DENON AVR control protocol
Application model : AVR-4308
Application terminal: RS-232C/ Ethernet
Connector specification
Ⅰ. RS-232C
Connector type: DB-9pin female type, slave straight connection (DCE type)
( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )
Communication format:
Synchronous system
Communication system
Communication speed
Character length
Parity control
Start bit
Stop bit
Communication procedure
Communication data length
Version
Date
5.1.0
06.Jul.'07
5.1.0_a
23.Jan.'08
: Tone step synchronization
: A half duplex
: 9600bps
: 8 bits
: None
: 1 bit
: 1 bit
: Non procedural
: 135 bytes (maximum)
Contents
Original
1.Added NSE,NSB,NSC for iRadio Control.
2.Corrected the Command of IPE,IPA for iPod Control.
3.Added Response MS Command for DTS Mode.
4.Corrected the Response Command of PSMODE.
- 1 -
Ver. 5.1.0_a
Page
24,42
25,43,44,45,46
31,32
33

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVR 4308CI - AV Network Receiver and is the answer not in the manual?

Questions and answers

Related Manuals for Denon AVR 4308CI - AV Network Receiver

Summary of Contents for Denon AVR 4308CI - AV Network Receiver

  • Page 1 DENON AVR control protocol Ver. 5.1.0_a Application model : AVR-4308 Application terminal: RS-232C/ Ethernet Connector specification Ⅰ. RS-232C Connector type: DB-9pin female type, slave straight connection (DCE type) ( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )
  • Page 2 Ⅱ. Ethernet ： RJ-45(10BASE-T/100BASE-TX) Connector type Example ① Ethernet AVR/AVC Cross cable Example ② AVR/AVC Ethernet Ethernet Straight Straight cable cable Communication format ： Communication system : A half duplex Communication speed : 10Mbps/100Mbps Communication port : TCP port 23 (telnet) Communication data length : 135bytes (maximum) - 2 -...
  • Page 3 NETWORK SETUP of AVR-4308 >Procedure of Network Setup mode. (1)Press SYSTEM SETUP button, then System Setup Menu appears on FL-display(and GUI) (2)Select “Network Setup > Detail” . (3)Set parameters described below. <DHCP> "ON"---Use this setting when DHCP server is on the local network. "OFF"---Use this setting when DHCP server is not on the local network.
  • Page 4 Protocol specification The following three data forms are defined. COMMAND The message sent to a system(AVR) from a controller(Touch Panel etc.) A command to a system is given from a controller. EVENT The message sent to a controller (Touch Panel etc.) from a system (AVR) The result is sent, when a system is operated directly and a state changes.
  • Page 5 The example of a command * <CR> is the meaning of 0x0D. SIDVD<CR> : Select Input source DVD MSSTEREO<CR> : surround Mode Set to STEREO MVUP<CR> : Master Volume UP PWON<CR> : system PoWer ON PWSTANDBY<CR> : system PoWer STANDBY SI?<CR>...
  • Page 6 Others A) COMMAND is receivable also during transmission of EVENT. B) Since CHANNEL VOLUME changes simultaneously when the SURROUND MODE changes, the value of the channel volume of all channels returns as EVENT. C) CHANNEL VOLUME returns the data of ALL channels by the present SURROUND MODE also including an intact channel. In this case, the data of an intact channel is set to "50".
  • Page 7 COMMAND and PARAMETER list COMMAND PARAMETER function example POWER ON/STANDBY change PWON<CR> STANDBY PWSTANDBY<CR> Return PW Status PW?<CR> MASTER VOLUME UP/DOWN , direct change to **dB MVUP<CR> DOWN MVDOWN<CR> **:00 to 99 by ASCII , 80=0dB, 99=---(MIN) MV80<CR> Return MV Status MV?<CR>...
  • Page 8 COMMAND PARAMETER function example SB UP ---SURROUND BACKch (SBch 1SP) CVSB UP<CR> SB DOWN CVSB DOWN<CR> SB ** **:00 to 99 by ASCII , 50=0dB CVSB 50<CR> Return CV Status CV?<CR> OUTPUT MUTE ON/OFF change MUON<CR> MUOFF<CR> Return MU Status MU?<CR>...
  • Page 9 COMMAND PARAMETER function example AUTO set AUTO mode (Priority:HDMI>>DIGITAL>>ANALOG) SDAUTO<CR> HDMI SDHDMI<CR> set force HDMI INPUT mode DIGITAL SDDIGITAL<CR> set force DIGITAL INPUT (Optical,Coaxial)mode ANALOG set force ANALOG INPUT mode SDANALOG<CR> EXT.IN-1 ---Set EXT.IN mode at AVR-4308 SDEXT.IN-1<CR> Return SD Status SD?<CR>...
  • Page 10 COMMAND PARAMETER function example CLASSIC CONCERT MSCLASSIC CONCERT<CR> MONO MOVIE MSMONO MOVIE<CR> MATRIX MSMATRIX<CR> VIDEO GAME MSVIDEO GAME<CR> VIRTUAL MSVIRTUAL<CR> Return MS Status MS?<CR> QUICK1 QUICK SELECT 1-3 MODE SELECT MSQUICK1<CR> QUICK2 MSQUICK2<CR> QUICK3 MSQUICK3<CR> QUICK1 MEMORY USER1-3 MODE MEMORY MSQUICK1 MEMORY<CR>...
  • Page 11 COMMAND PARAMETER function example TONE DEFEAT ON PARAMETER setting PSTONE DEFEAT ON<CR> TONE DEFEAT OFF TONE DEFEAT ON/OFF PSTONE DEFEAT OFF<CR> TONE DEFEAT ? Return PSTONE DEFEAT Status PSTONE DEFEAT ?<CR> SB:MTRX ON SURROUND BACK SP MODE set PSSB:MTRX ON<CR> SB:NON MTRX PSSB:NON MTRX<CR>...
  • Page 12 COMMAND PARAMETER function example TRE UP TREBLE UP/DOWN , direct change to **dB PSTRE UP<CR> TRE DOWN PSTRE DOWN<CR> **:00 to 99 by ASCII , 50=0dB TRE ** ---AVR-4308 can be operated from -6 to +6(44 to 56) PSTRE 50<CR> TRE ? PSTRE ?<CR>...
  • Page 13 COMMAND PARAMETER function example PAN ON PANORAMA ON/OFF PSPAN ON<CR> PAN OFF PSPAN OFF<CR> PAN ? PSPAN ?<CR> Return PSPAN Status DIM UP PSDIM UP<CR> DIMENSION UP/DOWN , direct change to **dB DIM DOWN **:00 to 99 by ASCII , 00=0, PSDIM DOWN<CR>...
  • Page 14 COMMAND PARAMETER function example NIGHT OFF NIGHT MODE direct change PSNIGHT OFF<CR> NIGHT LOW PSNIGHT LOW<CR> NIGHT MID PSNIGHT MID<CR> NIGHT HI PSNIGHT HI<CR> NIGHT ? Return PSNIGHT Status PSNIGHT ?<CR> RSTR OFF AUDIO RESTORER direct change PSRSTR OFF<CR> RSTR MODE1 PSRSTR MODE1<CR>...
  • Page 15 COMMAND PARAMETER function example PHONO MULTI ZONE-2 mode set , and select source at AVR-4308 Z2PHONO<CR> ---The name of PARAMETER is IPOD the same as that of the time of SI COMMAND. Z2IPOD<CR> SOURCE MULTI ZONE-2 mode cancel at AVR-4308 Z2SOURCE<CR>...
  • Page 16 COMMAND PARAMETER function example Z2PS BAS UP Z2PSBAS UP<CR> ZONE2 BASS UP/DOWN , direct change to **dB BAS DOWN Z2PSBAS DOWN<CR> **:00 to 99 by ASCII , 00=0dB BAS ** ---AVR-4308 can be operated from -10 to +10(40 to 60) Z2PSBAS 00<CR> BAS ? Return Z2PSBAS Status Z2PSBAS ?<CR>...
  • Page 17 COMMAND PARAMETER function example PHONO MULTI ZONE-3 mode set , and select source at AVR-4308 Z3PHONO<CR> ---The name of PARAMETER is IPOD the same as that of the time of SI COMMAND. Z3IPOD<CR> SOURCE MULTI ZONE-3 mode cancel Z3SOURCE<CR> MULTI ZONE-3 VOLUME UP/DOWN , direct change to **dB Z3UP<CR>...
  • Page 18 COMMAND PARAMETER function example Z3PS BAS UP Z3PSBAS UP<CR> ZONE3 BASS UP/DOWN , direct change to **dB BAS DOWN **:00 to 99 by ASCII , 00=0dB Z3PSBAS DOWN<CR> BAS ** ---AVR-4308 can be operated from -10 to +10(40 to 60) Z3PSBAS 00<CR>...
  • Page 19 COMMAND PARAMETER function example MULTI ZONE-4 mode set , and select source at AVR-4308 Z4CD<CR> ---The name of PARAMETER is V.AUX the same as that of the time of SI COMMAND. Z4V.AUX<CR> SOURCE MULTI ZONE-4 mode cancel Z4SOURCE<CR> MULTI ZONE-4 ON/OFF change at AVR-4308 Z4ON<CR>...
  • Page 20 ※ANALOG TUNER Control COMMAND PARAMETER function example ANUP TUNER Frequency UP/DOWN TFANUP<CR> ANDOWN TFANDOWN<CR> AN****** --- ****.** kHz at AM band (>050000 is AM.) TFAN105000<CR> (6 digits) ****.** MHz at FM band (<050000 is FM.) (1050.00kHz at AM) Return TF Status TFAN?<CR>...
  • Page 21 ※XM Control(North America model only) COMMAND PARAMETER function example XMUP XM Channel UP/DOWN TFXMUP<CR> XMDOWN TFXMDOWN<CR> XM*** --- ***:XM CH No. TFXM001<CR> (3 digits) (XM001 CH at XM) Return TFXM Status TFXM?<CR> XMUP XM PRESET CH UP/DOWN , direct change to No.** TPXMUP<CR>...
  • Page 22 ※HD RADIO Control(North America model only) COMMAND PARAMETER function example HDUP HD Channel UP/DOWN , direct change TFHDUP<CR> HDDOWN TFHDDOWN<CR> HD****** --- ****.** kHz at AM band (>050000 is AM.) TFHD105000<CR> (6 digits) ****.** MHz at FM band (<050000 is FM.) (1050.00kHz at AM) HDMC*(1 TFHDMC2<CR>...
  • Page 23 ※DAB Control(Europe model only) COMMAND PARAMETER function example DAUP DAB Channel UP/DOWN TFDAUP<CR> DADOWN TFDADOWN<CR> DA****** --- ***.*** kHz TFDA174928<CR> (6 digits) (174.928kHz) Return TFDAB Status TFDA?<CR> DAUP DAB PRESET CH UP/DOWN , direct change to No.** TPDAUP<CR> DADOWN TPDADOWN<CR> DA** TPDAA1<CR>...
  • Page 24 ※iRadio/mServer/USB Extended Control COMMAND PARAMETER function example Select INPUT source NET/USB and USB Start Playback SIUSB<CR> Select MULTI ZONE-2 source NET/USB and USB Start Playback Z2USB<CR> Select MULTI ZONE-3 source NET/USB and USB Start Playback Z3USB<CR> Select MULTI ZONE-4 source NET/USB and USB Start Playback Z4USB<CR> “Cursor Up”...
  • Page 25 ※iPod Extended Control COMMAND PARAMETER function example “Cursor Up” Control IP90<CR> “Cursor Down” Control IP91<CR> “Cursor Left” Control IP92<CR> “Cursor Right” Control IP93<CR> “Enter (Play/Pause)” Control IP94<CR> “Play/Pause” Control IP9A<CR> “Stop” Control IP9C<CR> “Skip Plus” Control IP9D<CR> “Skip Minus” Control IP9E<CR>...
  • Page 26 ※Cursol/Enter/Menu(Setup) COMMAND PARAMETER function example “Cursor Up” Control MNCUP<CR> “Cursor Down” Control MNCDN<CR> “Cursor Left” Control MNCLT<CR> MNCRT<CR> “Cursor Right” Control MNENT<CR> “Enter” Control “RETURN” Control MNRTN<CR> MEN ON MNMEN ON<CR> “GUI Menu ON” Control MEN OFF “GUI Menu OFF” Control MNMEN OFF<CR>...
  • Page 27 ※Remote Lock/Panel Lock COMMAND PARAMETER function example REMOTE LOCK ON REMOTE CONTROL LOCK ON/OFF SYREMOTE LOCK ON<CR> REMOTE LOCK OFF SYREMOTE LOCK OFF<CR> PANEL LOCK ON PANEL BUTTON(Except MASTER VOL.)CONTROL LOCK ON SYPANEL LOCK ON<CR> PANEL+V LOCK ON PANEL BUTTON & MASTER VOL. CONTROL LOCK ON SYPANEL+V LOCK ON<CR>...
  • Page 28 EVENT(or RESPONSE) and PARAMETER list EVENT PARAMETER function example POWER ON/STANDBY change PWON<CR> STANDBY PWSTANDBY<CR> MASTER VOLUME change , **:00 to 99 by ASCII MV80<CR> 98 = +18dB(MAX) 80 = 0dB 00 = -80dB 99 = ---(MIN) FL ** CHANNEL VOLUME change , **:00,38 to 62 by ASCII CVFL 50<CR>...
  • Page 29 EVENT PARAMETER function example NET/USB SINET/USB<CR> (North America model Only) SIXM<CR> HDRADIO (North America model Only) SIHDRADIO<CR> (Europe model Only) SIDAB<CR> SIUSB<CR> IPOD SIIPOD<CR> MAIN-ZONE ON/OFF change ZMON<CR> ZMOFF<CR> PHONO REC SELECT source change SRPHONO<CR> ---The name of PARAMETER is IPOD the same as that of the time of SI COMMAND.
  • Page 30 EVENT PARAMETER function example DIRECT SURROUND mode change MSDIRECT<CR> PURE DIRECT MSPURE DIRECT<CR> STEREO MSSTEREO<CR> MULTI CH IN MSMULTI CH IN<CR> MULTI CH IN MSM CH IN+PL2X C<CR> +PL2x C MULTI CH IN MSM CH IN+PL2X M<CR> +PL2x M MULTI CH DIRECT MSMULTI CH DIRECT<CR>...
  • Page 31 EVENT PARAMETER function example DTS NEO:6 C MSDTS NEO:6 C<CR> DTS NEO:6 M MSDTS NEO:6 M<CR> DTS SURROUND MSDTS SURROUND<CR> DTS ES DSCRT6.1 MSDTS ES DSCRT6.1<CR> DTS ES MTRX6.1 MSDTS ES MTRX6.1<CR> DTS+PL2x C MSDTS+PL2X C<CR> DTS+PL2x M MSDTS+PL2X M<CR> DTS+NEO:6 MSDTS+NEO:6<CR>...
  • Page 32 EVENT PARAMETER function example NEURAL (North America model Only) MSNEURAL<CR> DOLBY D+ MSDOLBY D+<CR> DOLBY D+ +EX MSDOLBY D+ +EX<CR> DOLBY D+ +PL2x C MSDOLBY D+ +PL2X C<CR> DOLBY D+ +PL2x M MSDOLBY D+ +PL2X M<CR> DOLBY TRUEHD MSDOLBY HD<CR> DOLBY HD MSDOLBY HD<CR>...
  • Page 33 EVENT PARAMETER function example TONE DEFEAT ON TONE DEFEAT ON/OFF change PSTONE DEFEAT ON<CR> TONE DEFEAT OFF PSTONE DEFEAT OFF<CR> SB:MTRX ON SURROUND BACK MODE change PSSB:MTRX ON<CR> SB:NON MTRX PSSB:NON MTRX<CR> SB:PL2xC PSSB:PL2X CINEMA<CR> SB:PL2xM PSSB:PL2X MUSIC<CR> SB:ON PSSB:ON<CR> SB:OFF PSSB:OFF<CR>...
  • Page 34 EVENT PARAMETER function example DRC AUTO PSDRC AUTO<CR> DRC change DRC LOW PSDRC LOW<CR> DRC MID PSDRC MID<CR> DRC HI PSDRC HI<CR> DRC OFF PSDRC OFF<CR> DCO OFF D.COMP change PSDCO OFF<CR> DCO MID PSDCO MID<CR> DCO LOW PSDCO LOW<CR> DCO MID PSDCO MID<CR>...
  • Page 35 EVENT PARAMETER function example DELAY *** AUDIO DELAY change, ***:000 to 999 by ASCII PSDELAY 200<CR> ---AVR-4308：200=200ms（MAX） 100=100ms, 000=0ms NIGHT OFF NIGHT MODE change PSNIGHT OFF<CR> NIGHT LOW PSNIGHT LOW<CR> NIGHT MID PSNIGHT MID<CR> NIGHT HI PSNIGHT HI<CR> RSTR OFF AUDIO RESTORER change PSRSTR OFF<CR>...
  • Page 36 EVENT PARAMETER function example PHONO MULTI ZONE-2 source change Z2PHONO<CR> ---The name of PARAMETER is IPOD the same as that of the time of SI COMMAND. Z2IPOD<CR> SOURCE MULTI ZONE-2 mode cancel Z2SOURCE<CR> MULTI ZONE-2 VOLUME change , **:10 to 99 by ASCII Z280<CR>...
  • Page 37 EVENT PARAMETER function example PHONO MULTI ZONE-3 source change Z3PHONO<CR> ---The name of PARAMETER is the same as that of the time of SI COMMAND. Z3IPOD<CR> SOURCE MULTI ZONE-3 mode cancel Z3SOURCE<CR> MULTI ZONE-3 VOLUME change , **:10 to 99 by ASCII Z380<CR>...
  • Page 38 ※ANALOG TUNER Control EVENT PARAMETER function example AN****** TUNER Frequency change TFAN105000<CR> (6 digits) (1050.00kHz at AM) --- ****.** kHz at AM band ****.** MHz at FM band AN**(PRESET No.) TPANA1<CR> TUNER PRESET change to No.** (PRESET No.”A1”) TUNER BAND , MODE change ANAM ---Band set to AM TMANAM<CR>...
  • Page 39 ※HD RADIO Control(North America model only) EVENT PARAMETER function example HD****** --- ****.** kHz at AM band (>050000 is AM.) TPHD105000<CR> (6 digits) ****.** MHz at FM band (<050000 is FM.) (1050.00kHz at AM) HDMC*(1 digit) TFHDMC2<CR> ---HD Multi Cast CH change(*:0～8) HD**(PRESET No.) TPHDA1<CR>...
  • Page 40 ※DAB Control(Europe model only) EVENT PARAMETER function example DAB****** --- ***.*** kHz TFDAB174928<CR> (6 digits) (174.928kHz) DAB**(PRESET No.) HD PRESET change to No.** TPDABA1<CR> (PRESET No.”A1”) DAB MODE change DABMULTI TMDABMULTI<CR> ---Tuning mode set to MULTIPLEX mode DABALPHA TMDABALPHA<CR> ---Tuning mode set to ALPHANUMERIC mode DABPTY TMDABPTY<CR>...
  • Page 41 ※iRadio/mServer/USB Extended Control EVENT PARAMETER function Onscreen Display Information is Answered By the NSA Command. Display Line1 Information NSA0**************_?????<CR> Display Line3 Information NSA1※************_?????<CR> Display Line4 Information NSA2※************_?????<CR> Display Line5 Information NSA3※************_?????<CR> Display Line6 Information NSA4※************_?????<CR> Display Line7 Information NSA5※************_?????<CR> Display Line8 Information NSA6※************_?????<CR>...
  • Page 42 EVENT PARAMETER function Onscreen Display Information(mserver/iRadio) is Answered By the NSE Command. Display Line1 Information NSE0**************_?????<CR> Display Line3 Information NSE1※************_?????<CR> Display Line4 Information NSE2※************_?????<CR> Display Line5 Information NSE3※************_?????<CR> Display Line6 Information NSE4※************_?????<CR> Display Line7 Information NSE5※************_?????<CR> Display Line8 Information NSE6※************_?????<CR> Display Line9 Information NSE7**************_?????<CR>...
  • Page 43 ※iPod Extended Control EVENT PARAMETER function Onscreen Display Information is Answered By the IPA Command. Display Line1 Information IPA0***************_???<CR> Display Line3 Information IPA1※*************_???<CR> Display Line4 Information IPA2※*************_???<CR> Display Line5 Information IPA3※*************_???<CR> Display Line6 Information IPA4※*************_???<CR> Display Line7 Information IPA5※*************_???<CR> Display Line8 Information IPA6※*************_???<CR>...
  • Page 44 EVENT PARAMETER function <example1> IPA0Artist??????????????????<CR> IPA1※ Ana Caram_????????????<CR> IPA2※ Badi Assad_???????????<CR> IPA3※ Christy Baron_????????<CR> IPA4※ Marta Gomez_??????????<CR> IPA5※ Rebecca Pidgeon_??????<CR> IPA6※ Sara K_???????????????<CR> IPA7※ Valerie Joyce_????????<CR> IPA8# SFL Songs RPT All_???<CR> IPA9 6]_?????????<CR> <example2> IPA0Now Playing iPod_???????<CR> IPA1※ A HARD DAY'S NIGHT._??<CR> IPA2※...
  • Page 45 EVENT PARAMETER function Onscreen Display Information(iPod) is Answered By the IPA Command. Display Line1 Information IPE0***************_???<CR> Display Line3 Information IPE1※*************_???<CR> Display Line4 Information IPE2※*************_???<CR> Display Line5 Information IPE3※*************_???<CR> Display Line6 Information IPE4※*************_???<CR> Display Line7 Information IPE5※*************_???<CR> Display Line8 Information IPE6※*************_???<CR> Display Line9 Information IPE7※*************_???<CR>...
  • Page 46 EVENT PARAMETER function <example1> IPE0Artist??????????????????<CR> IPE1※ Ana Caram_????????????<CR> IPE2※ Badi Assad_???????????<CR> IPE3※ Christy Baron_????????<CR> IPE4※ Marta Gomez_??????????<CR> IPE5※ Rebecca Pidgeon_??????<CR> IPE6※ Sara K_???????????????<CR> IPE7※ Valerie Joyce_????????<CR> IPE8# SFL Songs RPT All_???<CR> IPE9 6]_?????????<CR> <example2> IPE0Now Playing iPod_???????<CR> IPE1※ A HARD DAY'S NIGHT._??<CR> IPE2※...
  • Page 47 ※Remote Lock/Panel Lock EVENT PARAMETER function example REMOTE LOCK ON REMOTE CONTROL LOCK ON/OFF SYREMOTE LOCK ON<CR> REMOTE LOCK OFF SYREMOTE LOCK OFF<CR> PANEL LOCK ON PANEL BUTTON(Except MASTER VOL.)CONTROL LOCK ON SYPANEL LOCK ON<CR> PANEL+V LOCK ON PANEL BUTTON & MASTER VOL. CONTROL LOCK ON SYPANEL+V LOCK ON<CR>...
