Intel® Desktop Board
DG41WV
Technical Product Specification
®
The Intel
Desktop Board DG41WV may contain design defects or errors known as errata that may cause the product to deviate from published specifications. Current
characterized errata are documented in the Intel Desktop Board DG41WV Specification Update.
March 2010
Order Number: E89654-001
Advertisement
Table of Contents
Related Manuals for Intel BLKDG41WV
Summary of Contents for Intel BLKDG41WV
- Page 1 Order Number: E89654-001 ® The Intel Desktop Board DG41WV may contain design defects or errors known as errata that may cause the product to deviate from published specifications. Current characterized errata are documented in the Intel Desktop Board DG41WV Specification Update.
-
Page 2: Revision History
North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777, Germany 44-0-1793-421-333, other Countries 708-296-9333. Intel and the Intel logo are registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. * Other names and brands may be claimed as the property of others. -
Page 3: Intended Audience
DG41WV. It describes the standard product and available manufacturing options. Intended Audience The TPS is intended to provide detailed, technical information about the Intel Desktop Board DG41WV and its components to the vendors, system integrators, and other engineers and technicians who need this level of information. It is specifically not intended for general audiences. - Page 4 Intel Desktop Board DG41WV Technical Product Specification Other Common Notation Used after a signal name to identify an active-low signal (such as USBP0#) Gigabyte (1,073,741,824 bytes) GB/s Gigabytes per second Gbit Gigabit (1, 073,741,824 bits) Kilobyte (1024 bytes) Kbit Kilobit (1024 bits)
-
Page 5: Table Of Contents
Contents 1 Product Description 1.1 Overview..................7 1.1.1 Feature Summary ..............7 1.1.2 Memory Considerations ............8 1.1.3 Board Layout ................. 9 1.2 Online Support/Information .............. 11 2 Technical Reference 2.1 Connectors, Headers, and Jumpers ............ 13 2.1.1 Component-side Headers and Connectors ........ 13 2.1.2 Jumpers................ - Page 6 Intel Desktop Board DG41WV Technical Product Specification Tables Feature Summary................7 Board Components Shown in Figure 1 ..........10 Connectors and Headers Shown in Figure 2 ......... 14 Serial ATA Connectors ..............14 Serial Port B Connector ..............15 Chassis Fan Header ................. 15 Processor Fan Header ..............
-
Page 7: Product Description
Product Description Overview 1.1.1 Feature Summary Table 1 summarizes the major features of the Intel Desktop Board DG41WV. Table 1. Feature Summary Form Factor MicroATX (9.60 inches by 7.80 inches [243.84 millimeters by 198.12 millimeters]) Processor Support for the following: •... -
Page 8: Memory Considerations
Intel Desktop Board DG41WV Technical Product Specification Table 1. Feature Summary (continued) • Support for PCI* Local Bus Specification, Revision 2.3 Instantly Available PC Technology • Support for PCI Express* Revision 1.1 • Suspend to RAM support • Wake on PCI, serial port, front panel, PS/2 devices, PCI Express, LAN, and USB ports •... -
Page 9: Board Layout
Technical Reference 1.1.3 Board Layout Figure 1 shows the location of the major components of Intel Desktop DG41WV. Figure 1. Major Board Components... - Page 10 Intel Desktop Board DG41WV Technical Product Specification Table 2 lists the components identified in Figure 1. Table 2. Board Components Shown in Figure 1 Item/callout from Figure 1 Description Conventional PCI bus add-in card connector Conventional PCI bus add-in card connector...
-
Page 11: Online Support/Information
Online Support/Information To find information about… Visit this World Wide Web site: Intel Desktop Board DG41WV http://www.intel.com/products/motherboard/DG41WV/index.htm Desktop Board Support http://www.intel.com/support/motherboards/desktop Available configurations for the Intel http://www.intel.com/products/motherboard/DG41WV/index.htm Desktop Board DG41WV Supported processors http://processormatch.intel.com Chipset information http://www.intel.com/products/desktop/chipsets/index.htm BIOS and driver updates http://downloadcenter.intel.com... - Page 12 Intel Desktop Board DG41WV Technical Product Specification...
-
Page 13: Technical Reference
Technical Reference Technical Reference Connectors, Headers, and Jumpers This section describes the board’s connectors, headers, and jumpers. 2.1.1 Component-side Headers and Connectors Figure 2 shows the location of the component-side headers and connectors. Figure 2. Component-side Connectors and Headers... -
Page 14: Connectors And Headers Shown In Figure 2
Intel Desktop Board DG41WV Technical Product Specification Table 3 lists the connectors and headers identified in Figure 2. Table 3. Connectors and Headers Shown in Figure 2 Item/callout in Figure 2 Description Chassis fan header Processor core power connector (2 X 2) -
Page 15: Serial Port B Connector
Technical Reference Table 5. Serial Port B Connector Signal Name Signal Name DDCD2# RRXD2 TTXD2 DDTR2# Ground DDSR2# RRTS2# CCTS2# RRI2# Key (no pin) Table 6. Chassis Fan Header Signal Name Sense +12 V Ground Table 7. Processor Fan Header Signal Name Ground +12 V... -
Page 16: Front Panel Header
Intel Desktop Board DG41WV Technical Product Specification Table 10. Front Panel Header Signal Name Signal Name HDLED+ FP_LED+ HDLED- FP_LED- Ground FP_PWRBTN# FP_SYS_RST# Ground FPA_DET# Key (no pin) Table 11. Front Panel USB1/USB2 Header Signal Name Signal Name +5V_Dual +5V_Dual... -
Page 17: Jumpers
Technical Reference 2.1.2 Jumpers Figure 3 shows the location of the board’s jumper blocks. Figure 3. Jumpers Table 15 lists the jumper blocks identified in Figure 3. Table 15. Jumpers Shown in Figure 3 Item/callout in Figure 3 Description Keyboard power jumper block Clear CMOS jumper block... -
Page 18: Clear Cmos Jumper Settings
Intel Desktop Board DG41WV Technical Product Specification Table 16 and Table 17 list the settings for the jumper blocks. Table 16. Clear CMOS Jumper Settings Function/Mode Jumper Setting Description Normal The BIOS uses current configuration information and passwords for booting. -
Page 19: Back Panel Connectors
Technical Reference 2.1.3 Back Panel Connectors Figure 4 shows the locations of the back panel connectors. Item Description PS/2 mouse PS/2 keyboard Serial A Parallel USB 2.0 (2) USB 2.0 (2) Line in Line out Figure 4. Back Panel Connectors... -
Page 20: Mechanical Considerations
Intel Desktop Board DG41WV Technical Product Specification Mechanical Considerations 2.2.1 Form Factor The board is designed to fit into a microATX-form-factor chassis. Figure 5 illustrates the mechanical form factor of the board. Dimensions are given in inches [millimeters]. The outer dimensions are 9.60 inches by 7.80 inches [243.84 millimeters by 198.12 millimeters]. -
Page 21: Electrical Considerations
CAUTION All responsibility for determining the adequacy of any thermal or system design remains solely with the reader. Intel makes no warranties or representations that merely following the instructions presented in this document will result in a system with adequate thermal performance. -
Page 22: Reliability
The calculation is based on Telcordia Issue 2. The MTBF prediction is used to estimate repair rates and spare parts requirements. The MTBF data is calculated from predicted data at 50 ºC. The Intel Desktop Board DG41WV MTBF is 274,423 hours. -
Page 23: Regulatory Compliance And Battery Disposal Information
Electromagnetic Compatibility (EMC) standards • Product certification markings 3.1.1 Safety Standards The Intel Desktop Board DG41WV complies with the safety standards stated in Table 21 when correctly installed in a compatible host system. Table 21. Safety Standards Standard Title CSA/UL 60950-1 Information Technology Equipment –... -
Page 24: European Union Declaration Of Conformity Statement
European Union Declaration of Conformity Statement ® We, Intel Corporation, declare under our sole responsibility that the product Intel Desktop Board DG41WV is in conformity with all applicable essential requirements necessary for CE marking, following the provisions of the European Council Directive 2004/108/EC (EMC Directive), 2006/95/EC (Low Voltage Directive), and 2002/95/EC (ROHS Directive). -
Page 25: Product Ecology Statements
恰当的重复使用处理。 请参考http://www.intel.com/intel/other/ehs/product_ecology 了解此计划的详情，包括涉及产品之范围、回收地点、运送指导、条款和条件等。 Deutsch Als Teil von Intels Engagement für den Umweltschutz hat das Unternehmen das Intel Produkt-Recyclingprogramm implementiert, das Einzelhandelskunden von Intel Markenprodukten ermöglicht, gebrauchte Produkte an ausgewählte Standorte für ordnungsgemäßes Recycling zurückzugeben. Details zu diesem Programm, einschließlich der darin eingeschlossenen Produkte, verfügbaren Standorte, Versandanweisungen, Bedingungen usw., finden Sie auf der... - Page 26 Français Dans le cadre de son engagement pour la protection de l'environnement, Intel a mis en œuvre le programme Intel Product Recycling Program (Programme de recyclage des produits Intel) pour permettre aux consommateurs de produits Intel de recycler les produits usés en les retournant à...
-
Page 27: Emc Regulations
şartlar v.s dahil bütün ayrıntılarını ögrenmek için lütfen http://www.intel.com/intel/other/ehs/product_ecology Web sayfasına gidin. 3.1.4 EMC Regulations The Intel Desktop Board DG41WV complies with the EMC regulations stated in Table 22 when correctly installed in a compatible host system. Table 22. EMC Regulations Regulation Title... - Page 28 • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to the equipment not expressly approved by Intel Corporation could void the user’s authority to operate the equipment. Tested to comply with FCC standards for home or office use.
- Page 29 Regulatory Compliance and Battery Disposal Information Japan VCCI Statement Japan VCCI Statement translation: This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may cause radio interference.
-
Page 30: Regulatory Compliance Marks (Board Level)
Intel Desktop Board DG41WV Technical Product Specification 3.1.5 Regulatory Compliance Marks (Board Level) Intel Desktop Board DG41WV has the regulatory compliance marks shown in Table 23. Table 23. Regulatory Compliance Marks Description Mark UL joint US/Canada Recognized Component mark. Includes adjacent UL file number for Intel Desktop Boards: E210882. -
Page 31: Battery Disposal Information
Regulatory Compliance and Battery Disposal Information Battery Disposal Information CAUTION Risk of explosion if the battery is replaced with an incorrect type. Batteries should be recycled where possible. Disposal of used batteries must be in accordance with local environmental regulations. PRÉCAUTION Risque d'explosion si la pile usagée est remplacée par une pile de type incorrect. - Page 32 Intel Desktop Board DG41WV Technical Product Specification PRECAUCIÓN Existe peligro de explosión si la pila no se cambia de forma adecuada. Utilice solamente pilas iguales o del mismo tipo que las recomendadas por el fabricante del equipo. Para deshacerse de las pilas usadas, siga igualmente las instrucciones del fabricante.
- Page 33 Regulatory Compliance and Battery Disposal Information AWAS Risiko letupan wujud jika bateri digantikan dengan jenis yang tidak betul. Bateri sepatutnya dikitar semula jika boleh. Pelupusan bateri terpakai mestilah mematuhi peraturan alam sekitar tempatan. OSTRZEŻENIE Istnieje niebezpieczeństwo wybuchu w przypadku zastosowania niewłaściwego typu baterii.
- Page 34 Intel Desktop Board DG41WV Technical Product Specification...
