HP D5970A - NetServer - LCII Configuration Manual page 64

Step 1. Set the Controller SCSI ID
NOTE
1. Press Menu
2. Press + until Cntrl Changes appears in the display, then press Enter.
3. Press + until SCSI ID appears in the display, then press Enter.
4. Press + until For Cntrl X appears, then press Enter
5. Press + to select the desired SCSI ID, then press Enter.
6. When prompted to Reset OK?, press Enter .
7. When prompted to Confirm, press Enter.
8. Repeat this procedure selecting For Cntrl Y in step 4.
Step 2. Enable SCSI Settings SDTR and WDTR
The SCSI settings SDTR (Synchronous Data Transfer Request) and WDTR (Wide Data Transfer Request) must
be enabled for proper operation. These settings control the transfer of data over the SCSI bus.
1. Press Menu
2. Press + until Cntrl Changes appears in the display, then press Enter.
3. Press + until SDTR appears, then press Enter.
4. Press + until Enable appears, then press Enter.
5. When prompted to Confirm, press Enter.
6. Repeat the above steps, selecting WDTR in step 4.
Step 3. Create a Logical Drive
A single logical drive must be created on the disk array before the operating system can communicate with the
disk array. This logical drive must be reserved for exclusive use by the SureStore E Manager software and
cannot be used for user data.
1. Press Menu
2. Press + until Logical Drv Changes appears in the display, then press Enter.
3. Press + until Create L-Drv appears in the display, then press Enter.
4. Select the default drive number 0, then press Enter.
5. Set the capacity size to the default of 100 MB (megabytes), then press Enter.
6. When prompted to Confirm, press Enter.
NOTE
If two controllers are connected to the same SCSI bus, they must each have unique SCSI
IDs. SCSI ID 7 is reserved for use by the SCSI HBA.
Make sure you leave the disk array power on after completing these steps.
To part 3 of the HP NetServer Microsoft Cluster Installation Guide
