- Page 1 Double Drive Fully Automatic Washing Machine User’s manual HWM65-1128NZP HWM75-1128NZP Please read this manual carefully before using. Retain it for future reference.
-
Page 2: Table Of Contents
Contents Names of the parts ..............3 Safety precautions ..............4 Installation and adjustment ............6 Install the water inlet hose ............9 Preparation before washing ............11 Put in the laundries ..............12 Use the operation buttons ............13 Disposal after washing ............17 Trouble-shooting answer to question ........18 Packing List ................19 Specifications .................19... -
Page 3: Names Of The Parts
Names of the parts Power cord Top lid component Outer tub cover Back cover Detergent box Filter cover Fixed foot Hook Lint ¿lter Cabinet handle Balance ring Front control board Drain hose Control panel seat Pulsator Base frame Cabinet Adjustable foot label(2 pieces) Adjustable foot Inner cover Water inlet valve... -
Page 4: Safety Precautions
Safety precautions Please plug the plug on special The power cord plug should be convenient receptacle to be pluged in or pluged out with hand with rated voltage. Be sure to use while the washing machine runs normally. singlephase three pins receptacle. Be sure to pull the plug out and close the Ensure the earthing prong of the power water tap when the machine is idle, when... - Page 5 Do not decompose, repair or alter the Do not put hand into the rotating tub. It is machine by yourself. dangerous even if the rotation speed is slow. Take special care of the children. Keep children away from the washing machine to avoid them climbing on.
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the inner cover component 1. Open the top lid of the washing machine. 2. -
Page 7: Usage Of The Drain Hose
Adjust the installation position The largest allowed slope of the shank base of the machine is 2°. The slanting or rough ground will result in unstable running or stoppage of ● Confirm it’s horizontal: the machine. Please adjust it with Hang the lead line to check if following methods: it is horizontal. - Page 8 Remarks: In order to make sure of the correct of installation, it is suggested to change the direction of the drain hose with our company serviceman. HWM65-1128NZP 1.Dismantle the back cover of the washing machine. 2.Press the spring lamination lightly and pull the top...
-
Page 9: Install The Water Inlet Hose
Install the water inlet hose Confirm the water faucet Water tap, not suitable Water tap, suitable Outlet end surface >10mm It is required that the front end shall be longer than 10mm. The outlet end surface of the tap shall be flat and smooth. If not please file it to avoid leakage. - Page 10 Connection between the water inlet hose and the washing machine Nut of the water inlet hose Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before each usage. If it happens please contact our after-sale department immediately.
-
Page 11: Preparation Before Washing
Preparation before washing Preparation before washing Connect the water inlet hose. Confirm that the washing machine is earthed reliably. Then insert the power plug into the receptacle. Do not connect the earth terminal to the gas pipe and tap water pipe. Put down the drain hose. -
Page 12: Put In The Laundries
It is suitable for one time washing to put in reasonable amount of laundries and the laundries can be turned round in washing. Do not select “70L” (for HWM75-1128NZP) or “51L” (for HWM65-1128NZP) water level for laundries less than 1.0kg, so as to avoid splashing of water. -
Page 13: Use The Operation Buttons
Use the operation buttons Description of the function of the buttons (Take example for HWM65-1128NZP) Indicator mode and mea ning Flashing: indicate the running program On: indicate the program about to run,or indicate the selected mode Child lock function The function is intended for children safety and preventing the washing program from accidental changes by children. - Page 14 D “Soak” “Wash”,“Rinse”,“Spin” button Press the “Soak”,“Wash” “Rinse”,“Spin” button to select the desired soak time,wash time, rinse times and spin time from the Normal,Strong,Delicate,Memory and Standard programs. Press “Wash” “Rinse”,“Spin” button can change the process, can not change wash time, rinse times and spin time from the Wool and Silk programs.
- Page 15 H “Reserve Water” button Press “Reserve Water” button to keep rinsing water; When Reserve Water mode is selected, the washing machine will keep rinsing water after each rinsing with buzz and voice indications (for example, if 2nd rinsing is selected, then 2nd rinsing water will be kept; if 1st rinsing and 2nd rinsing are selected at the same time, then 1st and 2nd rinsing water will be both kept).
- Page 16 Before washing, please fold up the laundry as needed, then put the laundry into the inner tub, Àat and neat. These fabrics are not washable: 1. Fabrics that deform when soaked in water; 2. Fabrics that shrink, discolor or go through other exterior changes when soaked in water; 3.
-
Page 17: Disposal After Washing
Disposal after washing ● After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. ● Please first pull off the power plug from the receptacle before cleaning. Clean the detergent box and set it on the control panel seat. -
Page 18: Trouble-Shooting Answer To Question
Trouble-shooting answer to question (If there’s breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes.Please con¿rm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company. -
Page 19: Packing List
Inside the accessory bag component Double Drive Fully Automatic Washing Machine Inside the document bag Speci¿cations HWM75-1128NZP Model No. HWM65-1128NZP 18L, 24L, 30L, 35L, 20L,29L,38L,46L, Water level 54L,60L,65L,70L 41L, 46L, 50L, 54L Water Injection 0.001MPa - 1.0MPa 0.001MPa - 1.0MPa...
