass cover Recommended modalities CT, MR, US, DR, CR, NM, Film Certifications UL 60601-1 1ST EDITION, CAN/CSA-C22.2 NO. 601.1- M90, IEC 60601-1 2ND ED:1988 + A1:1991 + A2:1995, IEC 60950-1:2001 1ST EDITION, CE - 89/336/EEC, CE - 93/42/EEC, DEMKO - EN 60601-1, CCC - GB9254-...

  • Page 67: Warranty Statement

    Customer return a defective Product or part thereof to Barco without Barco's prior written approval. In the event the return to Barco of the defective Product is authorized by Barco, Barco shall issue to Customer an RMA (Return Material Authorization).
  • Page 68 All software installed on the system, whether they are acquired from Barco nv, MID or third party. An exception is made for software delivered by Barco nv, MID that would prove to be a cause for the mal functioning of the hardware covered under this Agreement.
  • Page 69 The Customer is responsible for installing the Barco nv, MID equipment in an environment for which it was intended. If there is an indication that the equipment was used – even temporary – outside its specifications, Barco nv, MID is entitled not to perform warranty repairs and terminate the warranty agreement. Any actions that have been taken by Barco nv, MID in this respect, may be invoiced to the Customer at normal pricing.
  • Page 70 Barco nv, MID shall not be responsible for machine failure and/or its failure to render service or maintenance due to causes beyond its reasonable control.
  • Page 71 (This page intentionally left blank.) Coronis Fusion 4MP/6MP...
