1. Application
- This document defines the communications method for control of the LCD8205
monitor.
2. Connectors and Writing
Connector : D-Sub 9-pin
Cable : Cross (reversed) cable or null modem cable
(please refer to LCD 8205 User's Manual )
3. Communication Parameter
Item
Baud Rate
Data Bit
Stop Bit
Parity Bit
Stream Control
3.1. Communication timing
- The controller should wait for a packet interval before next command is sent.
The packet interval needs to be longer than 600msec for the LCD monitor
Setting
9600bps
8bit
1bit
None
None
