Optical bay drive carrier ● Cables ● Four M3 guide screws (for HP 400 Workstations) Before you begin To view QuickSpecs and determine the compatibility of this product with your HP workstation, see http://www.hp.com/go/productbulletin. © 2009 Hewlett-Packard Development Company, L.P. ENWW Introduction...
Warnings and cautions WARNING! Any surface or area of the equipment marked with this symbol indicates the presence of an electrical shock hazard. To reduce the risk of injury from electrical shock, do not open any enclosed area marked with this symbol. WARNING! To reduce the risk of electric shock or damage to your equipment: —...
Step 1—Preparing for component installation NOTE: Workstation models vary. All illustrations are examples only. Accessing the internal components of the workstation If you need help preparing the workstation for this installation, consult the removal and replacement procedures in the service guide for your workstation at http://www.hp.com/support/ workstation_manuals.
Lower the diskette drive into the carrier Figure 2 Installing the diskette drive in the optical bay drive carrier Align the rear screws on the drive with the channel in the carrier To fully seat the diskette drive in the carrier, the carrier cannot be in contact with a solid surface.
To install the drive carrier and diskette drive, disengage the optical bay release latch while inserting the carrier into the optical drive bay Figure 4 Installing the carrier in the optical bay Slide the carrier into the bay. Release the latch just before the carrier is fully seated, to enable the latch pins to engage.
Gently push the cable down to keep it off the system board. . Figure 6 Routing the diskette data cable Step 4—Reassembling the workstation Reinstall the bezel, if applicable. Reinstall the airflow guide, if applicable. Reinstall the side access panel. Reconnect power to the workstation and all external devices.
