Denon AVR 4308CI - AV Network Receiver Manual page 28

EVENT(or RESPONSE) and PARAMETER list
EVENT
PW ON
STANDBY
MV **
CV FL **
FR **
C **
SW **
SL **
SR **
SBL **
SBR **
SB **
MU ON
OFF
SI PHONO
CD
TUNER
DVD
HDP
TV/CBL
SAT
VCR
DVR
V.AUX
The PARAMETER of MV, CV EVENT : Uses two or three ASCII characters. (see page4 J) section)
PARAMETER
POWER ON/STANDBY change
MASTER VOLUME change , **:00 to 99 by ASCII
98 = +18dB(MAX)
80 = 0dB
00 = -80dB
99 = ---(MIN)
CHANNEL VOLUME change , **:00,38 to 62 by ASCII
62 = +12dB(MAX)
50 = 0dB
38 = -12dB(MIN)
00 = OFF (define ONLY SWch in DIRECT mode.)
(at SBch 2SP)
(at SBch 2SP)
(at SBch 1SP)
OUTPUT MUTE ON/OFF change
INPUT source change
function
- 28 -
example
PWON<CR>
PWSTANDBY<CR>
MV80<CR>
CVFL 50<CR>
CVFR 50<CR>
CVC 50<CR>
CVSW 50<CR>
CVSL 50<CR>
CVSR 50<CR>
CVSBL 50<CR>
CVSBR 50<CR>
CVSB 50<CR>
MUON<CR>
MUOFF<CR>
SIPHONO<CR>
SICD<CR>
SITUNER<CR>
SIDVD<CR>
SIHDP<CR>
SITV/CBL<CR>
SISAT<CR>
SIVCR<CR>
SIDVR<CR>
SIV.AUX<CR>
