Product Description; Overview; Feature Summary - Intel BLKDG43GT Technical Product Specification

1

Product Description

1.1

Overview

1.1.1

Feature Summary

Table 1 summarizes the major features of Intel Desktop Board DG43GT.
Table 1. Feature Summary
Form Factor
Processor
Memory
Chipset
Audio
Video
Legacy I/O Control
MicroATX (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
Support for the following:
®
• Intel Core™2 Quad processor Q6000/Q8000/Q9000 Series in an LGA775
socket
®
• Intel Core™2 Duo processor E4000/E5000/E6000/E8000 Series in an LGA775
socket
® ®
• Intel Pentium Dual-Core processor E2000/E5000 Series in an LGA775 socket
® ®
• Intel Celeron Dual-Core processor 400/1000 Series in an LGA775 socket
® ®
• Intel Xeon processor 3000/X3000 Series in an LGA775 socket
• Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for up to 16 GB of system memory using non-ECC DDR2 800 or
667 MHz DIMMs
Intel ® G43 Express Chipset, consisting of:
• Intel ® 82G43 Graphics and Memory Controller Hub (GMCH)
• Intel ® 82801JIB I/O Controller Hub (ICH10)
10-channel (7.1 + 2) audio subsystem using Realtek ALC888S high definition
audio codec
Integrated graphics:
• Intel ® Graphics Media Accelerator X4500 (Intel
subsystem with support for:
― Analog displays (via a DVI-I to VGA adapter)
― Digital displays (DVI-I and HDMI)
• External graphics:
― PCI Express x16 add-in graphics card connector
― PCI Express x1 add-in graphics card connectors
― PCI conventional add-in graphics card connector
Winbond W83627DHG-A based Legacy I/O controller for hardware management
and serial, parallel, and PS/2* ports
® GMA X4500) onboard graphics
continued
9
