Design Wash 250
The Design Wash 250 by Elation Professional is a 250W discharge CMY moving head wash featuring the CMY
color mixing system, based on graduated cyan, magenta and yellow color filters as well as 8 fixed dichroic
colors. This unit also features motorized zoom, dual flag mechanical dimmer, variable speed strobe effect
(1-13 flashes per second), 180° beam shaper and frost filter. Control data input is via 3 pin or 5 pin DMX data
first in and out cables. The Design Wash 250 also features Philips MSD 250/2 lamp providing up to 3,000 hours
estimated lamp life. The Design Wash 250 is equipped with remote DMX adjustable motorized zoom allowing
for a maximum beam angle of 28° and a minimum beam angle of 18°. The unit is rated IP 20 and is designed
for indoor use only. Rigging for this unit includes 2 x 1/4 turn Omega clamps, 3-pin dmx cable and safety.
FEATURES
• 250W discharge moving head wash
• CMY color mixing system
• 8 dichroic-filters plus white
• High luminous-efficiency parabolic reflector
• Frost filter for softer beam
• 150 mm Fresnel lens
• Lux 28,000 @ 18º @ 2.5M
• 180° beam shaper
• Wide and flat beam can be rotated by 90°
• Automatic Pan / Tilt position correction
• Maximum PAN-movement 630° in 2.0 secs. (default)
or 540° (user selectable) / 16 bit
• Maximum TILT-movement 265° in 1.5 secs. / 16 bit
• Pre-set variable/random strobe and dimming pulse effect
• Sound active mode
• Vector Mode with blackout
• DMX control via 16 channels
• 4 Digit L.E.D. Display
• On board menu settings
Design Wash 250 Dimensions
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free ( 866 ) 245-6726
TECHNICAL SPECIFICATIONS
• DMX Channels: 16 DMX Channels,
RDMX - Remote DMX Addressing
• Control: USITT DMX-512 (16-bit resolution),
3-pin XLR serial input/output
• Dimmer: Dual Flag mechanical dimming system
• Strobe: Variable speed strobe effect
(1-13) flashes per second
• Motorized Zoom: Remote DMX adjustable
18° to 28° beam angle
• IP Rating: IP 20
• Power Supply: AC 98V, 120V, 220V, 208V, 230V,
240V 50/60Hz
• Power Consumption: 400W
• Fuse: 8A (120V) or 4A (220V), magnetic ballast
• Lamp: Philips MSD250/2
• Lamp life: 250W, 8500°K, 3000HRS
• Dimensions: ( L x W x H ) 14" x 14" x 22.5" /
355.6mm x 355.6mm x 571.5mm
• Weight: 59 lbs. / 26.76 kg
• Rigging: 2 x ¼ turn Omega Clamps
1 x safety cable
1 x 3-pin DMX data cable
