DisplayPort Extender over
Fiber Optic Cable
Model #: FO-DP-XX-MM
© 2010 Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. ("Avenview") products. Avenview makes no representations or warranties with
respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any
time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in
Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products
including, but not limited to, the implied warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.
Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly prohibited.
www.avenview.com
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avenview FO-DP-XX-MM
Summary of Contents for Avenview FO-DP-XX-MM
- Page 1 No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products including, but not limited to, the implied warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.
-
Page 2: Table Of Contents
2.1.1 Transmitter (Source) Module ....................7 2.1.2 Receiver Module ........................8 2.2 Connector Pin Assignment ......................8 2.2.1 Transmitter (Male) ........................ 8 2.2.2 Receiver (Female) ........................8 2.3 Mechanical Specifications ......................9 2.3.1 Case Dimensions ........................9 2.3.2 Optical Cable Info ........................ 10 www.avenview.com... -
Page 3: Section 1: Getting Started
Removal, installation, and set-up service charges. Safety Instructions The Avenview FO-DP-XX-MM, DisplayPort Extender System over Fiber Optic, has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipment’s, the FO-DP-XX-MM should be used with care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 4: Regulatory Notices Federal Communications Commission (Fcc)
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. Introduction Avenview FO-DP-XX-MM Series with fiber optic cable system lets you extend DisplayPort digital signal up to 65 meters (210 feet) at WQXGA (2560x1600) resolution. High Speed and long distance transmission by Optical fiber Compatible with DisplayPort standard v1.1a... -
Page 5: Before Installation
Use the DC power adapter with correct specifications. If inappropriate power supply is used then it may cause a fire. Do not twist or pull by force ends of the optical cable. It can cause malfunction. www.avenview.com... -
Page 6: Installation
Installation Avenview FO-DP-XX-MM is composed of a Transmitter converting the graphic signal of a computer to optical and Optical Fiber propagating the optical signal and Receiver supplying electrical signal to monitor converted from the optical signal to electrical signal. The Transmitter should be connected to computer/media player DisplayPort connector and the Receiver should be connected to a monitor/TV with DisplayPort connector. -
Page 7: Section 2: Specifications
TX DC Common Mode VTX-DC-CM TX AC Common Mode VTX-AC-CM Transmitter (Source) module of Model DPM includes 4 channel VCSEL (Vertical Surface Emitting Laser Diode) with 850 nm invisible laser radiation. Transmitter (Source) module of DPM is Class 1 Laser Product. www.avenview.com... -
Page 8: Receiver Module
ML-Lane2(p) ML_Lane2(n) ML_Lane3(p) ML_Lane3(n) CONFIG1 CONFIG2 AUX_CH(p) AUX_CH(n) Hot Plug Detect Return No Connect(DP_PWR) 2.2.2 Receiver (Female) Pin Name Pin Name ML_Lane3(n) ML_Lane3(p) ML_Lane2(n) ML-Lane2(p) ML-Lane1(n) ML_Lane1(p) ML_Lane0(n) ML_Lane0(p) CONFIG1 CONFIG2 AUX_CH(p) AUX_CH(n) Hot Plug Detect Return No Connect(DP_PWR) www.avenview.com... -
Page 9: Mechanical Specifications
2.3 Mechanical Specifications 2.3.1 Case Dimensions www.avenview.com... -
Page 10: Optical Cable Info
A helically Cable Outer Diameter 7.40 ± 0.20 Jacket Color Black Fiber Cable Characteristics Item Spec Unit Condition Storage Temperature -20 ~ 70 °C Spooled Operational Test 0 ~ 50 °C Max. Tensile Load Min. Radius Bend Crush Resistance N/50mm www.avenview.com... - Page 11 Disclaimer While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of...
