Figure 3. S3000Ahlx Connector And Component Locations - Intel S3000AH - Entry Server Board Motherboard User Manual

A. Video Memory
D. PCIe* x4 (x1 Lane) Slot 3
G. LAN SPI Flash
J. Clock Generator
M. Rear System Fan
P. Processor Fan
S. System Front DIMM Blower
Header
®
V. Intel S3000 MCH
Y. Front System Fan
BB. SATA Port 3
®
EE. Intel 82801 ICH7R
HH. SATA Port 1
KK. BIOS SPI Flash
NN. SMBus Connector
®
Intel Server Board S3000AH User's Guide
B. PCI 32/33 Slot 2
®
E. Intel 82541PI Lan Controller
®
H. Intel 82573E LAN Controller
K. Back Panel Connectors
N. 2x4 Power Connector
Q. DIMM Sockets (2B and 2A)
T. System Front Processor Blower
Header
W. Battery
Z. Floppy Connector
CC. SMSC* SCH5027 Super I/O
FF. Front Panel Connector
II. Clear CMOS Jumper
LL. External USB Connector
®
OO. Intel 6702 PXH-V Controller

Figure 3. S3000AHLX Connector and Component Locations

C. ATI* ES1000 Video Controller
F. PCI-X* 64/133 Slot 5
®
I. Intel Adaptive Slot, Slot 6
L. Diagnostic POST LEDs
O. Processor Socket
R. DIMM Sockets (1B and 1A)
U. Chassis Intrusion Header
X. 2x12 Main Power Connector
AA. PATA IDE Connector
DD. SATA Port 2
GG. System Maintenance Mode
Jumper
JJ. SATA Port 0
MM. SPI/FWH Select Header
PP. PCI 32/33 Slot 1
7
