How to Get Started

If you are familiar with the Fluke 80 Series DMM, read
"Using the Current Output Functions," review the tables
and figures in "Getting Acquainted with the Meter," and
begin using your meter.
If you are unfamiliar with Fluke 80 Series DMMs, or DMMs
in general, read "Measuring Electrical Parameters" in
addition to the sections referenced in the previous
paragraph.
The sections following "Using the Current Output
Functions" contain information about the power-up
options, and battery and fuse replacement instructions.
Later, use the Quick Reference Card to refresh your
memory about the various functions and features that you
can use.
Display
787
MIN MAX
% STEP
Rotary
Switch
mV
V
V
OFF
OUTPUT 0-24mA
SOURCE SIMULATE
+ +
A mA
30mA
0.44A
FUSED
(1A /30 sec)
FUSED
Figure 1. Fluke 787 ProcessMeter
ProcessMeter
How to Get Started
PROCESSMETER
Pushbuttons
RANGE HOLD H
COARSE FINE
REL Hz
mA
A
OUTPUT
mA
mA
Input/Output
Jacks
COM V
CAT
1000V
ee014f.eps
