Denon AVR 4308CI - AV Network Receiver Manual page 36

EVENT PARAMETER
Z2 PHONO
|
IPOD
SOURCE
**
ON
OFF
Z2MU ON
OFF
Z2CS ST
MONO
Z2CV FL **
FR **
Z2HPF ON
OFF
Z2PS BAS **
TRE **
The PARAMETER of Z2 EVENT : Uses two ASCII characters. (see page4 J) section)
function
MULTI ZONE-2 source change
---The name of PARAMETER is
the same as that of the time of SI COMMAND.
MULTI ZONE-2 mode cancel
MULTI ZONE-2 VOLUME change , **:10 to 99 by ASCII
98 = +18dB(MAX)
80 = 0dB
10 = -70dB
99 = ---(MIN)
MULTI ZONE-2 ON/OFF change
ZONE2 OUTPUT MUTE ON/OFF change
ZONE2 Channel setting
**:38 to 62 by ASCII , 50=0dB
**:38 to 62 by ASCII , 50=0dB
ZONE2 HPF ON/OFF change
ZONE2 BASS change
ZONE2 TEBLE change
- 36 -
example
Z2PHONO<CR>
|
Z2IPOD<CR>
Z2SOURCE<CR>
Z280<CR>
Z2ON<CR>
Z2OFF<CR>
Z2MUON<CR>
Z2MUOFF<CR>
Z2CSST
Z2CSMONO
Z2CVFL 50<CR>
Z2CVFR 50<CR>
Z2HPFON<CR>
Z2HPFOFF<CR>
Z2PSBAS 00<CR>
Z2PSTRE 00<CR>
