HP Rack Storage/12FC & HP Rack Storage/12
Introduction
This document defines the supported clusters using the HP NetServer LXr 8000 with the HP Rack
Storage/12FC and Microsoft Cluster Server and one or two HP Rack Storage/12s. This configuration
minimizes single points of failure (SPOF), provides maximum availability, and has been certified by Hewlett-
Packard and Microsoft. This guide is prescriptive; it describes the configuration supported by HP. Any
deviance to this configuration can result in an inoperative cluster or an operating cluster with degraded
performance, hidden SPOFs, etc., and therefore will not be supported by HP.
What's Defined in a Racked Cluster
Cluster
Type of SPUs
Number of nodes
Shared Storage
LANs:
Client LAN
Intra-cluster
(Heartbeat) LAN
Power source
System software:
Navigator version
Operating System
HP NetServer LXr 8000
with
Cluster Configuration Guide
1 September 1999
(see Versions at the end of this document)
Cluster
SPUs
Local and Shared Storage
Intra-cluster and Client LANs
HP NetServer LXr 8000
Each node must be the same model SPU, but may have different clock
speeds, main memory sizes, cache sizes, and number of CPUs (2, 3, or 4).
2
HP Rack Storage/12FC with FCArray Cards (1-Simplex or 2-Duplex), HP
disks, and using a HP D8602A HBA in the server. See Shared Storage
below.
Any that is HP and Microsoft approved. See Client LAN below.
HP D5013A with crossover cable. See Intra-cluster LAN below.
Direct from power mains, power conditioner or uninterruptible power
supply (UPS) using any power conditioner or UPS.
L.16.00 or later
Microsoft Windows NT Server 4.0, Enterprise Edition with Service Pack
SP4 or later
1

Advertising

   Related Manuals for HP D7171A - NetServer - LPr

   Summary of Contents for HP D7171A - NetServer - LPr

  • Page 1

    HP NetServer LXr 8000 with HP Rack Storage/12FC & HP Rack Storage/12 Cluster Configuration Guide 1 September 1999 (see Versions at the end of this document) Introduction This document defines the supported clusters using the HP NetServer LXr 8000 with the HP Rack Storage/12FC and Microsoft Cluster Server and one or two HP Rack Storage/12s.

  • Page 2

    Model HP NetServer LXr 8000 Clock speed 400/450, 500/550 MHz No. of CPUs 2 – 4 BIOS version Rel 10 or later CPU cache Any size 256 MB minimum. Must be HP. No. of power supplies Local storage See Local Storage below. I/O slots: P8 –...

  • Page 3

    Firmware 4.64-00 or later Status SCSI ID 5 (fixed) Disk SCSI IDs 0 – 3, 8 – 15 (fixed) Disk drives: HP 4.2 GB Ultra SCSI Disk Module D6104A HP 9.1 GB Ultra SCSI Disk Module D6106A HP 9.1 GB Ultra SCSI Disk Module D6107A HP 18.2 GB Ultra SCSI Disk Module D6108A HP 18.2 GB (10k rpm) Ultra SCSI Disk Module D7031A HP 18.2 GB (7200 rpm) Low Profile Ultra SCSI Disk Module D7174A...

  • Page 4: Shared Storage Cabling

    No. of NICs 1 minimum SPU I\O slot P7-P1. Install LAN one PCI slot P8-P2. Install LAN one PCI slot lower than the Client LAN. higher than the Intra-cluster LAN. Shared Storage Cabling This part of the guide defines the allowable cabling configurations for clusters using the HP NetServer LXr 8000, one required HP Rack Storage/12FC and two optional HP Rack Storage/12s.

  • Page 5

    HP Microsoft Cluster using HP Rack Storage/12FC and Rack Storage/12 and 6 Port Fibre Channel Hub (Duplex Operation)

  • Page 6

    Required shared storage devices: Optional shared storage devices: HP Microsoft Cluster using HP Rack Storage/12FC and Rack Storage/12 without 6 Port Fibre Channel Hub (Simplex Operation)

  • Page 7

    Power Cabling to Separate Power Circuits...

  • Page 8

    Versions 4 April 2000 Added local storage (Embedded RAID, 3Si, 1Si) controller driver 2.24 1 September 1999 Initial release.
