- Page 1 User’s manual Fully automatic washing machine This manual is for HWM65-918P Please read this manual carefully before using. Retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS Names of the parts Safety precautions Installation and adjustment Preparation before washing Put in the laundries Usage of the detergent Use the operation buttons Finish washing Disposal after washing Trouble-shooting Answer to question Packing list Specification the back cover... -
Page 3: Names Of The Parts
Names of the parts Top lid Control panel seat Inner tub Screw cover(left) Lint filter Cabinet Liquid handle whitener inlet Control panel film Pulsator Drain hose Fixed leg Cabinet Base frame Adjustable leg Notes: All illustrations in this Manual are given for reference only. Your products and accessories may show differences from these illustrations due to our continuous improvement. -
Page 4: Safety Precautions
Safety precautions The washing machine must be positioned Please plug the power plug on special so that the plug is accessible .Be sure to receptacle.Be sure to use three-pins pull the plug off and close the water faucet power receptacle .Ensure that the in following cases:power failure,delivering earthing terminal of the power receptacle the machine ,setting the machine idle... - Page 5 Safety precautions Do not decompose, repair or alter the Do not stretch hands into the working machine. It is dangerous even if the machine by yourself. rotation is slow. Take special care of the children. Do not put any hot or heavy items (such Do not wash laundries with volatile as the kettle with hot water ) on the materials (such as thinner, petrol etc.)
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the mannual. It is very important to your security and correct operating the machine. Install the bottom plate Insert the bottom plate to the pedestal from the front to Screw the back and the two fasteners to the opposite holes, then Front... -
Page 7: Install The Water Inlet Hose
Install the water inlet hose 1.Attach the water inlet hoses to water faucet . Using pliers,tighten the coupling . (As figuer 1) the water faucet NOTE:please check if the connection of the water inlet pipe is proper 2. Connect the other end to the water inlet valve . ( As figure 2) The water inlet hose Jointer of the water inlet hose... -
Page 8: Preparation Before Washing
1 Preparation before washing Preparation before washing 1.Connect the water inlet hose. Open the water faucet. 2.Confirm that the washing machine is earthed reliably. Then insert the power plug into the receptacle. The earth terminal shall not link to gas pipeline and faucet water pipeline. -
Page 9: Put In The Laundries
2 Put in the laundries The capacity of washing and spinning of he machine refer to the largest weight of the standard laundries under dry condition that can be washed or spinned in one time. One time washing quantity shall be lower than the rated capacity. -
Page 10: Use The Operation Buttons
4 Use the operation buttons a Description of the function of buttons Mode and meaning of the indicators On: indicate the program about to run,or indicate the selected mode or indicate the water level Flashing: indicate the running program, or indicate the selected mode or indicate the water level Child lock function Push and hold the“Rinse”button and“Water level”button, then push down the power on/off button. - Page 11 Remaining Times Mins Mins Memory Normal Time Mins Rinse Standard Mins Times Strong Mins Times Mins Wool Soft Power Delay Time ON/OFF Quick Mins Mins Tub Dry Reserve Water Spin Delay Pause Rinse Wash Water Program level “Reserve Water” button “Wash”“Rinse”“Spin”bottons Press “Reserve Water”...
-
Page 12: Finish Washing
Attention Even there's no water in the tub, the spinning will start after a certain period. Wash and spin after putting the damageable clothes into tuck net, to avoid scathe. Wash the laundries that are prone to lose colors separately from other laundries. -
Page 13: Disposal After Washing
Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. The lint filter must be used during washing. Clean the detergent box and set it on It must be cleaned in time after each using. -
Page 14: Trouble-Shooting Answer To Question
Trouble-shooting · Answer to question (If there’s breakdown, please pull off the power plug before checking) The following phenomenon are not breakdowns sometimes. Please con rm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company. -
Page 15: Packing List
Common phenomena Phenomena Explanation The spinning is intermittent when it starts. Balance the laundries to avoid slanting. Push the “spin” button to select “Spin”, but it doesn’t The program is setting the drain time. Some time is work. needed before it starts spinning. There may be some water flowing out of the drain hose It is the water remained in the factory inspection of in the first use of the machine. - Page 16 Specification 220V /50Hz Rated voltage/frequency 1/14L 2/18L 3/22L 4/26L5/30L Water level/Water quantity(about) 6/34L 7/38L 8/43L 9/47L 10/52L Injection pressure(MPa) 0.03 - 1.0 Washing/spinning capacity(kg) 6.5/6.5...
