Owner's Manual
Network Set-up
and Operation
Wired and Wireless Setting
Projector Set-up and Operation
Network Capture
Network Viewer
Moderator Function
This is the manual for the Network function.
Read this manual thoroughly to operate the Network function.
First, read the owner's manual of the projector to understand the basic operation of the
projector and the safety instructions.
The safety instructions in the owner's manuals should be followed strictly.

Advertisement

   Also See for Sanyo XU88 - PLC XGA LCD Projector

   Related Manuals for Sanyo XU88 - PLC XGA LCD Projector

   Summary of Contents for Sanyo XU88 - PLC XGA LCD Projector

  • Page 1: Network Capture

    Owner’s Manual Network Set-up and Operation Wired and Wireless Setting Projector Set-up and Operation Network Capture Network Viewer Moderator Function This is the manual for the Network function. Read this manual thoroughly to operate the Network function. First, read the owner's manual of the projector to understand the basic operation of the projector and the safety instructions.

  • Page 2: Compliance

    Model Number : QXXAVC922---P Trade Name : Sanyo Responsible party : SANYO FISHER COMPANY Address : 21605 Plummer Street, Chatsworth, California 91311 Telephone No. : (818)998-7322 This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions: (1) the device may not cause interference, and (2) the device must accept any interference, including interference that may cause undesired operation of this device.

  • Page 3

    övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. [Swedish] Islenska Hér með lýsir SANYO Electric Co., Ltd. yfir því að (QXXAVC922---P) er í samræmi við grunnkröfur og [Icelandic] aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC. Norsk SANYO Electric Co., Ltd.

  • Page 4: Safety Instructions

    Incorrect installation may cause fire or other accidents. CAUTION IN USING NETWORK FUNCTION ● SANYO Electric Co., Ltd. assumes no responsibility for the loss or damage of data, or damage of the computer caused by using this projector. Making back-up copies of valuable data in your computer is recommended.

  • Page 5: Table Of Contents

    Table of contents Compliance .................................2 Safety instructions ............................4 Table of contents ...............................5 Operating environment and configuration .....................7 Required operating environment for computers ................7 Network specifications of the projector ....................8 1. About LAN functions ............9 LAN functions and the features ........................10 Image projecting system via LAN ......................10 An example of the connection .........................11 LAN connection modes ..........................12...

  • Page 6

    How to use the setting page ........................46 Initial setting ..............................48 Network configuration ..........................51 Configuring wireless LAN setting and security setting..............53 E-mail setting ..............................55 SNMP setting ..............................59 7. Controlling the projector ..........63 Power control and status check .......................64 Controls ................................66 PC adjustment ..............................70 Setting up the projector ..........................71 Timer setting ..............................74 Projector information ...........................77...

  • Page 7: Operating Environment And Configuration

    Operating environment and configuration Required operating environment for computers When operating the projector via the networks, computers should meet the operating environment below. Microsoft Windows 2000 or Microsoft Windows XP or Microsoft Windows Vista (32bit version) Pentium 3 ; 1GHz or higher (more than 2GHz is recommended) for Windows 2000 or Windows XP Pentium 4 ;...

  • Page 8: Network Specifications Of The Projector

    Network specifications of the projector LAN Terminal Data communication speed 100Base-TX (100Mbps)/10Base-T (10Mbps) Protocol TCP/IP Wireless LAN Interface IEEE802.11b/g AdHoc, Communication Mode Infrastructure 1/2/5.5/11Mbps (IEEE802.11b) Data Transfer Speed 6/9/12/18/24/36/48/54Mbps (IEEE802.11g) Wireless Frequency (Channel) 2412MHz–2462MHz (CH1–CH11) IEEE802.11g OFDM 54/4Mbps 64QAM, 36/24Mbps 16QAM, 18/12Mbps Modulation Form QRSK, 9/6Mbps BPSK IEEE802.11b DSSS...

  • Page 9: About Lan Functions

    Chapter Chapter 1. About LAN functions This chapter describes the features, the mechanism, and connection procedures of the LAN.

  • Page 10: Lan Functions And The Features

    Chapter 1 About LAN functions LAN functions and the features This product is loaded with a LAN network function which enables you to project an image on the computer through a projector via Network with dedicated software. With the software, you can also manipulate the projecting image and the projector. This software has functions below and you can use the projector under various network environments to meet the wide-ranging needs of the operation.

  • Page 11: An Example Of The Connection

    An example of the connection An example of the connection The illustration below shows an example of the projection via the LAN. You can project the image on Computer (1) (Wired LAN connection), or Computer (2) (Wireless LAN connection) through the selected projector . Computer (2) Computer (1) Access point...

  • Page 12: Lan Connection Modes

    Chapter 1 About LAN functions LAN connection modes Connection modes differ depending on the LAN and computer environments. Connect appropriately for each environment. Wireless LAN, Infrastructure Communication Mode ■ Communicate over an access point between Wired LAN equipment and Wireless LAN equipment. Or, communicate over an access point among multiple Wireless LAN equipment.

  • Page 13

    LAN connection modes Wired LAN Communication Mode ■ Communicate via the LAN line. Computer(1) Computer(2) Computer (3) Operate the computer mouse with the remote control. ✳ When the projector’s remote control employs mouse operating function, you can operate the computer by the remote control which is provided with the projector. To use the remote control, point to the projector.

  • Page 14

    Chapter 1 About LAN functions...

  • Page 15: Setup Procedures

    Chapter Chapter 2. Setup procedures This chapter describes how to install the Network Capture 4 software and how to set up the networks.

  • Page 16

    Chapter 2 Setup procedures To use the projector via the networks, follow the setup procedures below. STEP 1 Install the software on computers. Install the software recorded in CD-ROM on each computer which will be operated. Read following pages of this chapter to install. Select Wired LAN or Wireless LAN then connect the STEP 2 LAN and set the configuration.

  • Page 17: Installing The Software

    Installing the software Installing the software It is required to install the software into your computer to use the Network Capture function . Please install the software as follows. Note: To install the software into the computer with Windows 2000, Windows XP or Windows Vista, you should logon as administrator.

  • Page 18

    Chapter 2 Setup procedures As the "License Agreement" will appear, read contents carefully and click Yes button if you agree to the license agreement to proceed with installing. During the installation, following window may appear, click Continue Anyway button. Click Finish to complete the installation.

  • Page 19: Installed Software

    Installing the software Installed software The following 3 softwares are installed on your computer. Network Capture 4: ● Captures the displayed image and the sound of the computer and serves them to the projector via the network. Network Viewer 4 (File Converter 1): ●...

  • Page 20: File Converter 2 Installation

    Chapter 2 Setup procedures File Converter 2 installation Set the supplied Network Viewer & Capture 4 CD-ROM into the CD-ROM drive of your computer. SetupDrv.exe Double click icon in the "Driver" folder in the CD-ROM. Select "English [United States]" from the pull-down menu on the language selection window and then Install click...

  • Page 21: Names And Functions Of The Operation Screen

    Chapter Chapter 3. Names and functions of the operation screen This chapter describes the functions of each part of the operation screen.

  • Page 22: Network Connection Standby Display

    Chapter 3 Names and functions of the operating screen Network connection standby display Turn on the projector and select either “Wired” or “Wireless” from the input menu of the projector. The “Please wait... ” message will be displayed on the screen. After short time, the network connection standby display screen will appear as below.

  • Page 23: Network Capture 4 Window

    Network Capture 4 window Network Capture 4 window This software is to project the computer screen via the networks. Select "All Programs" from the start menu --> Network Viewer & Capture 4" --> "Network Capture 4", then following screen will appear. Then the program will start. Parts Names and Functions of the Screen Search PJ button Search the projector connected to the networks.

  • Page 24

    Chapter 3 Names and functions of the operating screen r Start communication button Enter the Communication mode, and then , the capture edit window starts. The selected projector shows the capture edit window. t Start real time capture button Capture (Project) the computer screen in real time. After the execution of "Start real time capture", the application window disappears.

  • Page 25: Wired Lan Configurations

    Chapter Chapter 4. Wired LAN configurations This chapter describes the preparation for Wired LAN setting with projectors and how to set the LAN environment.

  • Page 26: Connecting To The Lan Line

    Chapter 4 Wired LAN configurations Setting procedures and contents differ depending on the LAN installation location. When installing, consult your system administrator to set up the LAN appropriately. Connecting to the LAN line Connect the LAN cable to the LAN connection terminal of the projector. LINK/ACT Lamp (Orange) Light or blink orange when LAN Connection...

  • Page 27

    Network environment setting 4. Press SELECT button. LAN setting screen will appear and selected LAN settings will be displayed. Adjust each item to the setting environment. Consult your system administrator about the detailed settings. Adjust the figures with the Point ed buttons and move among the items with the Point 7 8 buttons.

  • Page 28: Confirming The Operation

    Chapter 4 Wired LAN configurations Confirming the operation Confirm that the projector has connected to the LAN properly. 1. Activate “Network Capture 4” which is installed into the computer connected to the LAN . 2. After “Searching projector” message appears, the name of the projector* appears on the Network Projector List, then the network setting has completed properly.

  • Page 29

    Confirming the operation When set up the projector in the location separated by the router and the segment is different; Projector will not be found nor displayed. In that case, the projector needs to be searched directly by the IP address. 1.

  • Page 30: Network Pin Code

    Chapter 4 Wired LAN configurations Network PIN code The Network PIN code is to restrict the access from the networks to the projector. After setting the Network PIN code, you need to enter it to operate the projector via the networks. 1.

  • Page 31: Wired Lan Factory Default Settings

    Wired LAN factory default settings Wired LAN factory default settings SELECTED LAN Parameter LAN1 LAN2 LAN3 IP ADDRESS 169.254.100.100 192.168.100.100 192.168.100.100 SUBNET MASK 255.255.0.0 255.255.255.0 255.255.255.0 GATEWAY ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255 DNS ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255 DHCP IP CONFIGURATION MANUAL MANUAL...

  • Page 32

    Chapter 4 Wired LAN configurations...

  • Page 33: Wireless Lan Configurations

    Chapter Chapter 5. Wireless LAN configurations This chapter describes the preparation for Wireless LAN setting with projectors and how to set the LAN environment. This projector contains the Wireless LAN module. The setting procedures and configurations differ depending on the LAN installation location. Consult your system administrator for installation and set the LAN appropriately.

  • Page 34: Setting The Network Environment

    Chapter 5 Wireless LAN configurations Setting the network environment The projector contains the Wireless LAN adapter. Set the Wireless LAN network through the projector menu. Detailed network settings will be made with browser. Refer to “6. Basic setting and operation”. ➔"Network configuration"...

  • Page 35

    Setting the network environment 4. Press SELECT button. LAN setting screen will appear and the selected LAN settings will be displayed. Adjust each item to the setting environment. Consult your system administrator for the detailed settings. Adjust the figures with the Point ed buttons and move among the items with the Point 7 8 buttons.

  • Page 36: Configuring Security With The Projector

    Chapter 5 Wireless LAN configurations Configuring security with the projector Configure security with the projector by following the steps below. After configuring the network in “5. Wireless LAN Configurations” (p.33-42), select “Next” in the LAN setting screen and press SELECT button. The security configuration screen appears. Refer to “6. Basic setting and operation”...

  • Page 37: Use Of Security Type "wep

    Configuring security with the projector Use of security type "WEP" 1. Use the Point ed buttons to select "WEP" security type. 2. Select “WEP Key index”. Use the Point ed buttons to choose the HEX or ASCII key. The four (#1–#4) kinds of WEP keys can be configured.

  • Page 38

    Chapter 5 Wireless LAN configurations Use of security type "WPA-PSK", "PWA2-PSK" 1. Use the Point ed buttons to select "WPA-PSK" security type. WEP security setting fields are grayed out. WPA-PSK configuration screen 2. Select “Next” and press SELECT button. The PSK key confirmation screen appears. 3.

  • Page 39: Easy Wireless Setting

    Easy wireless setting Easy wireless setting With this setting, you do not need any complicated LAN setting procedures. The network type will be AdHoc mode. CAUTION: This function can be used only when logged in by Administrative right with Windows XP and Windows Vista, and cannot be used with Windows 2000. Windows XP should be Service Pack 1 or later version.

  • Page 40: Network Pin Code

    Chapter 5 Wireless LAN configurations Computer environment and Wireless LAN connection; Wireless LAN with Wireless Easy setting connection will be made via AdHoc mode. For setting contents, refer to “Wireless LAN factory default settings” (p.42). With the Easy setting, computer’s LAN environment setting will be switched to the setup environment. Because of that, the LAN cannot work for the other operation while using “Network Capture 4”.

  • Page 41: Wireless Indicator Display

    WIRELESS indicator display WIRELESS indicator display When the wireless LAN configuration is set up correctly and the wireless communication is established with the access-point or the computer in the network, the WIRELESS indicator on the top panel lights up. While the projector scans the equipment in the network, the WIRELESS indicator blinks. WIRELESS indicator...

  • Page 42: Wireless Lan Factory Default Settings

    Chapter 5 Wireless LAN configurations Wireless LAN factory default settings Factory default settings for LAN4, LAN5, and SIMPLE as follows. Selected LAN Setting Items LAN4 LAN5 SIMPLE IP ADDRESS 169.254.100.100 192.168.100.100 169.254. * . * SUBNETMASK 255.255.0.0 255.255.255.0 255.255.0.0 GATEWAY ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255...

  • Page 43: Basic Setting And Operation

    Chapter 6. Basic setting and operation Describes basic operation and settings below by using the web browser. • Initial setting Setup the basic setting such as Projector name, Net- work PIN code, Time setting, etc. • Network setting Configure Wired/Wireless LAN environment. •...

  • Page 44: Starting Up The Browser

    Chapter 6 Basic setting and operation Starting up the Browser 1. Turn on the projector. 2. Start up the Network Capture 4. The Network Capture 4 searches projectors in the network and lists up the IP address or projector name of the projector on the Network Projector List. 3.

  • Page 45: Display Of Main Setting Page

    Starting up the browser Display of main setting page The following main setting page will be displayed depending on your display mode selection. Perform various kinds of settings through this page. Click on the menus to display the control and setting pages.

  • Page 46: How To Use The Setting Page

    Chapter 6 Basic setting and operation x Main setting page in the Light Mode display Sub menu tab Page numbers Setting page Returns to the display mode selec- Returns to main menu tion page. Main menu ✐ The blank page appears if your PDA does not provide a Adobe Flash Player.

  • Page 47

    How to use the setting page Type of the setting pallet Text box setting Enter the number or text and then click Set button. Change a value with s or t button and then click Set but- ton. The value changes quickly when s or t button is kept pressing.

  • Page 48: Initial Setting

    Chapter 6 Basic setting and operation Initial setting After installing the projector, perform the following basic initial setting. Click Initial Setting on the main menu to display the initial setting page. Item Description Language ....Switches display language on the setting page. English or Japanese.

  • Page 49: Network Pin Code Setting

    Initial setting Network PIN code setting This is to set the Network PIN code to restrict the access from an unau- thorized person through the network. Enter a 4-digit number as the Network PIN code onto the text box and click Set button.

  • Page 50: Date And Time Setting

    Chapter 6 Basic setting and operation Item Description NTP address ..... Enter the address of NTP server. Please consult your network administrator for setting up of the NTP server. Temperature .... Switches display temperature unit Centigrade or Fahren- heit AUTO Time setting .....

  • Page 51: Network Configuration

    Network configuration Network configuration Click Network on the main menu. The following setting page is displayed. Set up the projector's network environment on this Setting sub menu. Setting of LAN 1. Select a type of LAN from Change setting pull down menu. LAN1(Wired) LAN2(Wired) LAN3(Wired)

  • Page 52

    Chapter 6 Basic setting and operation 2. Select either "Manual" or "DHCP" from IP configuration pull down menu. When "DHCP" is selected, IP address, Subnet mask, Default Gateway, DNS are automatically configured by DHCP function. Only the DNS address allows you to set up manually if the DNS address information is not provided on your DHCP server.

  • Page 53: Configuring Wireless Lan Setting And Security Setting

    Configuring wireless LAN setting and security setting Configuring wireless LAN setting and security setting Configure the wireless LAN setting and security setting for LAN4 and LAN5. Configuring wireless LAN setting 1. Click page [2] of setting pages. Following wireless LAN setting can be done. After completing the configuration, press Set button.

  • Page 54

    Chapter 6 Basic setting and operation Configuring wireless LAN security setting Click page [3] of setting pages. Following wireless LAN security setting can be done. After completing the configuration, press Set button. Item Description Network security ...Sets the type of encryption. Following types are available. WEP64(40)bit Open WEP64(40)bit Share WEP128(104)bit Open...

  • Page 55: E-mail Setting

    E-mail setting E-mail setting This product has an E-mail function which can send an alert message to users or an administrator if it detects an abnormality on the projector or run out of the life span of the lamp. Click E-mail Setting on the main menu and follow the below steps. Item Description SMTP server*...

  • Page 56

    Chapter 6 Basic setting and operation Registering and deleting E-mail addresses Click "Add e-mail address" and type the e-mail address onto the text box and click Set button. To check the registered addresses, click Check/Delete sub menu tab. The addresses are listed as the figure on the right.

  • Page 57

    E-mail setting Examples: Type and contents of alert mail When the projector has an abnormality, the following alert messages are sent to the registered E-mail address depending on your selected condition. Administrator or user can take an efficient action quickly by receiving this message.

  • Page 58

    Chapter 6 Basic setting and operation ● When PJ lamp replacement time is reached: TITLE: Message from projector 10-03-2007 00:59 Projector Model Name: model name TCP/IP: 192.168.1.201 Projector Name: Proj05 It sends you following message. *The PJ lamp replace time is reached. ✐...

  • Page 59: Snmp Setting

    SNMP setting SNMP setting This product provides a SNMP (Simple Network Management Protocol) agent function. The SNMP consists of a manager and agents. The group which exchanges information with SNMP is called "Community". There are two access modes in a community, Refer (read only) and Set (read- write).

  • Page 60

    Chapter 6 Basic setting and operation Trap Item Description Community name ... Enter community name to send "Trap". Default name is "public". Trap address .... Enter IP address of the SNMP manager computer to receive "Trap". Up to 10 address can be registered. ✐...

  • Page 61

    SNMP setting Trap option Trap option setting Tick the check boxes in front of the condition item to send the trap. ✐ Click button if you tick or un-tick the check box on a page. [1]–––––––––––––––––––––––––––––––––– When PJ lamp is off. When PJ lamp replacement time is reached.

  • Page 62

    Chapter 6 Basic setting and operation...

  • Page 63: Controlling The Projector

    Chapter 7. Controlling the projector Describes controlling and setting of the projector by us- ing the web browser.

  • Page 64: Power Control And Status Check

    Chapter 7 Controlling the projector Power control and status check Click Power & Status on the main menu. The control page will be displayed. By clicking ON or Standby button on the page, the power of the projector can be con- trolled.

  • Page 65

    Power control and status check About projector condition Status Description Normal ..............Projector is operating normally. Power management in operation ......Power management is operating Lamp failure............Lamp failure is occurring Abnormal Temperature ........The temperature of the projector became too high Cooling down after abnormal Temp. Projector detects abnormal temp.

  • Page 66: Controls

    Chapter 7 Controlling the projector Controls Click Control on the main menu. The setting method differs depending on the con- tents of the page. Click on the page number to change pages and select desired set- ting items. ✐ Please see the owner's manual of the projector to have the further information of each control item.

  • Page 67

    Controls System This function is to select the system of signal input to the projector. The available system mode are listed on the pull-down menu button according to the input signal. Select a system and then click Set button. Available selection at the RGB(PC analog) input Item Description XGA1 ......

  • Page 68: Image Adjustment

    Chapter 7 Controlling the projector Image adjustment This function is to adjust the projected picture image and save the image mode. To store the adjusted value, click Store button, and to load the adjusted value, click Load button. Item Description Contrast.....Adjusts picture contrast Brightness ....Adjusts picture brightness Color ......Adjusts picture color saturation...

  • Page 69

    Controls Sound This function is to adjust the sound of the projector. The values in the text box represent the current control value or status. Item Description Volume ...... Adjusts the sound volume from the speakers. Mute ......Suppresses the sound.

  • Page 70: Pc Adjustment

    Chapter 7 Controlling the projector PC adjustment Click PC Adj. on the main menu. This function is to adjust the signal from the computer connected to the projector to obtain the proper picture image on the screen. Item Description Current mode ... Displays a current mode like VGA, SVGA, XGA, SXGA, UXGA, WXGA, etc.

  • Page 71: Setting Up The Projector

    Setting up the projector Setting up the projector Click Setting on the main menu. This function is to set up the projector. Select the sub menu [Screen setting], [Setting 1] or , [Setting 2] and then set up each setting. Item Description Screen ......

  • Page 72

    Chapter 7 Controlling the projector Item Description Language ....Sets the language display of projector's on-screen display menu. Auto setup ....Executes the Auto PC Adj, and Auto Keystone function Start below according to the each setting after clicking button. Auto PC Adj.

  • Page 73

    Setting up the projector Item Description Key lock ..... Sets the prohibition of controls either Projector or Remote control. Fan ......Sets the cooling options after turning off. L1 Normal cooling L2 Silent cooling Fan control ....Sets the fan control speed. Status ....Indicates the current fan mode.

  • Page 74: Timer Setting

    Chapter 7 Controlling the projector Timer setting This page is to set the timer to turn the projector off or on at a programmed day/date and time. Follow the steps below for setting. Click Timer on the main menu. "---" will appear on the cur- Present time set on the rent time when the time is projector...

  • Page 75: Check The Timer Events

    Timer setting Set an execute time Type the time with (Hour:Minute) and 24 hours format. Ex.: Type [18:25] if you specify [PM 6 o’clock and 25 minutes]. Select an event action Select an event action from the pull-down menu. Event Action ON ........

  • Page 76

    Chapter 7 Controlling the projector Notes on timer setting ✐ Up to 10 timer events can be registered. Timer events always operate according to the next valid event depending on the projector's power status. In the example below, event 3 turns on the projector so next event 4 (also turning on projector) will not be effective because the projector is already turned on.

  • Page 77: Projector Information

    Projector information Projector information This page is to display the basic information of the projector status. Click Information on the main menu. Items Description Input ......Displays selected input and source. System .......Displays selected signal system. Signal ......Input signal status Screen ......Displays screen mode. Lamp status ....

  • Page 78

    Chapter 7 Controlling the projector Indication of the lamp status Icon display/background Status Lamp on (Normal) White-Yellow/Blue Lamp on (Lamp is being used over a specified use time, replace lamp immedi- White-Yellow/Red ately) Lamp off (Normal) Gray/Blue Lamp off (Lamp is being used over a specified use time, replace lamp immedi- Gray/Red ately) Lamp failure (Lamp failure, check the lamp condition)

  • Page 79: Multi-control

    Multi-control Multi-control Controlling and setting the multi-projectors When you install multiple projectors in the network, you can control and set up them together. Click Multi Control on the main menu to display the control page. Note: To control the multiple projectors, each projector must be set the same Network PIN code. Example of multi control Select Input2 for PJ1 to PJ4.

  • Page 80: Start/stop The Multi Control

    Chapter 7 Controlling the projector Start/stop the multi control Switches on and off the multi-control function To start or stop controlling the multi-projectors, click Multi con- trol setting menu and select ON or OFF. Multi control setting OFF ..Stops multi control function ON ....

  • Page 81: Register The Projector

    Multi-control Register the projector To use the multi control function, register the IP address of the projector you intend to control. Click PJ registration sub menu tab and set the IP address, Memo and Multi control item, then click Set button. Items Description IP address ....Enter IP address of the projector to control...

  • Page 82: Change The Mode Of The Registered Projector

    Chapter 7 Controlling the projector Change the mode of the registered projector To change the mode of the registered projector, select a mode with the pull-down menu button under the IP address of the target projector and then click Set button. Mode Operation Control .......

  • Page 83: Controlling All Together

    Multi-control Check & Change page in the light mode Following functions in the "Check & Change" page are not avail- able in the light mode. - Changing the control mode. - Deleting the registered IP address - Indicating the each status - Indicating the each memo This indicates that the mode is "VisualControl".

  • Page 84: Viewer Auto Setting All Together

    Chapter 7 Controlling the projector Viewer auto setting all together "Viewer auto display" can be set all together. Set "ON" the multi control setting and select [3] Auto display from Viewer sub menu (selected by ‘Multi-control’ - “Network Viewer” menu). Set the dis- play time periods and repeat times for the auto image display.

  • Page 85: Network Capture Functions

    Chapter 8. Network capture functions Network Capture is a function to display the screen im- age and reproduce the sound of the computer via the network. - Real Time Capture - Network Communication - Moderator Function...

  • Page 86: About Network Capture Function

    Chapter 8 Network capture functions About Network Capture function The Network Capture is a function to display the screen image and reproduce the sound of the computer which has a Network Capture 4 software by the projector through the network. This function has 3 kinds of mode as below.

  • Page 87: Commands On The Task Bar

    About Network Capture function Commands on the task bar When the Network Viewer & Capture 4 icon on the task bar is clicked, the popup menu will appear. It provides according to the operating modes as shown in the table below. Network Capture activating Parameter set up...

  • Page 88: Parameter Set Up

    Chapter 8 Network capture functions Parameter set up Click Parameter set up button and setup the parameters on the Parameter setup window. Items Description Connection setting Capture port ....Sets the capture port no. on the projector. Default is 9000. Pincode ......

  • Page 89: Using The Real Time Capture

    Using the Real Time Capture Using the Real Time Capture This is a function to project the screen image and reproduce the sound of the computer by the projec- tor in real time. The captured image projected by the projector can be selected from the computer, web browser and the projector respectively.

  • Page 90: Control By The Computer

    Chapter 8 Network capture functions [1] Control by the computer * PC provides the Network Capture. Project this screen image with PJ2. Capture * Start capturing from the PC1. Select input mode to "Network" previously. Start up Network Capture 4. Select the projector(s) listed on the projector list on the application window and click Start real time capture.

  • Page 91: Control By The Web Browser

    Using the real time capture [2] Control by the web browser * PC provides the Network Capture. Capture * Start capturing of the PC1 from the Project a screen PC5. image of PC1 with PJ2. Select "Network" as input mode previously. Access to the control page of the projector by using the web browser.

  • Page 92

    Chapter 8 Network capture functions [3] Control by the projector * Start capturing of the PC1 from the projector PJ2. * PC provides the Network Capture. Capture Project a screen image of PC1 with PJ2. Select "Network" as input mode previously. Select "Network Capture"...

  • Page 93: From The Projector

    Using the real time capture Example of advanced use Displays the presentation data stored in the computer by using the wireless mouse function from the projector. Start capturing of the computer PC1 by using the projector. Select “Network Capture” icon from the menu and select "PC1" and then select "Connect" (+ p.92). =>...

  • Page 94: Using The Network Communication

    Chapter 8 Network capture functions Using the Network Communication This Network Communication is to communicate by sharing the captured image of a computer with multiple computers and a projector. Users can draw the text and figure on the captured image by using a drawing tool.

  • Page 95: Settings Before Using The Network Communication

    Using the Network Communication Settings before using the Network Communication To use the Network Communication, the capture setting of the projector must be set either [1] or [2] as described below. [1] Projector searches all the available subject computers in the network automatically. [2] Subject computers are registered to the projector.

  • Page 96: Description Of Capture Editing Window

    Chapter 8 Network capture functions Description of capture editing window Start Network Capture 4 and select the projector(s) on the projector list on the application window and click Communication Start button. The application window will disappear and the capture editing win- dow will appear on the computer screen as below.

  • Page 97

    Using the Network Communication Tool bar button names The following commands are assigned to the tool bar buttons. For each operation, refer to the descrip- tion of the item "Menu tree". Command Tool Save Terminate Communication Bar of Main PC communication Capture Authority...

  • Page 98: How To Use The Network Communication

    Chapter 8 Network capture functions How to use the Network communication Start the communication Display an image on the computer screen. Start Network Capture 4. The application window appears and the projectors in the network are listed. Select the projector(s) and click Start Communication button. The application window disappears and the capture editing window with a captured image appears on the computer screen.

  • Page 99: Edit Capture Image

    How to use the Network communication Edit capture image Drawing figures Click " :Pencil" button on the form tool bar. Select its attribute (shape, width, color and translucence) from the form and attribute tool bar. Drag a mouse pointer on the screen image to draw the figure. Erase drawn objects Click "...

  • Page 100

    Chapter 8 Network capture functions Drawing letter Click " :Letter frame" button on the form tool bar. Select a color of text with color tool bar. Drag a mouse pointer on the screen image to specify the area of the letter frame. The letter input dialog window will appear.

  • Page 101: Network Communication Operation And Change Of State

    Network Communication operation and change of state Network Communication operation and change of state Network Communication can be used under the environment which one or more computers are con- nected to the projector via the network. Preparation Start up the Network Capture 4 software on the subject computer. Set standby the projector or turn it on.

  • Page 102: Executing The Forcing Mode

    Chapter 8 Network capture functions Executing the forcing mode The network capture setting of the web page provides a forcing executing command. This command executes the release of authority or ending the communication forcibly. This is useful when the other subject PC keeps an authority all the time, or when the condition of the communication is not stable.

  • Page 103: Moderator Function

    Moderator function Moderator function This function is useful for a moderator or a teacher to conduct a meeting or a class, where all the par- ticipants including the moderator (teacher) are assigned a computer, to project images from each par- ticipant’s computer.

  • Page 104: Preparation For Using The Moderator Function

    Chapter 8 Network capture functions Preparation for using the moderator function First, follow the procedure in “2. Setup Procedure” ➔ “Step 1–3” (p.16) and confirm that the setting status is set as written below. • Network Capture 4 is installed on the moderator's computer and each client’s computer and each computer image can be projected.

  • Page 105: Using The Moderator Function

    Moderator function Description of application window Column Description Status ......Indicates the projector's condition. On real time, On One-shot capture, On Standby, In Moderator mode, etc. User......Indicates the client name (nickname or IP address) used by the projector. Error ......Indicates the error status during executing the real time capture or one-shot capture. Parameter set up ...

  • Page 106: Moderator's Password Setting Up

    Chapter 8 Network capture functions Moderator's password setting up This enables you to set up the password to join in the moderator's group. Parameter set up Start up the network Capture 4 and click button on the application window. On the mod- Moderator 's pass- erator function setting item on the parameter set up window, set up the password of word...

  • Page 107: Error Information

    Error information Error information Error messages Cause and corresponding Error when the communication is executed. The parameter setting (host Set up the parameter. name, capture port) has not been set. ➔ Check parameter setting (+p.88) Error when Start Communication or Start real time capture is executed. The It has not been registered to PJ as IP address of the computer has not been registered.

  • Page 108

    Chapter 8 Network capture functions...

  • Page 109: Network Viewer Functions

    Chapter 9. Network viewer functions Network Viewer is a function to display the image data stored in the file servers by the projector through the network. Describes the file converter software File Converter 1, File Converter 2, the program creator software Program Editor, and how to use Network Viewer.

  • Page 110: Creating The Available Data [network Viewer 4]

    Chapter 9 Network viewer functions Creating the available data [Network Viewer 4] The image available with this projector is the JPEG format (.jpg). There are several types of JPEG data. Before using the images with the Network Viewer function, it should be converted to the optimized JPEG data for this projector.

  • Page 111: Menu Tree

    Create the available data Menu Tree Menu Sub Menu Description View Update Updates contents of the preview window Preview size Sets size of the preview image, Large, Middle, Small Tools Option Sets default of the output destination and conversion mode Conversion Convert each file Converts a file into a JPEG file individually...

  • Page 112

    Chapter 9 Network viewer functions When converting each file, select a preview image first and then click Convert each file. To select two or more files at once, press and hold ✐ "Shift" key or "Ctrl" key and then click the preview images. When converting all the files in a folder, select a folder and click Convert a folder.

  • Page 113

    Creating the available data [Network Viewer 4] Setting of output destination and conversion mode When clicking Change button on the confirmation win- dow in the step 3 on the previous page, following option setting window appears. Output destination Select either Folder or FTP server as the output destina- tion of the converted files.

  • Page 114

    Chapter 9 Network viewer functions [2] How to use the Network Viewer 4 (File Converter 2) The File Converter 2 is a kind of the printer driver software to convert to the optimized JPEG data for the projection from the any documents created by the other software such as text editor, spreadsheet or presentation software.

  • Page 115: Creating A Program File [program Editor]

    Creating a program file [Program Editor] Creating a program file [Program Editor] Network Viewer 4 (Program Editor) is a tool to make a program file which specifies the display order of the images and its file path in the file server (FTP server). The Program Editor creates a folder "DispParam" at the login root directory in the FTP server, and files with each program name into this folder.

  • Page 116

    Chapter 9 Network viewer functions Click New button. Enter a program name and click Add button. Change : Changes the contents of the program file. Remove : Removes the program from The folder selection window appears and select a folder in the list.

  • Page 117: Setting Up The Display Order And Time Of The Images

    Creating a program file [Program Editor] Setting up the display order and time of the images In the default setting, the display order of the images is the same as ASCII code order of the file name. To change the display order or to set up the display time, take the following procedures. Display the folder list window in step 6 of the previous page.

  • Page 118

    Chapter 9 Network viewer functions To change the display order, select* files and then click UP or DOWN button on the menu bar to move them onto your desired place, or select files and then drag and drop them onto your desired place with mouse.

  • Page 119

    Creating a program file [Program Editor] Example of the created program selection Use the web browser to access to the control page of the projector. Click "Viewer" of the Network menu on the web page, then connect to the FTP server and select the program name which was made at previous section.

  • Page 120: Using The Network Viewer Function

    Chapter 9 Network viewer functions Using the Network Viewer function The Network Viewer is a function to acquire the JPEG image data from the file servers placed in the net- work and project them on the screen. The projected image data are specified by the folder unit. You can set the display time and the number of repeat, and also you can register those folders as the program.

  • Page 121

    Using the network viewer function Setup the setting page [1] of the Visual display. Item Description Host name ....Enter the host name or IP address of FTP server, yourftp.server etc. Folder Path ....Use "/"(root directory) normally, or enter the direc- tory name follow the "/"...

  • Page 122

    Chapter 9 Network viewer functions After clicking Set, the file list or preview list of the selected folder or program is displayed on the window. Decides a image to start auto display with Selects a page radio button The original image is displayed on another window by clicking on the preview image or file name Button...

  • Page 123

    Using the network viewer function Auto Display setting and control page [3] Repeat times (0 to 255 times) * 0 means endless play Display time* of the image (3 to 240 sec.) Click here to check the further information of the file error ✐...

  • Page 124

    Chapter 9 Network viewer functions Error information Error type Description File Error It is displayed when the projector cannot acquire the correct file images from the FTP server, or when the master projector is turned off during the multi-control. Click Error button to check the details. Connection Error It may be displayed when the slave projector is using the Network Viewer or Capture function during the multi-control.

  • Page 125

    Using the network viewer function Display time Repeat times Select "Auto" or "Manual" and then press SELECT button. When selecting "Auto", Set display time and repeat times Select "Connect" and then press SELECT button to start displaying. The images in the FTP server are displayed on the screen.

  • Page 126

    Chapter 9 Network viewer functions...

  • Page 127: Appendix

    Chapter 10. Appendix Use of telnet Web browser setting Firewall setting Troubleshooting Terminology...

  • Page 128: Use Of Telnet

    Chapter 10 Appendix Use of telnet You can control the projector by using the telnet application installed on your computer. Normally, the telnet application is available on your computer. * The telnet 10000 port is used to control the projector. Control (For example, in case of using the telnet application of the Windows XP Professional.) 1.

  • Page 129

    Use of telnet 4. Type the commands, refer to below table, to control the projector and then press "Enter" key for termination. For example, type "C00" which is a command to turn on the projector, and press "Enter" key. Confirm the projector is turning on. To disconnect the communication, press "Ctrl"...

  • Page 130: Web Browser Setting

    Chapter 10 Appendix Web browser setting This product is designed to enable the projector to be set up and controlled from an Internet web brows- er. Depending on the preference settings of the web browser, some control functions may not be avail- able.

  • Page 131: Windows Xp Professional

    Web browser setting Examples: OS/Browsers Windows XP Professional Internet Explorer v.6.0 ActiveScript setting Select Internet Options from Tools menu on the web browser and then select Security tab and click Customize Level… button. On the security setting window, scroll down and find the Scripting item, make sure that "Enable"...

  • Page 132: Proxy Setting

    Chapter 10 Appendix Flash Player Add-on setting Select Manage Add-ons... from Tools menu on the web browser. Select "Add-ons currently located in Internet Explorer" from Show pull-down menu. Make sure that the "Shockwave Flash Object" is listed under the item "Enabled". Proxy setting Select Internet Options from Tools menu on the web browser and then select Connection tab and click LAN Settings button.

  • Page 133

    Web browser setting Netscape Navigator v.7.0 JavaScript Setting Select Preference from Edit menu on the web browser and then select the item Advanced/Scripts & Plugins in the Category column. Make sure that the Enable JavaScript for Navigator is checked. Flash Player enable Flash Player Plug-in setting Select About:Plug-ins from Help menu on the web browser.

  • Page 134

    Chapter 10 Appendix Proxy setting Select from menu on the web browser and then select the item Preference Edit Advanced/Prox- in the column. Properly set up your web browser's the proxy server settings ac- Category cording to the local area network environment to which the projector is connected. - Using proxy server When you use an external internet connection from the local area network, select the item .

  • Page 135: Firewall Setting

    Firewall setting Firewall setting If you use Windows XP SP2 or Windows Vista and using Network Capture 4, you may see the Windows security warning dialog as below. In that case, click "Cancel the block" button on the dialog to enable the function of Network Capture 4.

  • Page 136: Troubleshooting

    Chapter 10 Appendix Troubleshooting If you have any trouble in setup or operation of the projector, refer to the troubleshooting items and check the relevant matters described. ■ The computer cannot connect projectors. Wired LAN Is the LAN cable connected to the projector properly? Are the Link lamp and Access lamp of the LAN terminal lighting properly? Not lighting : The LAN setting of the projector is set “On”? See “Wired LAN setting”...

  • Page 137

    Troubleshooting Infrastructure Mode: When selecting LAN5 (factory default setting) Check each item below in the Wireless Setting menu of the projector as follows: *IP Address ......No setting is required. *Sub net ........Should be the same as the setting of the access point *Gateway .........

  • Page 138

    Chapter 10 Appendix ■ Although the connection between PC and the projector is established, images are not projected on the screen. Make sure Wireless/Wired is selected from the Input source menu of the projector. ■ Cannot be turned on/off with the web browser. Make sure the settings of the projector are correct to use the projector with it.

  • Page 139

    Troubleshooting ■ Speed of playing back images are very slow. When connecting on AdHoc mode, check which Wireless channel you are using. If the computer using the same channel as yours is existing closely, the networking speed may be reduced or the communication unstable. Change the channel to resolve the problem. The channels of the projector and projector Client computer must be the same.

  • Page 140

    Chapter 10 Appendix Network Viewer ■ Images from the file server don’t appear on the screen? 1. Make sure that the input mode of the projector is "Network". 2. Check the account setting of the FTP server (+p.121). 3. The files in the FTP server must be optimized JPEG and converted by the File Converter 1 or 2. Please check data format.

  • Page 141

    Troubleshooting ■ Sometime I have the incorrect images converted by the File Converter 2? Try to change the mode to "Disable" on "Document options" - "Print optimization" item on the "Network Viewer4 (Driver) Advance Options" in the Network Viewer 4 (FileConverter 2) Printer driver setting.

  • Page 142: Terminology

    Chapter 10 Appendix Terminology DHCP server (Dynamic Host Configuration Protocol) It is necessary to set an IP address for each computer or equivalent equipment when a network is established by TCP/IP. If there exists DHCP server on the network, it will assign IP addresses to client computers every time they request it.

  • Page 143

    Terminology...

  • Page 144

    SO-KD3AC SANYO Electric Co., Ltd. NETWORK OWNER'S MANUAL...

This manual also for:

Plc-wxu30a - 3700 lumens

Comments to this Manuals

Symbols: 0
Latest comments:
