Maintaining the Machine
14-38
Cleaning the Components as Needed
Dirt or dust gather in the machine and can cause the machine to print
incorrectly. The following lists the parts to clean and how the dirt can
affect the print quality.
•
Contacts— These groups of contacts are located under the
Developer Assembly. Dirt or dust on the contacts causes the
printer to blur characters.
•
Metering Blade— The Metering Bade is located above the black
toner roller on the Developer Assembly. Dirt between the magnet
roller and the metering blade causes the machine to print vertical
lines.
•
Document Scanner— The Document Scanner is located on the
underside of the Control Panel.
•
Scanner Rollers and Retard Pad— The Scanner Rollers and
the Retard Pad are parts of the automatic document feeder inside
the scanner.
Document WorkCentre Pro 635, 645, 657
Advertisement
Related Manuals for Xerox WorkCentre Pro 657
Summary of Contents for Xerox WorkCentre Pro 657
- Page 1 Maintaining the Machine Cleaning the Components as Needed Dirt or dust gather in the machine and can cause the machine to print incorrectly. The following lists the parts to clean and how the dirt can affect the print quality. • Contacts—...
-
Page 2: Maintaining The Machine
Maintaining the Machine Use the following procedure to clean the additional components: 1. Grasp the Top Cover Open Lever and open the Top Cover. WARNING Do not touch the fuser housing inside the machine. The fuser housing is extremely hot while the machine is operating. Top Cover Top Cover Open Lever... - Page 3 Maintaining the Machine CAUTION Always hold the Developer Assembly by the green handles. Do not touch the green drum area or the black roller. Do not leave the Drum Unit out of the machine for an extended period. Touching the drum or exposing the Drum Unit to light could lower the print quality.
- Page 4 Maintaining the Machine 4. Separate the Drum Unit from the Developer Assembly. The following figure shows the Drum Unit and the Developer Assembly. Drum Unit Developer Assembly 5. Place the Drum Unit on a level surface. Cover the Drum Unit with a clean cloth to protect the unit from exposure to light.
- Page 5 Maintaining the Machine To clean Contacts 6. Use a cotton swab to clean the silver contacts in the machine. Contacts are located inside the chassis in the front, on the right, and in the rear. The following figure shows the locations of the contacts.
- Page 6 Maintaining the Machine Rear To clean the Metering Blade 7. Use the Mylar Scraper to scrape off the toner between the metering blade and the black toner roller on the Developer Assembly. The following figure shows how to clean the Metering Blade.
- Page 7 Maintaining the Machine 8. Position the Drum Unit with the green drum surface facing the black toner roller on the Developer Assembly. Without touching the green drum surface, hook the Drum Unit to the Developer Assembly. The following figure shows how to join the Drum Unit and the Developer Assembly.
- Page 8 Maintaining the Machine The following figure shows how the shafts on the Developer Assembly align with the slots. Document WorkCentre Pro 635, 645, 657 14-45...
- Page 9 Maintaining the Machine 10. Press firmly on the green squares on the Drum Unit until the Drum Unit clicks into place. The following figure shows how to press the Drum Unit into place. Drum Unit 11. Close the Top Cover. Press down the Top Cover until a "click" is heard to ensure the cover is closed.
