Benchmark Tests And Results - HP Visualize j6000 - Compute Farm Introduction

July 25, 2000
Page 3
1.2
1
0.8
0.6
0.4
0.2
23658
Ansys 5.6 (Structural modal ShelL Blcok Lanczom Medium)
Bigger is faster
71472
Degrees of Fredom
This graph was generated by taking the total elapsed time from three
different benchmark tests (models), each at different degrees of freedom
and normalizing the data. The workloads selected for this chart are from
the ANSYS 5.6 public benchmarks: sms-bls (23,658 DF) , sms-blm (71,472
DF), and smb-blm (73,575 DF). Each of these workloads is a structural
modal shell.
This graph shows that the Compaq Alpha 667 has a .057x performance
advantage to the j6000 on sms-bls. However, the j6000 is 1.40x faster
than the IBM and 1.628x faster than the Sun. This workload, with only
23658 degrees of freedom, is considered to have low complexity.
HP J6000 550Mhz 2-Way
Compaq Alpha 667MHz 2-Way
IBM RS6000 375MHz 2-Way
Sun U80 450MHz 2-Way
73575
