Fan Header Current Capability; Power Supply Considerations - Intel BLKD945GCCR Specification

2.10.3

Fan Header Current Capability

CAUTION
The processor fan must be connected to the processor fan header, not to a chassis fan
header. Connecting the processor fan to a chassis fan header may result in onboard
component damage that will halt fan operation.
Table 29 lists the current capability of the fan headers.
Table 29. Fan Header Current Capability
Fan Header
Processor fan
Front chassis fan
Rear chassis fan
2.10.4

Power Supply Considerations

CAUTION
The +5 V standby line for the power supply must be capable of providing adequate
+5 V standby current. Failure to do so can damage the power supply. The total
amount of standby current required depends on the wake devices supported and
manufacturing options.
System integrators should refer to the power usage values listed in Table 28 when
selecting a power supply for use with the board.
Additional power required will depend on configurations chosen by the integrator.
The power supply must comply with the following recommendations found in the ATX
form factor specification:
• The potential relation between 3.3 VDC and +5 VDC power rails
• The current capability of the +5 VSB line
• All timing parameters
• All voltage tolerances
Maximum Available Current
2.0 A
1.5 A
1.5 A
Technical Reference
63
